LED Module
Rev. No
1.5
Page
1 / 15
SPECIFICATION
<LAM-SQ32B>
<LAM-RT32B>
LAM-32LED (Lens Attached Module)
Model Name
Type
LAM-SQ32B, LAM-SQ32B
24V, 385mA
L A M -S Q 3 2 B
3000K
3500K
S I-B 8 V 0 9 5 2 6 0 W W
S I-B 8 U 0 9 5 2 6 0 W W
S I-B 8 T 0 9 5 2 6 0 W W
S I-B 8 R 0 9 5 2 6 0 W W
S I-B 8 P 0 9 5 2 6 0 W W
L A M -R T 3 2 B
S I-B 8 V 0 9 5 2 8 0 W W
S I-B 8 U 0 9 5 2 8 0 W W
S I-B 8 T 0 9 5 2 8 0 W W
S I-B 8 R 0 9 5 2 8 0 W W
S I-B 8 P 0 9 5 2 8 0 W W
Parts No.
4000K
5000K
6500K
SAMSUNG ELECTRONICS CO,.LTD.
SAN #24 NONGSEO-DONG, GIHEUNG-GU,
YONGIN-SI, GYEONGGI-DO, 446-711, KOREA
LAM-SQ32B, LAM-RT32B
Date of Issue : April, 2014
LED Module
Revision History
Rev.No
1.0
1.5
Data
April, 2014
April, 2014
Page
-
-
Revision
The first preliminary specification is
established. Total 15 pages
The final specification is released.
Total 15 pages.
Rev. No
1.5
Page
2 / 15
Remark
-
Code Information
- SI-B8W09XYZ0WW
W
: Color Temperature ( T : 4000K, R : 5000K, P : 6500K )
X
: Model type ( 1,3,5 ... : C type, 2,4,6 .... : D type )
YZ
: Model type ( 26 : 2x2 model, 28 : 1x4 model )
LAM-SQ32B, LAM-RT32B
※
Date of Issue : April, 2014
LED Module
Rev. No
1.5
Page
3 / 15
Contents
1
2
3
4
5
6
Products and Applications
Specification
Structure and Assembly
Approbation
Packing
Precautions In Handling
4
4
6
12
13
14
LAM-SQ32B, LAM-RT32B
Date of Issue : April, 2014
LED Module
1. Products and Application
Rev. No
1.5
Page
4 / 15
This specification defines general specification and performance for Lens Attached LED module.
Samsung LAM products target to replace conventional fluorescent lamps as T5, T8 and so on
with LED solutions. Due to transferring LED, new luminaire transferred to LED can take more
energy saving and longer life-time.
In special, Samsung has the competitiveness in middle-power solutions. This module uses
LM561B. Middle power solutions provide more homogeneous and higher efficient lights.
Moreover, LAM solution that is integrated advanced optical technology designed by Samsung
provides you higher uniformity. It's possible to design slimmer luminaire with clear appearance.
2. Specification
No.
2-1
Item
Dimension
Specifications
SQ : 250 x 259 x 6.8
RT : 216 x 273 x 6.8
SQ : 98 g
RT : 90 g
50,000 Hr
Unit
Remark
mm Tolerance:±0.5mm
2-2
Weight
g
Tolerance: ±5g
L70B50
2-4
Ingress Protection
N/A
-
-
Operating Temperature
Storage Temperatue
LAM-SQ32B, LAM-RT32B
℃
2-6
Ta = - 40 ~ 80
℃
2-5
Tc = - 20 ~ 50
-
-
Date of Issue : April, 2014
℃
2-3
Rated lifetime
hour
@Tc = 80
LED Module
No.
Item
Specifications
Sym. Model
3000K
3500K
2-7
Luminous flux
Φ
v
4000K
5000K
6500K
3000K
3500K
2-8
Efficiency
LPW
4000K
5000K
6500K
2-9
Color consistency
4000K
-
CRI
5/6500K
-
4000K
2-11 CCT
-
5000K
6500K
2-12 Operating Current
2-13 Operating Voltage
Iop
Vdc
-
-
-
-
-
-
-
80
3,710
4,745
6,020
-
22.0
Rev. No
1.5
Page
5 / 15
Unit
Max.
1260
1280
Remark
Min.
1010
1030
1060
1100
1060
Nom.
1130
1150
1200
1240
1200
123
126
1380
1330
135
130
3
4
-
3,985
5,028
6,530
385
24.0
-
-
-
-
-
4,260
Ra
step
MacAdam
@ initial time
-
@385mA, 24V
2-10 Color Rendering Index
7,040
-
26.0
mA
V
-
@385mA,
Measurement tolerance of luminous flux becomes ± 7%
in the
value,
LAM-SQ32B, LAM-RT32B
±
measurement tolerance of Vf becomes
0.3V in the value.
Date of Issue : April, 2014
℃
2-14 Power Consumption
-
-
-
9.2
-
W
@385mA,
Tp = 35
℃
Tp = 35
℃
5,311
K
Tp = 35
℃
130
-
lm/W
@385mA, 24V
Tp = 35
℃
1330
lm
@385mA, 24V
Tp = 35
※
