6.8×4.7 Circularity/ Single Turn /Trimming Potentiometer
-- 3329H--
...Install
dimension............................
Electrical Characteristics
Standard Resistance Range.................50Ω
½
2MΩ
Resistance Tolerance...................................±10%
Absolute Minimum Resistance..........
≤
1%R
或
10Ω
...Mutual
dimension............................
Contact Resistance Variation................CRV
≤
3%
Insulation Resistance...............R1
≥
1GΩ
(100Vac)
Withstand Voltage......................................500Vac
Effective Travel...............................................280°
Environmental Characteristics
Power Rating, 300 volts max
......................................0.25W@70℃,0W@125℃
Temperature Range.........................-55℃
½
125℃
Standard Resistance Table
Resistance(Ohms)
Resistance Code
Temperature Coefficient.....................±250ppm/℃
Temperature Variation...........-55℃,30min,+125℃
........................................................30min 5cycles
...............................△R
≤
5%R,△(Uab/Uac)
≤
5%
Vibration............................10
½
500Hz,0.75mm,6h
........................△R
≤
5%R,
△(Uab/Uac)
≤
7.5%R
Collision..............390m/s
2
,4000cycles,
△
R
≤
5%R
Electrical Endurance at 70℃..............0.5W@70℃
....................1000h,
△R
≤
10%R,CRV
≤
3% or 5Ω
Rotational Life........................................200cycles
...............................△R
≤
10%R,CRV
≤
3% or 5Ω
How To Order
3329-----H-------103
10
20
50
100
200
500
1,000
2,000
5,000
10,000
20,000
25,000
50,000
100,000
200,000
250,000
500,000
1,000,000
2,000,000
100
200
500
101
201
501
102
202
502
103
203
253
503
104
204
254
504
105
205
