ZY2140 40A No-Bus POL Data Sheet
8V to 14V Input
•
0.5V to 3.65V Output
Member of the
Family
Applications
•
Low voltage, high density systems with
Intermediate Bus Architectures (IBA)
•
Point-of-load regulators for high performance DSP,
FPGA, ASIC, and microprocessor applications
•
Industrial computing, servers, and storage
•
Broadband, networking, optical, and wireless
communications systems
•
Active memory bus terminators
Benefits
•
Integrates digital power conversion with intelligent
power management
•
Eliminates the need for external power
management components and communication bus
•
Completely programmable via pin strapping and
one external resistor
•
One part that covers all applications
•
Reduces board space, system cost and
complexity, and time to market
Description
Features
•
RoHS lead free and lead-solder-exempt products are
available
•
Wide input voltage range: 8V–14V
•
High continuous output current: 40A
•
Wide programmable output voltage range: 0.5V–
3.65V
•
Active digital current share
•
Output voltage margining
•
Overcurrent and overtemperature protections
•
Overvoltage and undervoltage protections, and Power
Good signal tracking the output voltage setpoint
•
Tracking during turn-on and turn-off with guaranteed
slew rates
•
Sequenced and cascaded modes of operation
•
Single-wire line for frequency synchronization
between multiple POLs
•
Programmable feedback loop compensation
•
Differential output voltage sense
•
Enable control
•
Flexible fault management and propagation
•
Start-up into the load pre-biased up to 100%
•
Current sink capability
•
Real time current measurements, monitoring, and
reporting
•
Industry standard size through-hole single-in-line
package: 1.8”x0.55”
•
Low height of 1.1”
•
Wide operating temperature range: 0 to 70ºC
•
UL 60950-1/CSA 22.2 No. 60950-1-07 Second
Edition, IEC 60950-1: 2005, and EN 60950-1:2006
Power-One’s point-of-load converters are recommended for use with regulated bus converters in an Intermediate
Bus Architecture (IBA). The ZY2140 is an intelligent, fully programmable step-down point-of-load DC-DC module
integrating digital power conversion and power management. The ZY2140 completely eliminates the need for
external components for sequencing, tracking, protection, monitoring, and reporting. Performance parameters of
the ZY2140 are programmable by pin strapping and an external resistor and can be changed by the user at any
time during product development and service without a need for a communication bus.
Reference Documents
No-Bus POL Converters. Application Note
®
Z-One POL Converters. Eutectic Solder Process Application Note
®
Z-One POL Converters. Lead-Free Process Application Note
ZD-02014 Rev. BB4, 11-Oct-2011
www.power-one.com
Page 1 of 14
TM
ZY2140 40A No-Bus POL Data Sheet
8V to 14V Input
•
0.5V to 3.65V Output
1.
Ordering Information
ZY
Product
family:
Z-One
Module
21
Series:
No-Bus
POL
Converter
40
Output
Current:
40A
y
RoHS compliance:
No suffix
- RoHS compliant with Pb solder
1
exemption
G
- RoHS compliant for all six substances
–
Dash
zz
Packaging Option :
R1
– 30 pcs Tray
Q1
– 1 pc sample for
evaluation only
2
______________________________________
1
The solder exemption refers to all the restricted materials except lead in solder. These materials are Cadmium (Cd), Hexavalent chromium
(Cr6+), Mercury (Hg), Polybrominated biphenyls (PBB), Polybrominated diphenylethers (PBDE), and Lead (Pb) used anywhere except in
solder.
2
Packaging option is used only for ordering and not included in the part number printed on the POL converter label.
Example:
ZY2140G-R3:
A 30-piece tray of RoHS compliant POL converters. Each POL converter is labeled
ZY2140G.
2.
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings may cause performance degradation, adversely affect long-
term reliability, and cause permanent damage to the POL converter.
Parameter
Operating Temperature
Input Voltage
Conditions/Description
Controller Case Temperature
250ms Transient
Min
-40
Max
105
15
Units
°C
VDC
3.
Environmental and Mechanical Specifications
Parameter
Ambient Temperature Range
Storage Temperature (Ts)
Weight
Operating Vibration
(sinusoidal)
Frequency Range
Magnitude
Sweep Rate
Repetitions in each axis (Min-Max-Min Sweep)
Acceleration
Duration
Number of shocks in each axis
Calculated Per Telcordia Technologies SR-332
ZY2140
ZY2140G
ZY2140 and ZY2140G
JEDEC J-STD-020C
245
5
0.5
1
2
50
11
10
TBD
220
260
Conditions/Description
Min
0
-55
33
500
Nom
Max
70
125
Units
°C
°C
grams
Hz
G
oct/min
sweeps
G
ms
MHrs
°C
°C
Non-Operating Shock
(half sine)
MTBF
Peak Reflow Temperature
Peak Reflow Temperature
Lead Plating
Moisture Sensitivity Level
100% Matte Tin
3
ZD-02014 Rev. BB4, 11-Oct-2011
www.power-one.com
Page 2 of 14
ZY2140 40A No-Bus POL Data Sheet
8V to 14V Input
•
0.5V to 3.65V Output
4.
Electrical Specifications
Specifications apply at the input voltage from 8V to 14V, output load from 0 to 40A, ambient temperature from 0°C
to 70°C, output capacitance consisting of 110µF ceramic and 220µF tantalum, and the CCA=1 unless otherwise
noted.
4.1
Input Specifications
Parameter
Input voltage (V
IN
)
Undervoltage Lockout Threshold
Input Current
Maximum Input Current
Conditions/Description
Refer to Figure 1
Ramping Up
Ramping Down
V
IN
=12V
V
IN
=8V
Min
8
7.5
6.6
23
19.7
Nom
Max
14
Units
VDC
VDC
VDC
mADC
ADC
4.2
Output Specifications
Parameter
Output Current (I
OUT
)
Output Voltage Range (V
OUT
)
Output Voltage Setpoint
3
Accuracy
Line Regulation
3
3
Conditions/Description
V
IN MIN
to V
IN MAX
Programmable with a resistor between
TRIM and MARGIN pins
Default (no resistor)
V
IN
=12V, I
OUT
=0.5*I
OUT MAX
, room
temperature
V
IN MIN
to V
IN MAX
0 to I
OUT MAX
50% - 75% - 50% load step
Slew rate 1A/µs, C
OUT
=380µF
to 10% of peak deviation
V
IN
=12V, V
OUT
=0.75V
V
IN
=12V, V
OUT
=2.5V
V
IN
=12V, V
OUT
=3.3V
V
IN
=12V, V
OUT
=0.5V
V
IN
=12V, V
OUT
=0.75V
V
IN
=12V, V
OUT
=1.0V
V
IN
=12V, V
OUT
=1.2V
V
IN
=12V, V
OUT
=1.8V
V
IN
=12V, V
OUT
=2.5V
V
IN
=12V, V
OUT
=3.3V
V
IN
=12V, I
OUT
=0.5*I
OUT MAX
2 phases combined
2
Min
-40
1
Nom
Max
40
3.65
Units
ADC
VDC
VDC
%V
OUT
%V
OUT
%V
OUT
mV
µs
mV
mV
mV
%
%
%
%
%
%
%
ppm/°C
0.5
0.5
±1.5% or 20mV whichever is
greater
±0.5
±0.5
280
100
15
25
35
75.3
81.9
85.3
87
90.2
92.1
93.5
35
450
500
550
Load Regulation
Dynamic Regulation
Peak Deviation
Settling Time
Output Voltage Peak-to-Peak
Ripple and Noise
BW=20MHz
Full Load
Efficiency
F
SW
=500kHz
Full Load
Room temperature
Temperature Coefficient
Switching Frequency
1
kHz
At the negative output current (bus terminator mode) efficiency of the ZY2140 degrades resulting in increased internal power dissipation.
Maximum allowable negative current is limited to 40A.
2
ZY2140 is a step-down converter, thus the output voltage is always lower than the input voltage as show in
Error! Reference source not
found..
3
Digital PWM has an inherent quantization uncertainty of ±6.25mV that is not included in the specified static regulation parameters.
ZD-02014 Rev. BB4, 11-Oct-2011
www.power-one.com
Page 3 of 14
ZY2140 40A No-Bus POL Data Sheet
8V to 14V Input
•
0.5V to 3.65V Output
4.3
Protection Specifications
Parameter
Conditions/Description
Output Overcurrent Protection
Type
Threshold
Threshold Accuracy
Output Overvoltage Protection
Type
Threshold
Threshold Accuracy
Delay
Follows the output voltage setpoint
Measured at V
O.SET
=2.5V
From instant when threshold is exceeded until
the turn-off command is generated
Output Undervoltage Protection
Type
Threshold
Threshold Accuracy
Delay
Follows the output voltage setpoint
Measured at V
O.SET
=2.5V
From instant when threshold is exceeded until
the turn-off command is generated
Overtemperature Protection
Type
Turn Off Threshold
Turn On Threshold
Threshold Accuracy
Delay
From instant when threshold is exceeded until
the turn-off command is generated
Power Good Signal (PGOOD pin)
Logic
Lower Threshold
Upper Threshold
Delay
Threshold Accuracy
V
OUT
is inside the PG window and stable
V
OUT
is outside of the PG window or ramping
up/down
Follows the output voltage setpoint
Follows the output voltage setpoint
From instant when threshold is exceeded until
status of PG pin changes
Measured at V
O.SET
=2.5V
-2
High
N/A
Low
90
110
6
2
%V
O.SET
%V
O.SET
μs
%V
O.SET
Temperature is increasing
Temperature is decreasing after module was
shut down by OTP
-5
6
Non-Latching, 130ms period
120
110
5
°C
°C
°C
μs
-2
6
Non-Latching, 130ms period
75
2
%V
O.SET
%V
UVP.SET
μs
-2
6
130
1
Min
Nom
Max
Units
Non-Latching, 130ms period
140
-25
25
%I
OUT
%I
OCP.SET
Latching
%V
O.SET
2
%V
OVP.SET
μs
___________________
1
Minimum OVP threshold is 1.0V
ZD-02014 Rev. BB4, 11-Oct-2011
www.power-one.com
Page 4 of 14
ZY2140 40A No-Bus POL Data Sheet
8V to 14V Input
•
0.5V to 3.65V Output
4.4
Feature Specifications
Parameter
Conditions/Description
Current Share (CS pin)
Type
Current Share Accuracy
I
OUT MIN
≥20%*I
OUT NOM
Tracking
Rising Slew Rate
Falling Slew Rate
Proportional to SYNC frequency
Proportional to SYNC frequency
Enable (EN pin)
EN Pin Polarity
EN High Threshold
EN Low Threshold
Open Circuit Voltage
Turn-On Delay
Turn-Off Delay
From EN pin changing state to V
OUT
starting to ramp up
From EN pin changing state to V
OUT
reaching 0V
Feedback Loop Compensation (CCA pin)
CCA pin is open
Recommended C
OUT
/ESR range,
combination of ceramic + tantalum
Recommended C
OUT
/ESR range, ceramic
50/5 +
220/40
100/5
100/5 +
470/40
220/5
400/5 +
2000/20
400/5
µF/mΩ
µF/mΩ
µF/mΩ
3.3
0
11
Positive (enables the output when EN pin is
open or pulled high)
2.3
1.0
VDC
VDC
VDC
ms
ms
0.1
-0.5
V/ms
V/ms
Active, Single Line
±20
%I
OUT
Min
Nom
Max
Units
CCA pin is connected to GND
Output Current Monitoring (CS pin)
Output Current Monitoring
Accuracy
Conversion Ratio
30%*I
OUT NOM
< I
OUT
< I
OUT NOM
V
IN
=12V
Duty Cycle of the negative pulse
corresponding to 100% of nominal current
Remote Voltage Sense (-VS and +VS pins)
Type
Voltage Drop Compensation
Voltage Drop Compensation
Between +VS and VOUT
Between -VS and PGND
Differential
300
100
mV
mV
-20
74
+20
%I
OUT
%
ZD-02014 Rev. BB4, 11-Oct-2011
www.power-one.com
Page 5 of 14
