GMZ12XX75_series
1.2” 5x7 Dot Matrix
---------------------------------------------------------------------------------------------------------------------------------------
QT-Brightek Corporation
1.2” 5×7 Dot Matrix
Part No.: GMZ12XX75_series
Product: GMZ12XX75_series
Date: June 22, 2015
Version# 1.5
Page 1 of 13
GMZ12XX75_series
1.2” 5x7 Dot Matrix
---------------------------------------------------------------------------------------------------------------------------------------
Table of Contents:
Introduction ........................................................................................................................................... 3
Electrical / Optical Characteristic (Ta=25
o
C) ........................................................................................ 4
Absolute Maximum Rating .................................................................................................................... 4
Pin Configuration .................................................................................................................................. 7
Characteristic Curves ............................................................................................................................ 8
Solder Profile ...................................................................................................................................... 10
Package Dimensions .......................................................................................................................... 11
Ordering Information ........................................................................................................................... 12
Revision History .................................................................................................................................. 13
Disclaimer ........................................................................................................................................... 13
Product: GMZ12XX75_series
Date: June 22, 2015
Version# 1.5
Page 2 of 13
GMZ12XX75_series
1.2” 5x7 Dot Matrix
---------------------------------------------------------------------------------------------------------------------------------------
Introduction
Feature:
Low power consumption
Packed in foam
AlInGaP technology for R/S/Y/O/AG
InGaN technology for IG/IB
Z=C: Anode Row, Cathode column or A: Anode
Column, Cathode Row
XX= Color
Description:
These 1.2” 5x7 dot matrix displays are made with
white dots and a grey surface.
Application:
Instrument panels
Indoor/Outdoor display board
Audio equipment
Certification & Compliance:
TS16949
ISO9001
RoHS Compliant
Dimension:
Units: mm / tolerance = +/-0.25mm
Product: GMZ12XX75_series
Date: June 22, 2015
Version# 1.5
Page 3 of 13
GMZ12XX75_series
1.2” 5x7 Dot Matrix
---------------------------------------------------------------------------------------------------------------------------------------
Electrical / Optical Characteristic (Ta=25
o
C)
Product
Anode Row,
Anode
Material
Cathode
Column,
Column
Cathode Row
GMC12R75
GMA12R75 AllnGaP
GMC12S75
GMC12Y75
GMC12O75
GMA12S75
GMA12Y75
GMA12O75
AllnGaP
AllnGaP
Color
I
F
(mA)
Typ. Max. Min. Typ. Max.
Red
Yellow
Orange
Yellow
Green
True
Green
Blue
20
20
20
20
20
20
20
2.0
2.0
2.0
2.0
2.1
3.2
3.0
2.6
2.6
2.6
2.6
2.6
4.0
4.0
619
636
585
601
566
500
460
624 629
639 647
590 595
606 611
571 574
525 535
465 470
Typ.
60
35
130
60
25
200
160
V
F
(V)
λ
D
(nm)
I
V
(mcd)
AlInGaP Deep Red
GMC12AG75 GMA12AG75 AlInGaP
GMC12IG75
GMC12IB75
GMA12IG75
GMA12IB75
InGaN
InGaN
Absolute Maximum Rating
Material
AlInGaP
Derating liner from 25
o
C
P
d
(mW)
I
F
(mA) I
FP
(mA)* V
R
(V)
per dice (mA/
o
C)
70
0.33
0.4
25
30
90
100
5
5
T
OP
(
o
C)
T
ST
(
o
C)
-25 to +85 -25 to +85
-25 to +85 -25 to +85
InGaN
120
*Duty 1/10 @ 1KHz
Luminous Intensity I
V
for Red @ I
F
=20mA
Bin
P
Q
R
Min.
30
50
70
Max.
50
70
90
Unit
mcd
Luminous Intensity I
V
for Deep Red @ I
F
=20mA
Bin
F
G
H
Min.
10
30
50
Max.
30
50
70
Unit
mcd
Product: GMZ12XX75_series
Date: June 22, 2015
Version# 1.5
Page 4 of 13
GMZ12XX75_series
1.2” 5x7 Dot Matrix
---------------------------------------------------------------------------------------------------------------------------------------
Luminous Intensity I
V
for Yellow @ I
F
=20mA
Bin
J
K
L
Min.
100
130
150
Max.
130
150
170
Unit
mcd
Luminous Intensity I
V
for Orange @ I
F
=20mA
Bin
G
H
I
Min.
30
50
70
Max.
50
70
90
Unit
mcd
Luminous Intensity I
V
for Yellow Green @ I
F
=20mA
Bin
F
G
H
Min.
10
30
50
Max.
30
50
70
Unit
mcd
Luminous Intensity I
V
for True Green @ I
F
=20mA
Bin
M
N
Min.
160
200
Max.
200
350
Unit
mcd
Luminous Intensity I
V
for Blue @ I
F
=20mA
Bin
K
L
M
Min.
130
150
170
Max.
150
170
200
Unit
mcd
Dominant Wavelength λ
D
for Red @ I
F
=20mA
Bin
1
2
Min.
619
623
Max.
623
629
Unit
nm
Dominant Wavelength λ
D
for Deep Red @ I
F
=20mA
Bin
1
2
3
Min.
636
640
643
Max.
640
643
647
Unit
nm
Product: GMZ12XX75_series
Date: June 22, 2015
Version# 1.5
Page 5 of 13
