INTERCONNECTS
SERIES 830, 831, 832, 833 • 2mm
GRID GULL WING SURFACE MOUNT
HEADERS AND SOCKETS • SINGLE AND DOUBLE ROW STRIPS
Left Hand
Footprint
•
Headers (830 & 832) use MM #6218 pins. See
page 208 for details
.087
Number of Pins
X 2mm
.019 DIA.
.142
•
Sockets (831 & 833) use MM #1802 receptacles
.110
.189
Right Hand
Footprint
.090
and accept pin diameters from .015”-.025”.
See page 169 for details
•
Coplanarity .005” (Single Row max 12 pins;
4mm
.045
2mm
.190
.173
P.C.B.
Double Row max 24 pins) For higher pin
counts, contact Technical Support
Coplanarity .005”. For pin counts >12 positions, consult
Technical Support.
FIG. 1
.165
2mm
Number of Pins
X 2mm / 2
.095
.019
DIA.
.142
.045
.110
.189
.270
•
Contact is rated at 3 amps
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
ORDERING INFORMATION
2mm
FIG. 1L
FIG. 1R
FIG. 2
Single Row Header, Left Hand Footprint, Odd or Even # of pins
830 XX 0_ _ 30 001000
Specify number of pins
02-50
Footprint
.252
P.C.B.
2mm
Single Row Header, Right Hand Footprint, Even # of pins
830 XX 0_ _ 30 002000
Specify number of pins
02-50
Coplanarity .005”. For pin counts >24 positions, consult
Technical Support.
FIG. 2
Left Hand
Footprint
.087
Number of Pins
X 2mm
Double Row Header, Even # of pins
832 XX _ _ _ 30 001000
Specify number of pins
004-100
90
200
µ”
Sn/Pb
SPECIFY PLATING CODE XX=
Right Hand
Footprint
.090
10
10
µ”
Au
40
200
µ”
Sn
.145
.083
.110
.228
Pin Plating
.173
P.C.B.
2mm
4mm
.045
FIG. 3L
FIG. 3R
FIG. 4
RoHS - 2
Single Row Socket, Left Hand Footprint, Odd or Even # of pins
831 XX 0_ _ 30 001000
Specify number of pins
02-50
.190
Coplanarity .005”. For pin counts >12 positions, consult
Technical Support.
FIG. 3
.165
Single Row Socket, Right Hand Footprint, Even # of pins
831 XX 0_ _ 30 002000
Specify number of pins
02-50
PAGE 44 | INTERCONNECTS
2mm
Number of Pins
X 2mm / 2
.095
Double Row Socket, Even # of pins
833 XX _ _ _ 30 001000
Specify number of pins
XX=Plating Code
See Below
91
10
µ”
Au
.145
.083
2mm
.110
.228
.045
004-100
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.270
.252
P.C.B.
2mm
Footprint
2011/65/EU
Coplanarity .005”. For pin counts >24 positions, consult
Technical Support.
FIG. 4
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
93
30
µ”
Au
41
200
µ”
Sn
10
µ”
Au
43
200
µ”
Sn
30
µ”
Au
200
µ”
Sn/Pb 200
µ”
Sn/Pb
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
