INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 800 01
Panel Mount, Shocksafe Specifications
Standard
6.3x32mm Fuses
IEC 60127-6
Fuse carrier inserted
max. 0,2
4,45
0,5
UL 512
Approvals
M12,7x1,5
7,62
VDE: License No. 123336
SEMKO: Certificate No. 9850284
UL Recognized: File No. E 70164
Mounting
Bayonet-joint
3,2 2,5
11,7 -0,15
12 -0,1
12.7mm diameter D-hole or double D-hole
Admissible torque on plastic hex nut is 1.2Nm
Solderable or 4.8mm quick connect-fits 0.5mm tab
IP 40 (IEC 60529)
PC2 (IEC 60127-6)
Holder/Cap:
Metal Parts:
Terminals:
Te r m i n a l s
SW14
∅
15
∅
16
4,8
Protection Class & Category
Materials
12,7 -0,1
12,7 -0,1
Panel alternatives
5,5 1...6 5
45,7
8
Cap / No. 816
Black Thermoplastic
Polyamide PA 6.6, UL94 V-0
Copper alloy,
corrosion protected
Solderable, tinned
Slot for screwdriver
Bayonet-connector-nose
Electrical Data (23ºC)
Rated Voltage: 500V
Rated Current: 10A (800+816 - VDE/SEMKO)
16A (UL/CSA)
Rated Power : 2.5W (VDE/SEMKO)
-25ºC to +70ºC (consider de-rating)
-25ºC/+70ºC/21 days (IEC 60068-2-1...3)
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
≤
5mΩ
∅
9,2
7
For 6.3x32mm Fuses
Temperature
Operating Temperature
1,5
max. 33,8
1,2
Test
Climatic Test
Stock Conditions
Vibration Resistance
Contact Resistance
Dielectric Strength
> 1.5 kV
Impulse Voltage
4 kV, 50 Hz, 1 min., dry
> 10
3
MΩ (500 VDC, 1 min.)
235ºC, 3 sec. (Wave)
350ºC, 1 sec. (Manual)
260ºC, 5 sec. (IEC 60068-2-20)
Conductor - 2.5mm
2
Insulation Resistance
Solderability
Order Information
Packaging
Bulk (100 pcs.)
Soldering Heat Resistance
Minimum Cross Section
Marking
800 01, 500V, Approvals
4.7g (Holder) / 2.5g (Cap)
Order Numbers
Holder
Cap, 6.3x32mm
No. 800 0000 010
No. 816 0000 000
Unit Weight
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
