HN3A51F
TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)
HN3A51F
Audio Frequency General Purpose Amplifier Applications
High voltage
: V
CEO
=
−120V
: h
FE
= 200 to 700
High h
FE
Excellent h
FE
linearity
: h
FE
(I
C
=
−0.1mA)
/ h
FE
(I
C
=
−2mA)
= 0.95 (typ.)
Low noise
: NF = 1dB (typ.)
Unit: mm
(Q1, Q2 Common)
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
*
T
j
T
stg
Rating
−120
−120
−5
−100
−20
300
150
−55
to 150
Unit
V
V
V
mA
mA
mW
°C
°C
1.COLLECTOR1
2.EMITTER 1
3.COLLECTOR2
4.EMITTER 2
5.BASE 2
6.BASE 1
(C1)
(E1)
(C2)
(E2)
(B2)
(B1)
Note:
JEDEC
―
Using continuously under heavy loads (e.g. the application of high
JEITA
―
temperature/current/voltage and the significant change in
TOSHIBA
2-3N1B
temperature, etc.) may cause this product to decrease in the
Weight: 0.015 g (typ.)
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
* Total rating. Power dissipation per element should not exceed 200mW.
Electrical Characteristics
(Ta = 25°C) (Q1,Q2 Common)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter
saturation voltage
Transition frequency
Collector output capacitance
Noise figure
Symbol
I
CBO
I
EBO
h
FE
V
CE
f
T
C
ob
NF
Test
Circuit
―
―
―
―
―
―
―
Test Condition
V
CB
=
−120V,
I
E
= 0
V
EB
=
−5V,
I
C
= 0
V
CE
=
−6V,
I
C
=
−2mA
I
C
=
−10mA,
I
B
=
−1mA
V
CE
=
−6V,
I
C
=
−1mA
V
CB
=
−10V,
I
E
= 0, f = 1MHz
V
CE
= −6
V, I
C
= −0.1
mA
f
=
1 kHz,R
g
=
10 kΩ
Min
―
―
200
―
―
―
―
Typ.
―
―
―
―
100
4
1.0
Max
−0.1
−0.1
700
−0.3
―
―
―
V
MHz
pF
dB
Unit
μA
μA
Marking
Equivalent Circuit
(top view)
6
Q1
5
4
48
Q2
Start of commercial production
1
2
3
2000-12
1
2014-03-01
HN3A51F
