AWH 64G-0232-T datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> AWH 64G-0232-T

Preview

AWH 64G-0232-T: DescriptionCONN HEADER 64POS VERT LONG GOLD; CategoryThe connector; File Size175KB，1 Pages; ManufacturerASSMANN WSW components; Environmental Compliance

Download Datasheet Parametric View All

AWH 64G-0232-T Overview

CONN HEADER 64POS VERT LONG GOLD

AWH 64G-0232-T Parametric

Parameter Name	Attribute value
Connector type	Connector
Contact type	Male pin
Spacing - Mating	0.100"（2.54mm）
Number of pins	64
Number of rows	2
Line spacing - patching	0.100"（2.54mm）
Number of pins loaded	all
style	Board to cable/wire
shield	Covered - 4 walls
Installation type	Through hole
Termination	welding
Fastening type	Lock/eject hook, long
Contact Length - Mating	-
Contact length - terminal	0.130"（3.30mm）
Overall contact length	-
Insulation height	0.669"（17.00mm）
Contact shape	Square
Contact surface treatment - mating	gold
Contact Surface Treatment Thickness - Mating	flash memory
Contact Surface Preparation - Column	tin
Contact material	brass
Insulation Materials	Polybutylene terephthalate (PBT), glass fiber reinforced
characteristic	keyway
Operating temperature	-40°C ~ 105°C
Intrusion protection	-
Material flammability rating	UL94 V-0
Insulation color	grey
Rated current	3A
Rated voltage	-
Joint stack height	-
Contact Surface Treatment Thickness - Column	-
application	-

Preview

Download Datasheet

View All

1

4

A

10

2

3

5

6

7

NOTES:

B

C

12

Recommended P.C.B Layout(Top Side)

(PCB BOARD TOLERANCE±0.05)

MATERIAL

1.Insulator Material:PBT+30%G.F,(UL94V-0), Grey

2.Contact Material : Brass

3.Contact Plating : Gold Flash / Tin or Full Tinned

Over Ni

ELECTRICAL

1.Current Rating : 3.0AMP

2.Withstand Voltage : 1000V AC/minute

3.Contact Resistance : 20mΩ max

4.Insulation Resistance: 1000MΩ min

ENVIRONMENTAL

7

1.Operation Temperature: -40°C to +105°C

2.Soldering Temperature:235°C±5°C/5s±1s

3.Packing : Tray

4.No side slot "A" and "B" from 6 to 16 pin

No side slot "A" from 18 to 58 pin

Ordering Information

A

B

C

AWH xxG-0xx2-T

3

D

5

12

No. of Contacts

06 08

2: Gold Flash

10 12

/Tinned

14 16

5: Full Tinned

18 20

24 26

30 34

40 50

60 64

Latch Type

0(w/o latch)

2(with short latch)

3(with long latch)

D

4

E

Dimension L

4

5

E

8

F

Long Latch

without Latch

Short Latch

with short Latch

with long Latch

F

Scale

Free

12

TOLERANCE

X.X

X.XX

11

Update the dimension

Add the dimension

06.04.2017

29.04.2015

Winnie

Drawn

Date

25.01.2006

G

9

RoHS compliant

Unit: mm

Name

Customer-No.

Alex

±0.40

±0.25

10

X.XXX ±0.15

Angle

9

G

Add special PCB layout

Add UL file no.

13.10.2014

12.12.2013

Ray

Amy

Approved

06.04.2017

Winnie

ASSMANN WSW-No.

AWH xxG-0xx2-T

±

3°

8

7

Id.

Add the Fulled Tinned Version

Update

Modification

11.11.2013

30.08.2013

Date

Winnie

Name

Drawing-No.

H

1

2

ASS 2310 CO

rev12

H

3

4

5

Replace

Sheet
