LT1785ACS8#TRPBF

Description
IC TXRX 60V RS485/RS422 8SOIC
CategoryAnalog mixed-signal IC    Drivers and interfaces
File Size833KB,12 Pages
ManufacturerLinear ( ADI )
Websitehttp://www.analog.com/cn/index.html
Environmental Compliance
Download Datasheet Parametric View All

LT1785ACS8#TRPBF Overview

IC TXRX 60V RS485/RS422 8SOIC

LT1785ACS8#TRPBF Parametric

Parameter NameAttribute value
Brand NameLinear Technology
Is it Rohs certified?conform to
MakerLinear ( ADI )
Parts packaging codeSOIC
package instructionSOP, SOP8,.25
Contacts8
Manufacturer packaging codeS8
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Differential outputYES
Number of drives1
Input propertiesDIFFERENTIAL SCHMITT TRIGGER
Interface integrated circuit typeLINE TRANSCEIVER
Interface standardsEIA-422; EIA-485
JESD-30 codeR-PDSO-G8
JESD-609 codee3
length4.9 mm
Humidity sensitivity level1
Number of functions1
Number of terminals8
Maximum operating temperature70 °C
Minimum operating temperature
Minimum output swing1.5 V
Maximum output low current0.0016 A
Package body materialPLASTIC/EPOXY
encapsulated codeSOP
Encapsulate equivalent codeSOP8,.25
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)250
power supply5 V
Certification statusNot Qualified
Maximum receive delay900 ns
Number of receiver bits1
Maximum seat height1.75 mm
Maximum slew rate9 mA
Maximum supply voltage5.25 V
Minimum supply voltage4.75 V
Nominal supply voltage5 V
surface mountYES
technologyBIPOLAR
Temperature levelCOMMERCIAL
Terminal surfaceMatte Tin (Sn)
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
maximum transmission delay2000 ns
width3.9 mm
Base Number Matches1
