Omni Smart UPS System - Line-interactive, tower
battery backup with hospital grade plug and
receptacles
MODEL NUMBER:
OMNISMART700HG
Description
Tripp Lite's OMNI SMART 700HG offers UPS protection, built-in line interactive voltage regulation,
intelligent monitoring and unattended shutdown capability. 700VA power handling capacity supports
computers, internetworking equipment and other critical loads during commercial power failures. Line
interactive voltage regulation corrects brownouts as low as 75V and overvoltages as high as 147V back to
normal 120V levels, saving battery reserves for use only during complete power failures. Includes 4
hospital grade outlets, diagnostic LEDs and built-in DB9 communications port that works with web
downloadable PowerAlert Software and cabling to provide automatic unattended shutdown of connected
network and PC applications.
Highlights
q
700VA line interactive tower
UPS system
q
Hospital grade plug and 4
NEMA5-15R hospital grade
output receptacles
q
Corrects brownouts and
overvoltages from 75 to 147V
without using battery power
q
Enhanced DB9 communications
port
Features
q
Package Includes
q
Ideal UPS protection for mission critical equipment and computers where hospital-grade input/output
connections are required
OMNI SMART 700HG UPS
System
q
Provides connected equipment with continuous power during short and long duration loss of commercial
power
q
RS-232 monitoring cable
Warranty information
Instruction manual
q
q
Line-interactive voltage regulation corrects brownouts and overvoltages from 75 to 147 volts back to
usable 120v output levels, without using battery power
q
q
Hospital-grade plug and outlets offer added degree of safety to input/output connections
Supports loads up to 700VA/425 watts
22 minutes half load runtime (with 350VA load), 9 minutes full load runtime (with 700VA load)
Hospital grade input plug and 4 NEMA5-15R hospital grade output receptacles
1-DB9 serial port for network interface; SNMP compatible
Surge protection and EMI/RFI noise filtering
PowerAlert UPS monitoring and auto-shutdown software available for free download from
www.tripplite.com
q
q
q
q
q
q
q
Includes complete cabling for remote monitoring via PowerAlert software
4 diagnostic LEDs indicate AC present, on battery, voltage correction & battery low/replace
Battery replacement door
2 year product warranty
q
q
q
Specifications
OVERVIEW
UPC Code
037332100504
OUTPUT
Frequency Compatibility
60 Hz
1/4
Output (VA)
Output (Watts)
Output Nominal Voltage
Output Voltage Regulation
Output Frequency Regulation
700
425
120V nominal
LINE MODE: Sine wave line voltage 120V (-18% / +8%)<br> BATTERY MODE: PWM sine wave output 120V +/-5%
LINE MODE: Passes line frequency of 60Hz +/-10% <br> BATTERY MODE: Inverter output regulated to 60Hz +/-
0.5Hz
INPUT
UPS Input Cord Length (ft.)
UPS Input Cord Length (m)
Recommended Electrical Service
Maximum Input Amps
Maximum Input Watts
Input Connection Type
Voltage Compatibility (VAC)
6
1.8
15A 120V
3.8
460
NEMA 5-15P Hospital-Grade
120
BATTERY
Full Load Runtime (min.)
Half Load Runtime (min.)
DC System Voltage (VDC)
Battery Access
Replacement Battery Cartridge
Typical Battery Lifespan
Battery Charge
9 minutes (700VA)
22 minutes (350VA)
12
Battery access door allows hot swap battery replacement without powering connected equipment off
<a class="productLink" href="//www.tripplite.com/UPS-Replacement-Battery-Cartridge-select-Tripp-Lite-Best-
Liebert-Minuteman-other-UPS~RBC52">RBC52</a> (quantity 2)
3-6 years, depending on usage
2-4 hours to 90%
VOLTAGE REGULATION
Voltage Regulation Description
Overvoltage Correction
Brownout Correction
Severe Brownout Correction
Automatic Voltage Regulation (AVR) circuits maintain clean, regulated computer-grade 120V nominal output, without
using battery power, during brownouts to 75V and overvoltages to 147V
Input voltages between 128 and 147V AC are reduced by 12%
Input voltages between 93 and 107V AC are boosted by 14%
Input voltages between 75 and 92V AC are boosted by 30%
USER INTERFACE, ALERTS & CONTROLS
Front Panel LEDs
Switches
Audible Alarm
4 front-panel indicator LEDs to display line power status, battery power status, battery low/replace status and voltage
regulation operation
Yes, includes 2 front panel mounted push-button switches for system enable, self-test and alarm cancel functions
Audible alarm indicates power failure conditions, silenceable via alarm cancel switch. Once cancelled, alarm will
resume when approximately 2 minutes of battery operation remain (assuming full load).
2/4
SURGE / NOISE SUPPRESSION
EMI / RFI AC Noise Suppression
AC Suppression Response Time
Dataline Suppression
Yes
Instantaneous
-
PHYSICAL
Shipping Dimensions (hwd / in.)
Shipping Dimensions (hwd / cm)
Shipping Weight (lbs.)
Shipping Weight (kg)
Unit Dimensions (hwd / in.)
Unit Dimensions (hwd / cm)
Unit Weight (lbs.)
Unit Weight (kg)
Cooling Method
Material of Construction
Form Factors Supported
14.00 x 8.50 x 11.00
35.56 x 21.59 x 27.94
23.00
10.43
10.75 x 5.25 x 7.25
27.3 x 13.3 x 18.4
20
9.07
Convection
PVC
Tower
ENVIRONMENTAL
Relative Humidity
0 to 95%, non-condensing
COMMUNICATIONS
Network Monitoring Port
DB9
LINE / BATTERY TRANSFER
Transfer Time (Line Power to
Battery Mode)
Low Voltage Transfer to Battery
Power
High Voltage Transfer to Battery
Power
2-4 milliseconds
75V (resets to line power as voltage increases to 79V)
147V (resets to line power as voltage decreases to 143V)
SPECIAL FEATURES
Cold Start
Yes, inverter can be "cold started" to enable temporary AC output during a power failure
CERTIFICATIONS
Certifications
Tested to UL1778 (USA, Series AGOM700KSR61), cUL (Canada), FCC Class A (emissions)
WARRANTY
3/4
Product Warranty Period
(Worldwide)
Optional Coverage
2-year limited warranty
3 year, 5 year, next day and on-site warranty coverage available
