Model 501 Tracker
™
II
Cable Locator System
Read
and
understand
all of the instructions
and safety information in this manual before
operating or servicing this tool.
52031017 REV 4
© 2008 Greenlee Textron Inc.
8/08
Contents
Description ...............................................................................................................2
Safety .......................................................................................................................2
Purpose of This Manual............................................................................................2
Important Safety Information................................................................................ 3–4
Identification .............................................................................................................5
Operation.............................................................................................................. 5–7
Inductive Coupler Description ..................................................................................8
Inductive Antenna Description ...............................................................................10
Specifications .........................................................................................................11
Maintenance ...........................................................................................................12
Compatible Products .............................................................................................12
Description
The Model 501 is designed to locate the path and depth of buried cable, service
wires, metallic pipe or conduit and locate the end of a cut cable.
The Model 501 consists of:
• 501T Transmitter
• 501R Receiver
• 500CA Carrying Case with Inductive Antenna
• CS16 Cord Set
• IC-1 Inductive Coupler
Safety
Safety is essential in the use and maintenance of Greenlee tools and equipment.
This instruction manual and any markings on the tool provide information for
avoiding hazards and unsafe practices related to the use of this tool. Observe all of
the safety information provided.
Purpose of This Manual
This instruction manual is intended to familiarize all personnel with the safe
operation and maintenance procedures for the Greenlee Model 501.
Keep this manual available to all personnel. Replacement manuals are available
upon request at no charge at www.greenlee.com.
All specifications are nominal and may change as design improvements occur.
Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
Tracker is a trademark of Greenlee Textron Inc.
KEEP THIS MANUAL
2
501
Important Safety Information
SAFETY ALERT
SYMBOL
This symbol is used to call your attention to hazards or unsafe practices
which could result in an injury or property damage. The signal word, defined
below, indicates the severity of the hazard. The message after the signal
word provides information for preventing or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result in severe injury or
death.
Hazards which, if not avoided, COULD result in severe injury or death.
Hazards or unsafe practices which, if not avoided, MAY result in injury or
property damage.
Read
and
understand
this material before operating or
servicing this equipment. Failure to understand how to
safely operate this tool could result in an accident causing
serious injury or death.
Electric shock hazard:
Contact with live circuits could result in severe injury
or death.
3
Important Safety Information
Electric shock hazard:
• Do not expose this unit to rain or moisture.
• Use this unit for the manufacturer’s intended purpose only, as described in
this manual. Any other use can impair the protection provided by the unit.
• Use test leads or accessories that are appropriate for the application. Refer to
the category and voltage rating of the test lead or accessory.
• Inspect the test leads or accessory before use. They must be clean and dry,
and the insulation must be in good condition.
• Before opening the case, remove the test leads from the circuit and shut off
the unit.
Failure to observe these warnings could result in severe injury or death.
Electric shock hazard:
• Do not attempt to repair this unit. It contains no user-serviceable parts.
• Do not expose the unit to extreme temperatures or high humidity. Refer to
“Specifications”.
Failure to observe these precautions may result in injury and can damage the
instrument.
4
501
Identification
The Model 501 is designed to locate the path and depth of buried cable, service
wires, metallic pipe or conduit and locate the end of a cut cable.
Transmitter
The transmitter is housed in an aluminum case and is powered by eight (8) 1.5V AA
batteries. The transmitter has an on/off control knob which is also used to adjust
the output level and a light emitting diode (LED) indicating the battery condition.
In addition, the transmitter has an automatic shut-off feature after 1.5 hours of
non-use. Effective range is greater than 4000 feet in length and for depths up to
7 feet.
Receiver
The receiver is encased in an aluminum housing, mounted with an antenna and is
powered by one (1) 9V battery. Like the transmitter, the receiver will automatically
shut itself off after 1.5 hours of non-use. The receiver has a speaker for listening to
the signal, a meter for monitoring the signal level, a headset jack, an on/off volume
control knob and an antenna for detecting the tone over the cable.
Carrying Case with Inductive Antenna
The case is used for storing and transporting the Tracker II system and is
constructed of vacuum formed polyethylene. The case also includes an easy, quick
reference operation guide on the inside of the lid.
Cord Set
An 8 foot pair of leads with plugs and clips is included for connecting the
transmitter to the cable or pipe.
Inductive Coupler
The inductive coupler induces a tracing tone on a cable, wire or pipe by clamping
around it.
Optional Headset
The headset can be used to monitor the received signal in high noise level areas
and is plugged into the receiver jack provided.
Operation
Testing Transmitter Batteries
Plug cord set leads into transmitter and clip leads together. Turn transmitter control
on and rotate fully clockwise. A bright LED indicates enough battery power. Refer to
the “Maintenance” section for battery replacement.
Connecting Transmitter Leads
IMPORTANT:
The transmitter is protected against damage from inadvertent direct
connection to voltages up to 250 VAC. However, direct connection to energized
cable is not recommended. The inductive coupler Model IC-1 is included for such
applications.
Shielded Cable (Coaxial):
Connect one lead to the shield and the other lead to one
wire within the cable.
Unshielded Cable:
Connect each lead to separate conductors within the cable.
Single Conductor:
Connect one lead to the conductor and the other lead to earth
ground via screwdriver.
5
Wireless Connectivity
