OP6700 Intellicom
Models OP6700, OP6600
OP6700 Description
OP6700 Specifications
D
Large View
|
360° View
S
Description
The Intellicom is a C-programmable, 12-key graphic display with Ethernet for network connectivity and a VFD
option for applications requiring high visibility. To accommodate users' installation preferences, the versatile
Intellicom can be either wall or panel mounted.
S
Features
10Base-T Ethernet with RJ-45
High-visibility backlit, supertwist 4 x 20 LCD
12-key, user-relegendable keypad
8 industrialized I/O
Scratch-resistant, self-healing lens
Powered by the
Rabbit® 2000 microprocessor,
the OP6700 offers direct connection to 10Base-T Ethernet and
communicates with serial devices via RS-232 and/or RS-485, providing multiple solutions for your
communication applications. Eight general-purpose I/O provide control functionality.
A high-visibility 4 x 20 character display with backlighting provides excellent character legibility, and a tactile
feedback 2 x 6 keypad offers a legend that can be user customized. The Intellicom is easily mounted and comes
with bezel and impact-resistant plastic enclosure.
Programming the Intellicom
http://www.rabbit.com/products/op6700/index.shtml
10/14/2008
OP6700 Intellicom | Products | Rabbit
Page 2 of 2
Programs are developed using Rabbit's industry-proven
Dynamic C®
software development system. An
extensive library of drivers and sample programs is provided, along with royalty-free TCP/IP stack with source.
All Intellicom models can be programmed and debugged over Ethernet/Internet using appropriate accessory
hardware.
OP6700 Intellicom Specifications
Features
Microprocessor
Ethernet Port
Flash
SRAM
Backup Battery
Keypad/Display
Digital Inputs
Digital Outputs
Speaker Outputs
Serial Ports
Serial Rate
Connectors
Real-Time Clock
Timers
Watchdog/Supervisor
Power
Operating Temp.
Humidity
Board Size
Enclosure Size
Part Number
Starter Package
20-101-0411
U.S. 20-101-0411, 101-0414,
Int'l 20-101-0411, 101-0415
OP6700
OP6600
Rabbit 2000 @ 18.432 MHz
10Base-T, RJ-45
512K (2 x 256K)
128K (standard)
Socketed board with 3 V lithium coin-type, 1,000 mA·h, supports RTC and SRAM
2 x 6 domed tactile keypad with customizable legend, supertwist 4 x 20 LCD with
backlighting
4 protected to ±36 V DC
4 sink 200 mA, 40 V DC max.
Software-adjustable frequency and volume
3 total: one 5 V CMOS-compatible (programming) and either two 3-wire RS-232, one
3-wire RS-232 and one RS-485, or one 5-wire RS-232
Max. burst rate = CLK/32
Max. sustained rate = burst/2
Screw terminals
Yes
Five 8-bit timers (four cascadable from the first) and one 10-bit timer with 2 match
registers
Yes
9-40 V DC, 2.4 W (backlighting on)
0°C - 50°C
5-95%, non-condensing
4.7" x 4.3" x 0.8"
(119 mm x 109 mm x 20 mm)
6.7" × 5.7" × 2.0"
(170 mm × 145 mm × 51 mm)
101-0412
U.S. 101-0412, 101-0414,
Int'l 101-0412, 101-0415
None
256K
