LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
SXC
SXC
SERIES
105℃, Overvoltage Vent Operation Facility,
Snap-in Terminal Type
◆FEATURES
•
Load Life : 105℃ 2000 hours.
•
RoHS compliance.
•
This series has specification of vent operation in overvoltage situation. Please consult
us for any further details.
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
I＝3
CV
Leakage Current(MAX)
Characteristics
−25∼＋105℃
200V.DC, 400V.DC
±20％（20℃，120Hz）
(After 5 minutes application of rated voltage)
I＝
Leakage Current
(μA) V＝
Rated Voltage
(V) C＝
Rated Capacitance
(μF)
Dissipation Factor(MAX)
(tanδ)
Impedance Ratio(MAX)
Rated Voltage
(V)
Z
（−25℃）（20℃）
/Z
200
3
400
8
0.15（20℃，120Hz）
（120Hz）
After applying rated voltage with rated ripple current for 2000hrs at 105℃, the capacitors shall meet the following requirements.
Capacitance Change
Dissipation Factor
Leakage Current
Within ±20％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
Endurance
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Frequency
Hz）
（
Coefficient
200WV
400WV
60 50） 120
（
0.80 1.00
0.80 1.00
500
1.10
1.05
1k 10k≦
1.14 1.18
1.10 1.15
◆PART NUMBER
□□□
Rated Voltage
SXC
Series
□□□□□
Rated Capacitance
□
Capacitance Tolerance
OOE
Option
SN
Terminal Code
D×L
Case Size
◆Option
Code
without plate
with plate
◆DIMENSIONS
●
SN
［4(3.5)mm½terminal type
（mm）
OOE
Blank
VENT
SLEEVE
2-φ2
NEGATIVE
10
10
±0.1
L±2
※
4±0.5
※For φ35, 3.5±0.5
φD±1
φD±1
MOUNTING HOLES
LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
SXC
◆STANDARD SIZE, RATED RIPPLE CURRENT
Cap(μF)
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
WV
φD
200
φ20
20×20
20×20
20×20
20×25
20×25
20×30
20×35
20×40
φ22
0.42
0.47
0.52
0.69
0.75
0.87
1.00
1.20
22×20
22×20
22×25
22×25
22×25
22×25
22×30
22×35
22×40
22×45
0.51
0.56
0.69
0.75
0.88
0.99
1.20
1.30
1.44
1.60
φ25
φ30
φ35
25×20
25×20
25×25
25×25
25×25
25×30
25×30
25×35
25×40
0.63
0.70
0.88
0.99
1.20
1.34
1.44
1.60
1.76
30×20
30×20
30×20
30×25
0.85
0.95
1.05
1.20
30×25
30×25
30×30
30×30
30×35
30×45
1.30
1.48
1.60
1.74
2.11
2.40
35×20
35×20
35×25
35×25
35×25
35×30
35×30
35×35
35×35
35×40
1.08
1.15
1.48
1.58
1.74
2.10
2.30
2.30
2.65
2.65
35×45
WV
φD
400
φ20
20×20
20×20
20×20
20×25
20×25
20×30
20×35
20×40
φ22
0.20
0.22
0.25
0.35
0.39
0.44
0.51
0.57
22×20
22×20
22×20
22×25
22×25
22×25
22×30
22×35
22×40
22×45
0.23
0.25
0.28
0.39
0.45
0.49
0.56
0.62
0.73
0.85
φ25
φ30
φ35
3.08
Cap(μF)
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
25×20
25×20
25×20
25×25
0.30
0.34
0.39
0.45
25×25
25×25
25×30
25×30
25×35
25×40
25×45
0.49
0.56
0.61
0.73
0.85
0.94
1.07
30×20
30×20
30×20
30×25
0.41
0.45
0.50
0.56
30×25
30×25
30×30
30×30
30×35
30×35
30×40
0.59
0.73
0.79
0.95
1.24
1.35
1.30
30×45
1.47
35×20
35×20
35×20
35×25
35×25
35×30
35×35
35×35
35×40
35×45
0.51
0.54
0.61
0.78
0.95
1.24
1.28
1.41
1.59
1.87
Ripple Current (A r.m.s./120Hz, 105℃)
Case Size φD×L(mm)
