EQM08-4KC-F5AS103-00
( 1/6 )
1.Scope
This specification shall cover the characteristics of the shock sensor.
Preliminary
2.Kyocera’s Type Name
PSCE242K-R090C
3.Customer’s Type Name
4.Electrical Characteristics
Items
4-1 Primary Axis Inclined Angle
4-2 Capacitance
4-3 Charge Sensitivity
4-4 Insulation Resistance
4-5 Resonant Frequency
4-6 Non-linearity
(Reference only)
Voltage Sensitivity
Specifications
25
±
3degree
315pF
±
30%, at 1Vrms, 1kHz
0.055pC/G
±
40 %, under vibration at 200Hz, 2G
0.5Gohm minimum, at 10VDC(charging time 200msec)
90.0 kHz
±20%
5% maximum, under vibration at 25G
0.175 mV/G, under vibration at 200Hz, 2G
<Measurement Condition>
The reference temperature shall be 25℃ ± 5℃.
5.Dimensions and Marking
2.4±0.20
Marking of Polarity
Body
Lime
; Black Colour
; Brown Colour
Characteristic Spec
2
; Initial Primary Axis Inclined Angle
K
; Electrical Characteristics
2K
2.0±0.20
Manufacturing Day Cade ;
Day
Cade
1
A
11
L
21
W
2
B
12
M
22
X
3
C
13
N
23
Y
4
D
14
P
24
Z
5
E
15
Q
25
a
6
F
16
R
26
b
7
G
17
S
27
c
8
H
18
T
28
d
9
J
19
U
29
e
10
K
20
V
30
f
31
g
0.40 ( typ.)
Day
Cade
1.20±0.10
Day
Cade
Electrode
Unit ; mm
EIAJ Date Code ;
2009 Jan.
½
Dec. :
2010 Jan.
½
Dec. :
2011 Jan.
½
Dec. :
2012 Jan.
½
Dec. :
A
N
a
n
½
½
½
½
M
Z
m
z
except
except
except
except
"I"
"O"
"i"
"o"
Fig.1
0.40±0.15
Note : These alphabets should be repeated after Jan. 2013
KYOCERA CORPORATION
EQM08-4KC-F5AS103-00
( 2/6 )
6.Environmental Characteristics
Items
6-1.High Temperature
Storage Test
Preliminary
Conditions
Keep in a chamber at 85
±2°C
for 1000 +12/-0 hours, and then keep at room
temperature for 1 hour. The characteristics of shock sensor shall meet the
specifications.
6-2.Low Temperature
Storage Test
Keep in a chamber at –40
±2°C
for 1000 +12/-0 hours, and then keep at
room temperature for 1 hour. The characteristics of shock sensor shall meet
the specifications.
6-3.Moisture
Resistance Test
Keep in a chamber at 90 to 95 % R.H. and 60
±
2°C for 500 +12/-0 hours,
and then keep at room temperature for 1 hour. The characteristics of shock
sensor shall meet the specifications.
6-4.Temperature
Cycling Test
Apply 100 thermal cycles with the following temperatures:
-
-
-
upper temperature 85°C for 20 minutes and transfer time 10 minutes
lower temperature -40°C for 20 minutes and transfer time 10 minutes
total cycle time is 1hour
and then left at room temperature for 1 hour. The characteristics of shock
sensor shall meet the specifications.
6-5.Mechanical Shock
Test
After applying the acceleration at 29430m/sec
2
{3000G} in each of X, Y and
Z axis (each 3 times). The characteristics of shock sensor shall meet the
specifications.
6-6.Solderability Test
At first, being soaked in the Methanol solution containing Rosin for 5
seconds and then being dipped in a bath of Pb/Sn solder at 250
±
5°C for 4
±
0.5 seconds. The surface of the electrode terminal shall be soldered more
than 95%.
6-7.Resistance to
Soldering Heat Test
Pre-heat temperature is 150 to 180°C for 1 minute. High temperature is 250
±
5°C, over 200°C for 20 seconds max.(2times). Then keep at room
temperature for 1 hour. The characteristics of shock sensor shall meet the
specifications.
6-8.Board Flex Test
After soldered on the circuit board specified as below, then the load which
cause 3 mm bend to the board is applied. The characteristics of shock
sensor shall meet the specifications. The shock sensor cause no defect in
the appearance. (Circuit Board: FR4, 100 x
50
20
40 x 1.6 )
F
R230
3.0mm
45
45
1.0
<Measurement Condition>
The reference temperature shall be 25°C±5°C.
KYOCERA CORPORATION
