High Reliability Photologic®
Hermetic Sensors
OPL800TX, OPL800TXV
Features:
100% screened and quality conformance tested to Optek’s High
Reliability program
Direct TTL/STTL interface
Hermetic, lensed TO-18 package
Mechanically and spectrally matched to OP235/OP236TX/TXV LEDs
Description:
The OPL800TX/TXV is a high reliability optoelectronic microcircuit that incorporates a photodiode, linear amplifier and
Schmi
trigger on a single silicon chip. The device features TTL/STTL compa
ble logic level output which can drive up to 8
TTL loads without addi onal interface circuitry. The Photologic
®
chip is mounted on a standard TO‐18 header with gold
plated leads which is herme cally sealed in a lensed gold plated metal can. These devices are mechanically and spectrally
matched to the OP235TX/TXV and OP236TX/TXV infrared emi ng diodes. All parts are processed to Optek’s 100 percent
screening program pa erned a er Method 5004 of MIL‐STD‐883 and the quality conformance tes ng of Method 5005.
Typical characteris c curves are shown on the commercial OPL800 datasheet.
Applications:
Non-contact reflective object sensor
Assembly line automation
Machine automation
Machine Safety
End of travel sensor
Door sensor
Military and harsh environments
(2)
(1)
(3)
Absolute Maximum Ra ngs
(T
A
= 25° C unless otherwise noted)
Supply Voltage, V
CC
(not to exceed 3 sec)
Storage Temperature Range
Opera ng Temperature Range
Lead Soldering Temperature [1/16 inch (1.6 mm) from case for 5 sec. with soldering iron]
Power Dissipa on
Dura on of Output Short to V
CC
or Ground
Irradiance
Notes:
1. RMA flux is recommended. Dura on can be extended to 10 seconds maximum when wave soldering.
2. Derate linearly 2.5 mW/°C above 25°C.
3. Light measurements are made with λ = 935 nm.
General Note
TT Electronics reserves the right to make changes in product specification without
notice or liability. All information is subject to TT Electronics’ own data and is
considered accurate at time of going to print.
© TT electronics plc
+10.0 V
‐55° C to +150°C
‐55° C to +125°C
240°C
(1)
250 mW
(2)
1.00 sec
3 mW/cm
2
OPTEK Technology, Inc.
1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200
www.optekinc.com | www.ttelectronics.com
Issue A
11/2016 Page 1
High Reliability Photologic®
Hermetic Sensors
OPL800TX, OPL800TXV
Group A Inspec on‐Electrical Tests
(Performed on each inspec on lot a er all devices have been subjected to the 100% processing requirements.)
SYMBOL
Subgroup 1
(3)
I
CCH
I
CCL
V
OL
V
OH
I
OS
Supply Current, High
Supply Current, Low
Low Level Output Voltage
High Level Output Voltage
Short Circuit Output Current
3005
3005
3007
3006
3011
V
CC
= 5.5 V, E
e
= 1.0 mw/cm
2
V
CC
= 5.5 V, E
e
= 0.0 mw/cm
2
V
CC
= 4.5 V, I
OL
= 12.8 mA,
E
e
= 0.0 mw/cm
2
V
CC
= 4.5 V, I
OH
= ‐800 μA, E
e
=
1.0 mw/cm
2
V
CC
= 4.5 V, E
e
= 1.0 mw/cm
2,
Output =
Ground
116/0
2.4
‐20
‐100
V
mA
15.0
15.0
0.40
mA
mA
V
EXAMINATION OR TEST
METHOD
CONDITIONS
N/C
LIMIT
MIN
MAX
UNITS
Subgroup 2
(3)
TA = +125
°C
I
CCH
I
CCL
V
OL
V
OH
Supply Current, High
Supply Current, Low
Low Level Output Voltage
High Level Output Voltage
3005
3005
3007
3006
V
CC
= 5.5 V, E
e
= 1.0 mw/cm
2
V
CC
= 5.5 V, E
e
= 0.0 mw/cm
2
V
CC
= 4.5 V, I
OL
= 12.8 mA,
V
CC
= 4.5 V, I
OH
= ‐800 μA, E
e
=
116/0
2.4
15.0
15.0
0.40
mA
mA
V
V
Subgroup 3
(3)
TA =
‐55
°C
I
CCH
I
CCL
V
OL
V
OH
Supply Current, High
Supply Current, Low
Low Level Output Voltage
High Level Output Voltage
3005
3005
3007
3006
V
CC
= 5.5 V, E
e
= 1.0 mw/cm
2
V
CC
= 5.5 V, E
e
= 0.0 mw/cm
2
V
CC
= 4.5 V, I
OL
= 12.8 mA,
E
e
= 0.0 mw/cm
2
V
CC
= 4.5 V, I
OH
= ‐800 μA, E
e
=
1.0 mw/cm
2
116/0
2.4
0.40
V
V
15.0
15.0
mA
mA
Subgroup 3
(3)
t
r
, t
f
t
PHL
t
PLH
Rise and Fall Time
Propaga on Delay, Low‐High
Propaga on Delay, High‐Low
3004
3003
3003
V
CC
= 5.0 V, R
L
= 8TTL loads
V
CC
= 5.0 V, R
L
= 8TTL loads
V
CC
= 5.0 V, R
L
= 8TTL loads
116/0
100
10.0
10.0
ns
μs
μs
General Note
TT Electronics reserves the right to make changes in product specification without
notice or liability. All information is subject to TT Electronics’ own data and is
considered accurate at time of going to print.
© TT electronics plc
OPTEK Technology, Inc.
1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200
www.optekinc.com | www.ttelectronics.com
Issue A
11/2016
Page 2
