VS-MBRB4045CTHM3, VS-MBR4045CT-1HM3
www.vishay.com
Vishay Semiconductors
Schottky Rectifier, 2 x 20 A
VS-MBRB4045CTHM3
VS-MBR4045CT-1HM3
FEATURES
• 150 °C T
J
operation
• Low forward voltage drop
• High frequency operation
• High purity, high temperature epoxy
encapsulation for enhanced mechanical
strength and moisture resistance
• Guard ring for enhanced ruggedness and long
term reliability
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
Base
common
cathode
2
Base
common
cathode
2
2
1 Common
3
Anode cathode Anode
2
1 Common
3
Anode cathode Anode
• AEC-Q101 qualified, meets JESD 201 class 1A whisker
test
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
D
2
PAK
TO-262
PRODUCT SUMMARY
Package
I
F(AV)
V
R
V
F
at I
F
I
RM
max.
T
J
max.
Diode variation
E
AS
TO-263AB (D
2
PAK), TO-262AA
2 x 20 A
45 V
0.58 V
95 mA at 125 °C
150 °C
Common cathode
20 mJ
DESCRIPTION
The center tap Schottky rectifier has been optimized for low
reverse leakage at high temperature. The proprietary barrier
technology allows for reliable operation up to 150 °C
junction temperature. Typical applications are in switching
power supplies, converters, freewheeling diodes, and
reverse battery protection.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
I
FRM
V
RRM
I
FSM
V
F
T
J
t
p
= 5 μs sine
20 A
pk
, T
J
= 125 °C
Range
CHARACTERISTICS
Rectangular waveform (per device)
T
C
= 117 °C (per leg)
VALUES
40
40
45
900
0.58
-65 to 150
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
Maximum working peak reverse voltage
SYMBOL
V
R
V
RWM
VS-MBRB4045CTHM3
VS-MBR4045CT-1HM3
45
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
per leg
per device
Peak repetitive forward current per leg
Maximum peak one cycle non-repetitive
peak surge current per leg
Non-repetitive avalanche energy per leg
Repetitive avalanche current per leg
Revision: 06-Mar-14
Maximum average
forward current
SYMBOL
I
F(AV)
I
FRM
I
FSM
E
AS
I
AR
TEST CONDITIONS
T
C
= 118 °C, rated V
R
Rated V
R
, square wave, 20 kHz, T
C
= 117 °C
5 μs sine or 3 μs rect. pulse
Following any rated
load condition and with
10 ms sine or 6 ms rect. pulse rated V
RRM
applied
T
J
= 25 °C, I
AS
= 3 A, L = 4.4 mH
Current decaying linearly to zero in 1 μs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
VALUES
20
40
40
900
210
20
3
mJ
A
UNITS
A
Document Number: 94721
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-MBRB4045CTHM3, VS-MBR4045CT-1HM3
www.vishay.com
Vishay Semiconductors
ELECTRICAL SPECIFICATIONS
PARAMETER
SYMBOL
20 A
Maximum forward voltage drop
V
FM (1)
40 A
20 A
40 A
Maximum instantaneous
reverse current
Maximum junction capacitance
Typical series inductance
Maximum voltage rate of change
Note
(1)
Pulse width < 300 μs, duty cycle < 2 %
T
J
= 25 °C
I
RM (1)
C
T
L
S
dV/dt
T
J
= 100 °C
T
J
= 125 °C
V
R
= 5 V
DC
(test signal range 100 kHz to 1 MHz), 25 °C
Measured from top of terminal to mounting plane
Rated V
R
Rated DC voltage
TEST CONDITIONS
T
J
= 25 °C
T
J
= 125 °C
VALUES
0.60
0.80
0.58
0.80
1
50
95
900
8.0
10 000
pF
nH
V/μs
mA
V
UNITS
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER
Maximum junction temperature range
Maximum storage temperature range
Maximum thermal resistance,
junction to case per leg
Typical thermal resistance,
case to heatsink
Maximum thermal resistance,
junction to ambient
Approximate weight
minimum
maximum
SYMBOL
T
J
T
Stg
R
thJC
R
thCS
R
thJA
DC operation
Mounting surface, smooth and greased
(Only for TO-220)
DC operation
(For D
2
PAK and TO-262)
TEST CONDITIONS
VALUES
-65 to 150
-65 to 175
1.5
0.50
50
2
0.07
Non-lubricated threads
Case style D
2
PAK
Case style TO-262
6 (5)
12 (10)
g
oz.
kgf · cm
(lbf · in)
°C/W
UNITS
°C
Mounting torque
Marking device
MBRB4045CTH
MBR4045CT-1H
Revision: 06-Mar-14
Document Number: 94721
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-MBRB4045CTHM3, VS-MBR4045CT-1HM3
www.vishay.com
Vishay Semiconductors
1000
I
F
- Instantaneous Forward Current (A)
1000
I
R
- Reverse Current (mA)
T
J
= 175 °C
100
100
10
1
0.1
0.01
0.001
T
J
= 150 °C
T
J
= 125 °C
T
J
= 100 °C
T
J
= 75 °C
T
J
= 50 °C
T
J
= 25 °C
10
T
J
= 125 °C
T
J
= 25 °C
1
0
0.5
1.0
1.5
2.0
2.5
0
5
10
15
20
25
30
35
40
45
V
F
- Forward Voltage Drop (V)
Fig. 1 - Maximum Forward Voltage Drop Characteristics
(Per Leg)
900
V
R
- Reverse Voltage (V)
Fig. 2 - Typical Values of Reverse Current vs.
Reverse Voltage (Per Leg)
C
T
- Junction Capacitance (pF)
800
700
600
500
400
300
200
T
J
= 25 °C
0
10
20
30
40
50
V
R
- Reverse Voltage (V)
Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage (Per Leg)
Z
thJC
- Thermal Impedance (°C/W)
10
1
P
DM
0.1
Single pulse
(thermal resistance)
D = 0.75
D = 0.50
D = 0.33
D = 0.25
D = 0.20
t
1
t
2
0.01
Notes:
1. Duty factor D = t
1
/t
2
2. Peak T
J
= P
DM
x Z
thJC
+ T
C
0.001
0.00001
0.0001
0.001
0.01
0.1
1
10
t
1
- Rectangular Pulse Duration (s)
Fig. 4 - Maximum Thermal Impedance Z
thJC
Characteristics (Per Leg)
Revision: 06-Mar-14
Document Number: 94721
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-MBRB4045CTHM3, VS-MBR4045CT-1HM3
www.vishay.com
160
20
RMS limit
Vishay Semiconductors
Allowable Case Temperature (°C)
150
Average Power Loss (W)
140
130
120
110
100
90
See
note
(1)
80
0
5
10
15
Square
wave (D = 0.50)
80 % rated V
R
applied
DC
15
10
5
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
DC
0
20
25
30
0
5
10
15
20
25
30
I
F(AV)
- Average Forward Current (A)
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current
I
F(AV)
- Average Forward Current (A)
Fig. 6 - Forward Power Loss Characteristics
I
FSM
- Non-Repetitive Surge Current (A)
1000
At any rated load condition
and with rated V
RRM
applied
following surge
100
10
100
1000
10 000
t
p
- Square Wave Pulse Duration (µs)
Fig. 7 - Maximum Non-Repetitive Surge Current (Per Leg)
Note
(1)
Formula used: T = T - (Pd + Pd
C
J
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= Rated V
R
Revision: 06-Mar-14
Document Number: 94721
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VS-MBRB4045CTHM3, VS-MBR4045CT-1HM3
www.vishay.com
ORDERING INFORMATION TABLE
Vishay Semiconductors
Device code
VS- MBR
1
1
2
3
4
5
6
7
8
-
-
-
-
-
-
-
-
2
B
3
40
4
45
5
CT
6
-1
7
RL
8
H
9
M3
10
Vishay Semiconductors product
Essential part number
B = D
2
PAK
None = TO-262
7
None
7
= -1
Current rating (40 = 40 A)
Voltage rating (45 = 45 V)
CT = Essential part number
None = D
2
PAK
-1 = TO-262
None = Tube
L = Tape and reel (left oriented - for D
2
PAK only)
R = Tape and reel (right oriented - for D
2
PAK only)
H = AEC-Q101 qualified
Environmental digit:
M3 = Halogen-free, RoHS-compliant and termination lead (Pb)-free
3
3
=B
None
9
10
-
-
ORDERING INFORMATION
(Example)
PREFERRED P/N
VS-MBRB4045CTHM3
VS-MBR4045CT-1HM3
VS-MBRB4045CTLHM3
VS-MBRB4045CTRHM3
QUANTITY PER T/R
50
50
800
800
MINIMUM ORDER QUANTITY
1000
1000
800
800
PACKAGING DESCRIPTION
Antistatic plastic tube
Antistatic plastic tube
13" diameter reel
13" diameter reel
LINKS TO RELATED DOCUMENTS
Dimensions
TO-263AB (D
2
PAK)
TO-262AA
TO-263AB (D
2
PAK)
TO-262AA
TO-263AB (D
2
PAK)
www.vishay.com/doc?95046
www.vishay.com/doc?95419
www.vishay.com/doc?95444
www.vishay.com/doc?95443
www.vishay.com/doc?95032
Part marking information
Packaging information
