Miniature push-pull connectors with ground function
MXR Series
Features
1. User friendly lock mechanism
The single action push-pull lock function allows
quick connections and disconnections as well as
high density mounting.
2. Grounding function for FCC compliance
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Metal, outer shell provides stable contact for
grounding.
3. Sequential contact structure
A sequential mating type is available. This version
allows for the contacts to mate in a sequenced
order.
Product Specifications
Number of contacts
Rated current
3
4
6
8
Number of contacts
Rated voltage
3
4
6
8
-25 to +85ç
-10 to +60ç
Conditions
Measured at DC 1A
Measured at DC 100V
AC 300V for 1minute
10 to 55Hz/cycle, amplitude : 0.75mm, 3 axis directions,
2 hours each
Acceleration : 490m/s
2
, duration : 11ms, 3 axis directions,
3 times each
1,000 times
-55ç : 30 minutes
➝
Normal temperature : 10 to 15
minutes
➝
85ç : 30 minutes
➝
Normal temperature :
10 to 15 minutes, left for 5 cycles
Temperature : 40°C, relative humidity : 90 to 95%,
left for 96 hours
Rated current
2A
Ratings
Rated voltage
AC 100, DC 140V
Operating temperature range
Storage temperature range
Items
1. Contact resistance
2. Insulation resistance
3. Withstanding voltage
4. Vibration resistance
5. Shock resistance
6. Mating cycles
Specifications
A maximum of 20mø
A minimum of 1,000Mø
No flashover or dielectric breakdown.
No electrical discontinuity for 10µs or
greater.
No electrical discontinuity for 10µs or
greater.
Contact resistance : a maximum of 40mø
Insulation resistance :
a minimum of 1,000Mø
Insulation resistance :
a minimum of 10Mø (at high humidities)
a minimum of 100Mø (when dry)
7. Temperature cycle
8. Moisture resistance
Materials / Finish
Part
Shell
Insulator
Contact
Material
Aluminum alloy
PBT resin
Copper alloy
Finish
Nickel plating
----------------
Gold plating, partial gold plating
Remarks
----------------
UL94V-0
----------------
In cases where the application will demand a high level of reliability, such as automotive,
please contact a company representative for further information.
2018.7④
1
MXR Series
●
Miniature push-pull connectors with ground function
Product Number Structure
Refer to the chart below when determining the product specifications from the product number.
Please select from the product numbers listed in this catalog when placing orders.
MXR - 8 P A - 3 P B
(**)
❶
❷
❸
❹
❺
❻
❼
½
qSeries
name : MXR Series
wShell
size : Indicates the outer shell diameter at the mating end.
eShell
classification : Classified as follows
P : Plug
R : Receptacle
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
r
Shell modification : The letters A, B, C, D, E, etc. indicate modifications of the shell form.
tPin
arrangement : Indicated by the number of pins
yPin
form : Classified as follows
P : Male contacts
S : Female contacts
u
Pin modification : The letters A, B, C, D, E, etc. indicate modifications of the pin form.
iSpecial
specifications : A two-digit number is added to indicate other specifications, such as (01), (02), (03)...
12
3
Ø13.9
MXR-8P-8P(31)
Part No
MXR-8PA-3PB(71)
MXR-8PA-4PB(71)
MXR-8PA-6PB(71)
MXR-8P-8P(31)
MXR-8P-8P(72)
HRS No.
127-0003-6 71
127-0004-9 71
127-0005-1 71
127-0002-3 31
127-0002-3 72
A
47
50
ØB
5
8
Weight
8g
9g
A
(Representative shape example)
Bushing
Black
White
Remarks
Sequenced construction
----------------
----------------
Note : Cable pull force, twisting strength and other characteristics may differ, depending on cable specifications and structure.
Please evaluate under the actual conditions prior the use.
Receptacle (Secured with hex nut for mounting)
Solder termination
Panel
Guide
Ø10.5
Ø14
2 1
3
9
MXR-8RA-8S(71)
Part No.
MXR-8RA-3S(71)
MXR-8RA-4S(71)
MXR-8RA-6S(71)
MXR-8RA-8S(71)
HRS No.
127-0121-2 71
127-0122-5 71
127-0123-8 71
127-0124-0 71
Weight
3.5g
19
A
(Representative shape example)
A
19.3
20.4
Remarks
----------------
----------------
----------------
----------------
2
Suitable cable diameter
ØB
Plug
MXR Series
●
Miniature push-pull connectors with ground function
Receptacle (Flange type)
Dip termination
Panel
M2.6∞0.45
Guide
Ø10.5
Min. Ø11.5
3
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
2
11
20
6
10.5
15
MXR-8R-8SA(71)
(Representative example)
Part No.
MXR-8R-3SA(71)
MXR-8R-4SA(71)
MXR-8R-6SA(71)
MXR-8R-8SA(71)
HRS No.
127-0101-5 71
127-0103-0 71
127-0104-3 71
127-0102-8 71
Weight
3.5g
Remarks
with gold-plated contacts
Layout dimensions for dip post contacts
3 pin
3-Ø
Ø0
1.9±0.05
0.7
+0
.
0 1
4.1±0.05
0.8±0.05
1.7±0.05
1.9±0.05
d)
ole)
roun
1
+0.
(G
ng h
0
tioni
si
Ø0.8
+0.1
(Po
0.8
0
2-Ø
2.3±0.05
2.3±0.05
.8
+0
0 .1
4 pin
ro
2±0.05
(G
4-
Ø
un
0.
7
d)
0.4±0.05
1.7±0.05
+0
0 .1
0.8
2-Ø
.1
+0 0
)
ole
gh
in
on
siti
o
(P
4.1±0.05
2.1±0.05
2.9±0.05
1.5±0.05
1.5±0.05
1.2±0.05
2±0.05
1.2±0.05
2±0.05
6 pin
2±0.05
1.9±0.05
6-Ø
0.7
+
0.
0 1
8 pin
8-Ø
4.1±0.05
1.2±0.05
1±0.05
2.2±0.05
2±0.05
1.9±0.05
le)
nd)
+0.1
(Grou
ho
Ø0.8
0
ing
1
on
0.
i
+ 0
sit
.8
(Po
Ø0
2-
2.6±0.05
2±0.05
1.76±0.05
0.7
+
0.
0 1
3.41±0.05
1.76±0.05
Ø
0.8
1.4±0.05
2.25±0.05
2.03±0.05
0.5±0.05
0.98±0.05
2.19±0.05
)
nd
+ 0
rou
0.8
(G
2-Ø
4.1±0.05
.1
+0
0
le)
ho
ing
on
siti
o
0.1
(P
2±0.05
0.98±0.05
2.19±0.05
0.77±0.05
3.5±0.05
Remarks : Figures are views from the mating side of the receptacle.
Marks
▼
show the position of the guide.
13.5
18
2 1
3
MXR Series
●
Miniature push-pull connectors with ground function
Wiring and Assembly Procedure
MXR-8PA-3PB(71), MXR-8PA-4PB(71), MXR-8PA-6PB(71)
P shell unit
Clamp
Plug body
Cable bushing
Cable
7 or greater
Spanner spacing of 9.5
3
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
15
Work Procedure
1. Pass the cable through the components in this order : 1. cable bushing, 2. plug body, 3. clamp fitting. Then perform
the cable end processing.
2. Solder the wires to the P shell unit.
3. Align the protruding portion of the clamp with the recessed portion of the P shell unit and mount.
4. Align the plug and cable sheath strip position, then tighten the plug body to the screw portion of the P shell unit
with a torque of 1
N•m.
Note that to prevent loosening, an application of Locktight 263 manufactured by HENKEL JAPAN LTD. is
recommended.
5. Put the cable bushing over the clamp body to complete the job.
MXR-8P-8P(**)
P shell unit
Clamp fitting
Plug body
Cable bushing
Cable
2 or greater
Boss
Set screw
3
Spanner spacing of 10
18
Work Procedure
1. Pass the cable through the components in this order : 1. cable bushing, 2. plug body. Then perform the cable end
processing.
2. Solder the wires to the P shell unit.
3. Fasten the clamp fitting to the cable with the cable crimping tool (HR10A-TC-04).
4. Tighten the clamp body to the screw portion of the P shell unit with a torque of 1
N•m.
Note that to prevent loosening, an application of Locktighe 263 manufactured by HENKEL JAPAN LTD. is
recommended.
5. Tighten the set screw so that the tip falls into one of the two bosses of the clamp fitting.
Note that a tightening torque of 0.3
N•m.
is specified.
6. Put the cable bushing over the clamp body to complete the job.
4
MXR Series
●
Miniature push-pull connectors with ground function
Dimensions for receptacle mounting holes
3
+0.1
0
Guide position
Guide
position
13.5±0.05
.
Ø11
5
.1
+0
0
6
+0.1
0
Ø10
+0.1
.1
0
2-
Ø2
.8
.1
+0 0
10.5±0.05
Panel thickness 1 to 4mm
Panel thickness Max 1.6mm
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
(Jam Nut Type)
NOTES :
1. Above figures are views from the mating side of the receptacle.
Also note that the
▼
symbol indicates the guide position.
(Flange Type)
Applicable Tools
Type
Tightening jig
Cable crimping tool
Part No.
MXR-8P-T01
HR10A-TC-04
HRS No.
150-0092-3
150-0058-5
Applicable Connectors
All plug products
MXR-8P-8P (**)
MXR-8P-T01
HR10A-TC-04
Pin arrangement and electrical specifications
Number of contacts
3
4
6
8
Pin arrangement
Withstanding voltage
Current capacity
Insulation resistance
Contact resistance
Solder pot diameter
300V AC for 1minute
2A
1,000Mø or greater at 100V DC
20mø or less at 1A DC
0.9mm dia.
NOTES :
1. Above figures are views from the mating side of the receptacle.
Also note that the
▼
symbol indicates the guide position.
2. The withstand voltage value indicates the test voltage.
The connector should normally be used at less than 100V AC or 140V DC.
5
