TAW Series
Tantalum Solid Electrolytic Fused Capacitors
• Thin film fuse connected in series with capacitor
• Protection from possible damaging from high DC
leakage current (short circuit failure)
• CV range: 6.8-100μF / 10-50V
• Application: servers
LEAD-FREE COMPATIBLE
COMPONENT
CASE DIMENSIONS:
millimeters (inches)
Code
D
EIA
Code
EIA
Metric
L±0.20
(0.008)
W+0.20 (0.008) H+0.20 (0.008)
-0.10 (0.004)
–0.10 (0.004)
4.30 (0.169)
2.90 (0.114)
W
1
±0.20
(0.008)
2.40 (0.094)
A+0.30 (0.012)
-0.20 (0.008)
1.30 (0.051)
S Min.
4.40 (0.173)
2917 7343-31 7.30 (0.287)
W
1
dimension applies to the termination width for A dimensional area only.
For part marking see page 169
HOW TO ORDER
D
TAW
Type
Case Size
See table
above
476
*
Tolerance
K=±10%
M=±20%
010
R
0500
Capacitance Code
pF code: 1st two
digits represent
significant figures
3rd digit represents
multiplier (number of
zeros to follow)
Rated DC Voltage
010=10Vdc
016=16Vdc
020=20Vdc
025=25Vdc
035=35Vdc
050=50Vdc
Packaging
R = Pure Tin 7" Reel
S = Pure Tin 13" Reel
ESR in mΩ
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage (V
R
)
Category Voltage (V
C
)
Surge Voltage (V
s
)
Surge Voltage (V
s
)
Fuse Off
Fuse Continuous Current Capability
Temperature Range:
Reliability:
All technical data relate to an ambient temperature of +25°C
6.8 μF to 100 μF
±10%; ±20%
10
16
20
25
35
50
7
10
13
17
23
33
13
20
26
32
46
65
8
13
16
20
28
40
I > 4A in 1s, insulating resistance > 10MΩ
0.75A
-55°C to +125°C
1% per 1000 hours at 85°C, Vr with 0.1Ω/V series impedance,
60% confidence level
+85°C:
+125°C:
+85°C:
+125°C:
114
■
JANUARY 2014
TAW Series
Tantalum Solid Electrolytic Fused Capacitors
CAPACITANCE AND RATED VOLTAGE RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
μF
Code
1.0
105
2.2
225
4.7
475
6.8
685
10
106
22
226
33
336
47
476
100
107
6.3V (J)
10V (A)
Rated Voltage DC (V
R
) to 85°C
16V (C)
20V (D)
25V (E)
35V (V)
50V (T)
D(500)
D(500)
D(600)
D(800)
D(500)
D(500)
D(600)
D(600)
D(600)
D(600)
D(700)
D(700)
Available Ratings (ESR ratings in mOhms in brackets)
Engineering samples - please contact manufacturer
*Codes under development – subject to change
Note: Voltage ratings are minimum values. AVX reserves the right to supply
higher ratings in the same case size, to the same reliability standards.
RATINGS & PART NUMBER REFERENCE
AVX
Part No.
Rated
Case Capacitance Voltage
Size
(μF)
(V)
DCL
DF
ESR
(μA)
% Max. (mΩ) MSL
Max. Max. @100kHz
100kHz RMS Current (mA)
25ºC
85ºC
125ºC
100kHz RMS Voltage (mV)
25ºC
85ºC
125ºC
10 Volt @ 85ºC (7 Volt @ 125ºC)
TAWD476*010#0500
TAWD107*010#0500
TAWD336*016#0600
TAWD476*016#0800
TAWD226*020#0500
TAWD336*020#0500
TAWD106*025#0600
TAWD226*025#0600
TAWD685*035#0600
TAWD106*035#0600
TAWD685*050#0700
TAWD106*050#0700
D
D
D
D
D
D
D
D
D
D
D
D
47
100
33
47
22
33
10
22
6.8
10
6.8
10
10
10
16
16
20
20
25
25
35
35
50
50
4.7
10
6
8
500
500
1
1
548
548
493
493
450
390
493
493
450
450
450
450
417
417
219
219
200
173
219
219
200
200
200
200
185
185
274
274
300
346
274
274
300
300
300
300
324
324
246
246
270
312
246
246
270
270
270
270
292
292
110
110
120
139
110
110
120
120
120
120
130
130
16 Volt @ 85°C (10 Volt @ 125°C)
5.3
6
600
1
500
7.5
7
800
1
433
20 Volt @ 85ºC (13 Volt @ 125ºC)
4.4
6
500
1
548
6.6
6
500
1
548
25 Volt @ 85ºC (17 Volt @ 125ºC)
2.5
6
600
1
500
5.5
6
600
1
500
35 Volt @ 85ºC (23 Volt @ 125ºC)
2.4
6
600
1
500
3.5
6
600
1
500
50 Volt @ 85ºC (33 Volt @ 125ºC)
3.4
6
700
1
463
5
6
700
1
463
Moisture Sensitivity Level (MSL) is defined according to J-STD-020.
All technical data relates to an ambient temperature of +25°C. Capacitance
and DF are measured at 120Hz, 0.5V RMS with a maximum DC bias of 2.2 volts.
DCL is measured at rated voltage after 5 minutes.
For typical weight and composition see page 162.
NOTE: AVX reserves the right to supply a higher voltage rating or tighter
tolerance part in the same case size, to the same reliability standards.
TYPICAL FUSE ACTUATION
Typical Actuation Time vs Load Current
100.000
10.000
1.000
0.100
0.010
0.001
1
10
Actuation Time [ms]
Current [A]
100
Note: for a different fuse characteristic
requirements please contact manufacturer
JANUARY 2014
■
115
