Fuse Blocks and Clips
For 3AG Fuses
RoHS
Pb
3AG OMNI-BLOK
® Molded Base Type Fuse Block
®
®
A low profile fuse block featuring individual barriers which reinforce
the fuse clips while providing greater protection against clip damage
and electrical shock. The unique design permits self-alignment of clips
to fuse cap. This, plus a one-piece clip/terminal assures low contact
resistance. Higher current ratings have been attained using spring brass
clips. With the exception of the two-pole unit, multiple pole units may be
broken apart to obtain desired number of poles.
APPROVALS:
Recognized under the Components Program of
Underwriters Laboratories and Certified by CSA up to 300V and at
current ratings shown below.
Current Rating
U.L.
30A
20A
20A
30A
15A
Series
354
000
354
600
354
800
354
900
354
101-GY
CSA
30A
20A
20A
25A
15A
.312" REF. DIA. C BORE
.06" REF. DEEP (.10 REMAINS)
XX
SPECIFICATIONS:
Dielectric Strength:
1500V., Minimum.
Clip/Terminals:
Tin-Plated Spring Brass.
Base:
Glass reinforced Thermoplastic. (Gray except Anti-Rotation series
which is Black). UL 94V0 flammability rating.
Ambient Temperature:
– 40°C to +85°C.
P.C. Board Type
(Single pole units only)
.53" REF.
XX
.146" REF.
DIA. THRU
XX
1.46"
REF.
1.4"
.06" DIA. (2)
ELECTRICAL SPECIFICATIONS:
Series or
Catalog Number
354
000
354
600
354
800
354
900
354
101-GY
Terminals
Solder
3
/
16
" Q.C.
1
/
4
" Q.C.
1
/
4
" QC.
P.C. Board
Rating
30A, 300V*
20A, 300V
20A, 300V
30A, 300V
15A, 300V
A
.625"
TYP.
XX
Anti-Rotation Boss
(Single pole units only)
.08" REF.
45° .55" MAX.
.08" REF. DIA.
.156" DIA.
.65"
1.4"
2.19" REF.
.25"
TYP.
.10" DIA.
* 30 amp capability is based on temperature rise with #10 AWG wire properly soldered.
OPTION:
Two different style clips can be supplied for circuit identity or
polarization. Contact factory.
PATENTED
ORDERING INFORMATION:
Catalog Number
NEMA Style
3
1
/
16
" Q.C.
/
4
" Q.C.
Terminals
Terminals
354
601-GY
354
801-GY
354
602-GY
354
802-GY
354
603-GY
354
803-GY
354
604-GY
354
804 GY
354
605-GY
354
805-GY
354
606-GY
354
806-GY
354
607-GY
354
807-GY
354
608-GY
354
808-GY
354
609-GY
354
809-GY
354-610-GY
354
810-GY
354
611-GY
354
811-GY
354
612-GY
354
812-GY
354
821-BL*
354
621-BL*
—
—
NEMA Style
1
/
4
" Q.C.
Terminals
354
901-GY
354
902-GY
354
903-GY
354
904-GY
354
905-GY
354
906-GY
354
907-GY
354
908-GY
354
909-GY
354
910-GY
354
911-GY
354
912-GY
354
921-BL*
—
Number
of
Poles
1
2
3
4
5
6
7
8
9
10
11
12
1
1
Reference
Dimension
“A”
.50"
1.12"
1.75"
2.38"
3.00"
3.63"
4.25"
4.88"
5.50"
6.13"
6.75"
7.38"
.50"
.50"
Solder Type
Terminals
354
001-GY
354
002-GY
354
003-GY
354
004 GY
354
005-GY
354
006-GY
354
007-GY
354
008-GY
354
009-GY
354
010-GY
354
011-GY
354
012-GY
354
021-BL*
354
101-GY
*With Anti-Rotation Boss
486
w w w. l i t t e l f u s e . c o m
