PEF 220
www.vishay.com
Vishay Draloric
RF Power Plate Capacitors for Higher Voltages,
Class 1 Ceramic
FEATURES
• Low losses
• High reliability
• High voltage ratings
APPLICATIONS
These high quality power plate capacitors are designed for
usage in high frequency heating, welding equipment, and
working environments with effects of moisture, dust and
other impurities where high voltage ratings are required.
QUICK REFERENCE DATA
DESCRIPTION
Ceramic Class
Ceramic Dielectric
Type
Voltage (V
p
)
Min. Capacitance (pF)
Max. Capacitance (pF)
Mounting
VALUE
1
R7, R16, R42, R85, R230
PEF 220
15 000
16 000
7000
250
8000
1200
Screw terminal
12 000
400
6000
13 000
4000
10 000
14 000
300
1600
17 000
3000
3000
18 000
500
500
20 000
160
6000
MATERIAL
Capacitor elements made from class 1 ceramic dielectric
with noble metal electrodes.
Flexible connection terminals copper / brass, silver plated,
to allow for series and parallel interconnection.
RATED VOLTAGE
•
•
•
•
•
•
•
•
12 kV
p
13 kV
p
14 kV
p
15 kV
p
16 kV
p
17 kV
p
18 kV
p
20 kV
p
MARKING
Type designator, capacitance value and tolerance, rated RF
voltage, production date code, ceramic material code,
manufacturer logo.
FINISH
Noble metal electrodes and terminals are protective
lacquered.
The PEF 220 type features an insulating rim made from
silicone elastomer to minimize the adverse effects of
moisture, dust, and other impurities in the working
environment and to improve the characteristics of the
electrical field.
DIELECTRIC STRENGTH TEST
200 % of rated voltage, 50 Hz
DISSIPATION FACTOR
R7:
max. 0.07 %
R16:
max. 0.04 %
R42, R85, R230:
max. 0.05 %
Measuring frequencies:
1 MHz (< 1 nF); 300 kHz or 100 kHz ( 1 nF)
CAPACITANCE RANGE
160 pF to 10 nF
CAPACITANCE TOLERANCE
± 20 %, ± 10 %
INSULATION RESISTANCE
Min. 100 000 M (at 25 °C)
CERAMIC DIELECTRIC
•
•
•
•
•
R7 (TCC + 100 ppm/K)
R16 (TCC + 100 ppm/K)
R42 (TCC - 250 ppm/K)
R85 (TCC - 750 ppm/K)
R230 (TCC - 750 ppm/K)
OPERATING TEMPERATURE RANGE
-55 °C to +100 °C
Revision: 29-Feb-16
Document Number: 22083
1
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PEF 220
www.vishay.com
Vishay Draloric
CAP.
VALUE
(pF)
160
200
RATED
VOLTAGE
(kV
p
)
20
16
14
12
18
16
20
16
14
60
20
140
100
125
140
60
140
60
110
60
RATED
POWER
(1)
(kvar)
RATED
CURRENT
(A
RMS
)
SAP PART NUMBER AND ELECTRICAL DATA
PART NUMBER
PEF220WP161##BF1
PEF220WP201##BF1
PEF220WL251##BF1
PEF220WJ301##BF1
PEF220WF401##BF1
PEF220WN501##BG1
PEF220WL601##BG1
PEF220WP801##BH1
PEF220WP102##BH1
PEF220WL122##BH1
PEF220WJ162##BH1
PEF220WP202##BJ1
PEF220WP252##BJ1
PEF220WP252##BJ3
PEF220WP252##BJ2
PEF220WM302##BJ1
PEF220WH402##BJ1
PEF220WH502##BJ1
PEF220WF602##BJ1
PEF220WP602##BK1
PEF220BJ702##BK1
PEF220BJ802##BK1
PEF220WH103##BK1
R 230
R85
R 42
R 16
R7
CERAMIC
250
300
400
500
600
800
1000
1200
1600
2000
2500
2500
2500
3000
4000
5000
6000
6000
7000
8000
10 000
17
13
12
20
15
13
60
60
140
100
Notes
• ## 14
th
to 15
th
digit: capacitance tolerance code ± 20 % = 38, ± 10 % = 36
(1)
The surface temperature during operation must not exceed +100 °C
DIMENSIONS
in millimeters (inches)
8-finger terminals used on types
PEF220WP252##BJ2; PEF220WP252##BJ3;
PEF220BJ702##BK1; PEF220BJ802##BK1;
PEF220WH103##BK1
45 ± 1
(1.77 ± 0.04)
Insulating rim made
from
silicone
elastomer
43 max.
(1.69 max.)
Ø 225 max.
8.85 Dia. max.
SW
27
(1.06 HEX)
M 10 Thread
Revision: 29-Feb-16
Document Number: 22083
2
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
