Electronic housing - HCS-T MINI 1W 3AA C C 7035 - 2203134
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Handheld housing, T-Mini, light gray, consisting of two half shells with screws. Front 1.1 mm recessed, with
window and keypad slot, battery compartment cover and battery contacts for 3 AA batteries
Your advantages
Item is from the HCS product range
Suitable for handheld devices
Ergonomic straight or staggered housing design
Integration of LCD displays and membrane keypads
Degree of protection: up to IP54
Temperature range: -20 °C to +50 °C
Shock-resistant ABS plastic
Flammability rating UL 94-V0
Key Commercial Data
Packing unit
GTIN
GTIN
4055626376882
1 pc
Technical data
Item properties
Type
Order No.
Type
Housing type
Battery compartment
HCS-T MINI 1W 3AA C C 7035
2203134
stepped
Complete housing
3 x AA
Measurements
Caption
Schematic representation – for additional information, see product range
drawing in the Download Center
11/22/2018 Page 1 / 3
https://www.phoenixcontact.com/pi/products/2203134
Electronic housing - HCS-T MINI 1W 3AA C C 7035 - 2203134
Technical data
Measurements
Width [ w ]
Height [ h ]
Depth [ d ]
Dimensions
85 mm
182.5 mm
30 mm
x 1.1 mm (Recessed area on front)
62 mm x 32.6 mm (Window for display)
41 mm x 3.5 mm (Opening for membrane cable)
Material specifications
Housing material
Color (RAL)
ABS
light gray (7035)
Hammer test
Specification
Impact energy
Number of drop cycles
IEC 60068-2-75:2014-09
0.7 J
5
Thermostability (ball thrust test)
Specification
Temperature
Test duration
Force
IEC 60695-10-2:2014-02
80 °C
1h
20
Test for assessing the risk of fire (glow wire)
Specification
Temperature
Time of exposure
IEC 60695-2-11:2014-02
850 °C
30 s
Degrees of protection provided by enclosures (IP code)
Specification
Result, degree of protection, IP code
IEC 60529:1989-11 + AMD 1:1999-11 + AMD 2:2013-08
IP40
Packaging information
Pieces per package
Denomination packing units
1
Pcs.
Drawings
Dimensional drawing
W
h
d
Schematic representation – for additional information, see product range drawing in the Download Center
