CONDUCTIVE PLASTIC RECTILINEAR TYPE
JCL·JCL B
series
Basic construction
Conductive plastic rectilinear type
RoHS compliant
■
FEATURES
10
~
500 mm
High resolution (Essentially infinite)
Long life
Mounting plate seating position can be set to any posi-
tions (JCL B)
RoHS compliant
■
PART NUMBER DESIGNATION
J C L 1 0 0 B
Series name
JCL10, JCL20, JCL50, JCL100B
JCL200B, JCL300B, JCL500B
1 k
0 . 5 %
Independent linearity
0.5 %
：
±0.5
%
Nominal resistance value
（Ω）
1 k, 2 k, 5 k, 10 k
■
LIST OF PART NUMBERS
Effective
electrical
travel
Item
Nominal
resistance value
1 kΩ
10 mm
2 kΩ
5 kΩ
1 kΩ
20 mm
2 kΩ
5 kΩ
10 kΩ
1 kΩ
50 mm
2 kΩ
5 kΩ
10 kΩ
Part number
JCL10 1 k 0.5 %
JCL10 2 k 0.5 %
JCL10 5 k 0.5 %
JCL20 1 k 0.5 %
JCL20 2 k 0.5 %
JCL20 5 k 0.5 %
JCL20 10 k 0.5 %
JCL50 1 k 0.5 %
JCL50 2 k 0.5 %
JCL50 5 k 0.5 %
JCL50 10 k 0.5 %
Effective
electrical
travel
Item
Nominal
resistance value
1 kΩ
Part number
JCL100B 1 k 0.5 %
JCL100B 2 k 0.5 %
JCL100B 5 k 0.5 %
JCL100B 10 k 0.5 %
JCL200B 1 k 0.5 %
JCL200B 2 k 0.5 %
JCL200B 5 k 0.5 %
JCL200B 10 k 0.5 %
JCL300B 2 k 0.5 %
JCL300B 5 k 0.5 %
JCL300B 10 k 0.5 %
JCL500B 5 k 0.5 %
JCL500B 10 k 0.5 %
100 mm
2 kΩ
5 kΩ
10 kΩ
1 kΩ
200 mm
2 kΩ
5 kΩ
10 kΩ
2 kΩ
300 mm
5 kΩ
10 kΩ
※
Verify the above part numbers when placing orders.
500 mm
5 kΩ
10 kΩ
POTENTIOMETERS
JCL/JCL B
■
STANDARD SPECIFICATIONS
Item
Resistance torelance
Resolution
Independent linearity
Effective electrical travel
Mechanical travel
Power rating (at 40 °C)
Dielectric strength
Insulation resistance
Operating force
Stop strength
%
mm
mm
W
Vrms
MΩ minimum
mN {gf} maximum
N·m {kgf·cm} minimum
mm/s
ppm/°C
°C
cycle
g
Approx. 23
20 million
Approx. 27
Approx. 38
147 {15}
0.196 {2}
500
±
400
−40
~ 85
10 million
6 million
4 million
0.13
0.25
10
+1
0
Part number
%
JCL
10
20
50
100B
±
20
Essentially infinite
±
0.5
20
+1
0
200B
300B
500B
50
+1
0
100
+2
0
200
+2
0
300
+3
0
500
+3
0
Minimum effective electrical travel
0.6
1.5
1000 1 min
1000 (at DC500 V)
1960 {200}
0.981 {10}
3
4
7
Maximum traveling speed
Temp. coefficient of resistance
Operating temp. range
Life
Net weight
Protection grade
Approx. 182 Approx. 272 Approx. 373 Approx. 555
IP40
■
RATED POWER DERATING CURVE
100
Power rating ratio (%)
– 40
+ 40
Ambient temperature (℃)
+ 85
JCL/JCL B
POTENTIOMETERS
■
OUTLINE DIMENSIONS
JCL10 ~ 50
D
5
15
Unless otherwise specified, tolerance:
±
0.5 (Unit: mm)
1
φ
3
M2
3
2
When shaft inserted
18
1
3
2
3.3
A
5 10
2
2
Wiring
diagram
7
13.4
JCL10 ~ 50
(3)
B
(C)
5
2-M2
(Use with depth under 3)
Part
number
Mark
A
45
55
85
B
37
47
77
(C)
60
70
100
D
18
28
58
JCL10
JCL20
JCL50
JCL100B ~ 500B
Mounting plate pitch
M4
φ
6
22
51
10
2
4.5
4-
φ
3.5
B (Variable)
A
(D)
Projection A
5
C (Variable)
10
24
13
1
3
5
Projection A
JCL100B ~ 500B
Part
number
Mark
A
159
259
369
569
B
50 ~ 129
100 ~ 229
150 ~ 339
250 ~ 539
C
17 ~ 96
17 ~ 146
17 ~ 206
17 ~ 306
(D)
178.5
278.5
388.5
588.5
JCL100B
JCL200B
JCL300B
JCL500B
B dimensions require minimum 1/2 of effective electrical length.
