40HFL Series
Super Fast Recovery Rectifier
V
RRM
= 150-1000V, I
F(AV)
= 40Amp,VF = 1.95V
Symbol
A
K
Cathode to Stud Shown
(Anode to Stud add Suffix R)
MAXIMUM RATINGS
Parameter
(Tj = 25 C unless stated otherwise)
40HFL
40HFL
40HFL
(R)10
(R)20
(R)40
S02/5/10 S02/5/10 S02/5/10
40HFL
40HFL
(R)60
(R)80
S02/5/10 S02/5/10
40HFL
(R)100
S05/10
Symbol
V
RRM
I
F
(AV)
I
FSM
I
2
T
T
(STG)
Tj
Unit
Volt
Amp
Amp
Repetitive Peak Reverse Voltage
Maximum Average On-State Current
Peak Forward Surge Current 8.3mS
Maximum I
2
T for Fusing 8.3ms
Maximum Storage Temperature Range
Maximum Junction Temperature Range
100
200
400
40.0
420
730
600
800
1000
A
2
/S
O
-40 to +125
-40 to +150
C
C
O
ELECTRICAL CHARACTERISICS at
Parameter
Tj = 25 C Maximum. Unless stated Otherwise
Condition
Symbol
V
FM(1)
I
DRM
t
RR
t
RR
t
RR
R
TH (J-c)
M
T
Wt
Min
I
FM
=40 Amps
Value
Typ
Max
1.95
100
70
180
350
0.60
2.5
25
Unit
Volt
µA
nS
nS
nS
O
Maximum Forward Voltage (1)
Repetitive Peak Off- State Current
Reverse Recovery Time SO2
Reverse Recovery Time SO5
Reverse Recovery Time SO10
Thermal Resistance (Junction to Case)
Mounting Torque
Weight
V
R
= V
RRM
C/W
NM
grms
Mechanical Outline
0.90
(0.03)
17.25
(0.68)
0 4.0 (0.16) Min
7.0 (0.27) max
6.1 (0.84) min
10.20 (0.401) min
11.4 (0.45) max
14.86 (0.585) Max
12.80 (0.0.503) Min
C
L
4.0 (0.16) min
25.4 (1.00) max
10.6 (0.42) min
11.4 (0.46) max
1/4" 28 UNF - 2A
Metric M6 x 1
Case: DO-203AB (DO-5)
Case: Metal/ Glass to Metal Seal
All Dimensions in Millimeters (Inches)
