Radial Lead Power Chokes
NU
MB
ER
Series 3443
SERIES 3443 FERRITE CORE
3443-00K
3443-04K
3443-08K
3443-12K
3443-16K
3443-20K
3443-24K
3443-28K
3443-32K
3443-36K
3443-40K
3443-44K
3443-48K
3443-50K
3443-52K
3443-56K
3443-58K
3443-60K
3443-64K
3443-68K
3443-72K
3443-76K
3443-80K
3443-84K
3443-88K
3443-92K
3443-94K
3443-98K
1.0
1.5
2.2
3.3
4.7
6.8
10.0
15.0
22.0
33.0
47.0
68.0
100.0
120.0
150.0
220.0
270.0
330.0
470.0
680.0
1000.0
1500.0
2200.0
3300.0
4700.0
6800.0
10000.0
15000.0
0.005
0.006
0.007
0.008
0.009
0.010
0.015
0.022
0.033
0.052
0.078
0.092
0.140
0.175
0.210
0.330
0.420
0.510
0.610
0.910
1.40
2.20
3.30
5.10
7.70
11.7
14.2
21.9
17.8
16.2
15.0
14.0
13.0
12.5
10.0
8.5
6.5
5.5
4.5
4.0
3.3
3.0
2.7
2.2
1.95
1.70
1.60
1.30
1.00
0.84
0.69
0.55
0.45
0.36
0.33
0.26
17.8
16.2
15.0
12.4
10.3
8.9
7.3
5.9
4.9
4.0
3.3
2.8
2.3
2.1
1.9
1.5
1.35
1.20
1.00
0.90
0.73
0.60
0.49
0.40
0.34
0.28
0.23
0.19
IN
D
(µ UCT
H) A
±1 NC
0% E
@
DC
MA RES
XI IST
MU A
M NC
(O E
HM
S)
CU
R
MA RE
XI NT
MU R
M ATI
(A NG
m
ps
IN
)
CR
CU EM
RR EN
EN TA
T L
DC
(A
m
ps
)
1K
Hz
POWER INDUCTORS
Physical Parameters
Inches
A
0.500 ± 0.015
B
0.600 Max.
C
0.375 Min.
D
0.870 Max.
E
0.515 Max.
F*
0.040 ± 0.005
G
0.030 Min.
*F= AWG #18 TCW
Millimeters
12.72 ± 0.38
15.27 Max.
9.54 Min.
22.14 Max.
13.10 Max.
1.02 ± 0.13
0.76 Min.
RATED CURRENT vs. TEMPERATURE
100
% OF RATED CURRENT
Current Rating
Based on continuous operation
at room temperature. Derating is required at elevated
ambient temperatures in accordance with the derat-
ing curve.
Operating Temperature Range
–55°C to +125°C
Maximum Power Dissipation at 25°C
2.2 W
Weight Max.
(Grams) 12.0
Incremental Current 1)
Current Level which causes
a maximum of 10% decrease in inductance.
2)
The
Incremental Current at ambient temperatures other
than 25°C will be 70% of the adjusted current rating.
Core Material
Ferrite
Packaging
Bulk only
Made In the U.S.A.
