Data Sheet
16 Amp ULTRAFAST
SWITCHMODE POWER
PLASTIC RECTIFIERS
Mechanical Dimensions
JEDEC
TO-220AB
UF16C05 . . . 60 Series
Description
1
3
1
3
2
CASE
Common Anode Suffix A
2
CASE
Double Suffix D
1
3
2
CASE
Common Cathode Suffix C
Features
n
LOW FORWARD VOLTAGE
n
HIGH SURGE CAPABILITY
n
ULTRAFAST RECOVERY TIME
n
MEETS UL SPECIFICATION 94V-0
UF16C05 . . . 60 Series
Maximum Ratings
Peak Repetitive Reverse Voltage...V
RRM
Working Peak Reverse Voltage...V
RWM
DC Blocking Voltage...V
DC
RMS Reverse Voltage...V
R(rms)
Average Forward Rectified Current...I
F(av)
T
C
= 150°C @ Rated V
DC
Repetitive Peak Forward Surge Current...I
FM
@ Rated V
DC
, Square Wave, 20 kHz, T
C
= 150°C
05
50
50
50
35
10
100
100
100
70
15
150
150
150
105
20
200
200
200
140
30
300
300
300
210
40
400
400
400
280
50
500
500
500
350
60
600
600
600
420
Units
Volts
Volts
Volts
Volts
Amps
Amps
Amps
Amps
°C
............................................. 8.0 ...............................................
............................................. 1 6 ...............................................
............................................. 1 6 ...............................................
............................................. 125 ...............................................
Non-Repetitive Peak Forward Surge Current...I
FSM
@ Rated Load Cond., ½ Wave, Single Phase, 60Hz
........................................ -65 to 150 .........................................
Operating & Storage Temperature Range...T , T
J
STRG
Electrical Characteristics
Maximum Forward Voltage...V
F
@ I
F
= 8 Amps, PW = 300µs
Maximum DC Reverse Current...I
R
@ Rated DC Blocking Voltage
T
C
= 150°C
T
C
= 25°C
T
C
=150°C
T
C
= 25°C
< ................ 0.895 ............... > < ..... 1.0 ... > < ..... 1.2 ..... >
< ................ 0.975 ............... > < ..... 1.3 ... > < ..... 1.5 ..... >
Volts
Volts
............................................. 500 ...............................................
µAmps
............................................. 10 ...............................................
µAmps
< ................ 35 ............... > < .................. 50 .................. >
ns
Maximum Reverse Recovery Time...t
RR
I
F
= 1.0 Amp, di/dt = 50 Amps/µs
Page 4-36
Data Sheet
16 Amp ULTRAFAST
SWITCHMODE POWER
PLASTIC RECTIFIERS
Peak Forward Surge Current (A)
Non-Repetitive
Peak Forward Surge Current
Forward Current Derating Curve
Average Forward Current (A)
12
10
8
6
4
2
0
25 50 75 100 125 150 175
Ambient Temperature (°C)
°
Typical Reverse Characteristics
Junction Capacitance (pF)
µ
Reverse Current (µA)
200
100
10
1
10
100
Number of Cycles @ 60 Hz
Typical Junction Capacitance
UF16C05...20
UF16C50 & 60
UF16C05...20
UF16C30 & 40
UF16C50 & 60
UF16C30 & 40
Reverse Voltage (V)
Reverse Voltage (V)
Reverse Recovery
Characteristics
Non-Inductive
50Ω
Ω
25 VDC
Ω
D.U.T 10Ω
1
Ω
Non-
Inductive
(-)
Pulse
Generator
Note 2
Typical Instantaneous
Forward Characteristics
Forward Current (A)
UF16C05...20
(+)
(-)
+.5A
0A
-.25A
-1.0A
t
RR
Ratings at
25 Deg. C ambient
temperature
unless otherwise
specified.
1 cm
Single Phase Half
Wave, 60 Hz
Resistive or
Inductive Load.
For Capacitive
Load, Derate
Current by 20%.
Oscilliscope (+)
Note 1
Notes:
UF16C30...60
Forward Voltage (V)
1 . Rise Time = 7 ns Max.
Impedance = 1 megohm, 22 pF
2 . Rise Time = 10 ns Max.
Source Impedance = 50 Ohms
Time Base Set @ 50/100ns/cm
Page 4-37
UF16C05 . . . 60 Series
Industrial Control Electronics
