SERIES 850, 851, 852, 853 • .050” GRID HEADERS AND SOCKETS •
SINGLE AND DOUBLE ROW STRIPS
(Number of Pins
X .050”) + .015”
.118
.087
.016 DIA.
.114
.087
.016 DIA.
•
Series 850, 851, 852, 853 single and double
row interconnects have .050” pin spacing and
permit board stacking as low as .248”
See page 208 for details
•
Pin headers have .016” dia. pins (MM #4006-0)
•
MM #0467 and MM #4890 receptacles use
.050
FIG. 1
.120
.016 DIA.
Hi-Rel, 3- nger BeCu #11 contact rated at
3 amps. ( #11 contact accepts pin diameters
from .015”-.020” ). See pages 158 and 160 for
details
suitable for all soldering operations
(Number of Pins
X .050”/2) + .015”
.118
.075 .083
•
Insulators are high temperature thermoplastic,
ORDERING INFORMATION
Series 850...001
.016 DIA.
.118
FIG. 1
.050
Single Row .087” Pro le Pin Header
850 XX 0_ _ 10 001000
01-50
FIG. 2
.087
Specify number of pins
Series 852...001
(Number of Pins
X .050”) + .015”
FIG. 2
RoHS - 2
Double Row .083” Pro le Pin Header
852 XX _ _ _ 10 001000
004-100
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.120
.075
.161
Specify number of pins
XX=Plating Code
See Below
10
10
µ”
Au
.018 DIA.
.099
2011/65/EU
.050
SPECIFY PLATING CODE XX=
Pin Plating
90
200
µ”
Sn/Pb
40
200
µ”
Sn
FIG. 3
.120
(Number of Pins
X .050”/2) + .015”
Series 851...001
.120
.075
.158
FIG. 3
Series 853...001
Single Row .161” Pro le Socket
851 XX 0_ _ 10 001000
01-50
Specify number of pins
.018 DIA.
.102
FIG. 4
.050
Double Row .161” Pro le Socket
853 XX _ _ _ 10 001000
004-100
Specify number of pins
FIG. 4
PAGE 34 | INTERCONNECTS
.070
Series 851...002
(Number of Pins
X .050”) + .040”
FIG. 5
RoHS - 2
Single Row .185” Pro le Socket
851 XX 0_ _ 10 002000
01-77
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.075
.150
.185
Specify number of pins
XX=Plating Code
See Below
91
10
µ”
Au
2011/65/EU
.018 DIA.
.115
.050
FIG. 5
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
93
99
41
43
200
µ”
Sn
30
µ”
Au
47
200
µ”
Sn
Au Flash
200
µ”
Sn/Pb 200
µ”
Sn/Pb 200
µ”
Sn/Pb
200
µ”
Sn
30
µ”
Au
100
µ”
Sn/Pb
10
µ”
Au
