BMD-330
Bluetooth 5
Overview
Rigado’s BMD-330 is a powerful, highly flexible, ultra-low power
Bluetooth 5 module based on the nRF52810 SoC from Nordic
Semiconductor. Featuring a common footprint, the BMD-330
completes Rigado’s BMD-300
Series lineup with an optimized
peripheral set that is attractive for a wide range of cost-sensitive
applications.
The BMD-330 provides a complete RF solution allowing faster time-to-
market with reduced development cost and provides full use of the
nRF52810’s capabilities and peripherals. With an internal DC-DC
converter and intelligent power control the BMD-330 provides class-
leading power efficiency, enabling ultra-low power sensitive
applications. Carrying FCC, IC and CE certifications and Bluetooth
qualification, the BMD-330 is ready to implement right away.
Key Features
•
•
•
•
Supports the key Bluetooth 5 features of high throughput and increased broadcast capacity
Powerful & ultra-efficient 64MHz 32-bit ARM® Cortex™
M4
CPU and 192kB flash & 24kB RAM
Highly flexible GPIO & a strong digital and analog peripheral set that can interact without the CPU
Bluetooth qualified, FCC & IC certified, CE compliant
Quick Specifications
•
•
•
•
•
•
•
•
Supply: 1.7V
–
3.6V
TX Power: +4dBm, 0 dBm @ 4.6mA
Rx Sensitivity: -96 dBm @ 4.6mA
Pins: 32 GPIO
Interfaces: UART / I2C / SPI / PWM
PDM / ADC
Memory: 192kB Flash / 24kB RAM
Dimensions: 14.0 x 9.8 x 1.9mm
Operating Temp: -40°C to +85°C
Applications
•
•
•
•
•
•
•
•
Network Connectivity
processor
Smart RF Remotes
App-cessories
iBeacons™
/ Proximity
•
•
•
•
•
•
Fitness / Sports
Smart Toys
Connected Appliances
Lighting Products
Low-Power Sensor Networks
Home & Building
Automation
Key Fobs/Wrist Watches
Interactive Entertainment
Devices
Remote / Gaming Controls
AirFuel Wireless Chargers
www.rigado.com
3950 Fairview Industrial Dr SE Suite 100 Salem, Oregon 97302 USA
1.866.6RIGADO | +1 971.208.9870 | modules @rigado.com
BMD-330
Bluetooth 5
Block Diagram
BMD-330 Module
nRF52810
192kB
Flash
24
kB RAM
SWD Debug &
Programming
Accel Address
Resolver
SoftDevices
AES ECB
AES CCM Mode
Encryption
ARM Cortex-M4
@ 64MHz
Cloc k
Management
2.4GHz Radio
Multi-protocol
Mat chi ng
Network
The BMD-330 fully supports Nordic Semiconductor RF
protocol stacks known as SoftDevices. They integrate a
Bluetooth 5 LE controller and host, and provide a full and
flexible API for building Bluetooth low energy technology
System on Chip (SoC) solutions.
Balun
Real Time
Counter x2
Timer x3
Random Number
Gen
Watchdog
Timer
Programmable
Peripheral
Interconnect
Temperature
Sensor
Low Power
Comparator
General
Purpose
Comparator
Antenna
GPIO Task
Event Blocks
UART
Quadrature
Decoder
Evaluation Kit
The BMD-330 evaluation kit provides a great starting point
for Bluetooth 5 Low Energy projects. It is designed for ease
of use while still providing full access to the features of the
BMD-330. The built-in USB programmer allows for easy
programming and configuration. All the I/O are accessible
and Arduino R3 form factor connectors support plug-and-
play accessory shields.
Core LDO
TWI
Master
TWI Slave
SPI
Master
SPI Slave
DC/DC Buck
Regulator
4ch P WM
PDM
8-ch 12-bit
ADC
DC-DC
Inductor
Bulk
Capacitors
Decoupling
Capacitors
GPIO x32
(Analog x8)
32 MHz
Crystal
Specifications
General
Operating Temperature
Storage Temperature
Physical Dimensions
Operating Supply
Material
MAC Address
2.4 GHz Transceiver
SoftDevices
Frequency
Modulations
Transmit power
Receiver sensitivity
RSSI
Antenna
Approvals
FCC
IC
CE
-40°C to +85°C
-40°C to +125°C
14.0 x 9.8 x 1.9mm
1.7V to 3.6V
RoHS compliant
Unique MAC address provided (in flash & on label)
Bluetooth 5 LE Concurrent Peripheral / Central (S132)
Bluetooth 5 LE Peripheral (112)
2.360GHz to 2.500GHz
GFSK at 1 Mbps (LE mode), 2 Mbps data rates
+4 dBm to -20 dBm (4 dB steps), -40 dBm whisper mode
-96 dBm (LE mode)
1 dB resolution
Integrated antenna
FCC part 15 modular qualification
–
FCC ID: 2AA9B09
Industry Canada RSS-210 modular qualification
–
IC: 12208A-09
EN 301 489-1 V2.1.1
EN 301 489-17 V3.1.1
EN 300 328 V2.1.1
AS/NZS 4268 :2012+AMDT 1:2013, Short range devices
BT5 RF-PHY Component (Tested)
–
DID: D037298 QDID: 101625
Power Consumption
Radio - Tx
7.0mA @ +4dBm, 4.6mA @ 0dBm
Radio - Rx
4.6mA @ 1Mbps (Bluetooth low energy technology mode)
CPU - running
37.5µA/MHz running from flash, 2.4mA @ 64MHz
32.8µA/MHz running from RAM, 2.1mA @ 64MHz
CPU - off/idle
1.3µA in ON mode, with RTC
0.8µA in ON mode, all blocks IDLE
0.5µA in OFF mode, full 24kB RAM retention
Peripherals
UART
SPI Master
SPI Slave
TWI (I2C) Master
TWI (I2C) Slave
PDM
ADC
PWM
GP Comparator
Temp. Sensor
GPIO
Timers
1 block. 1200 baud to 1M baud, parity, CTS & RTS support
1 blocks. 125kHz to 8Mhz clock rates
1 blocks. 125kHz to 8Mhz clock rates
1 blocks. 100kHz to 400kHz clock rates
1 blocks. 100kHz to 400kHz clock rates
1 block. 2 microphones (left/right) 16kHz sample rate, 16-bit
8-ch, 12-bit @ 200ksps
1 block, 4 channels each.
8-ch, VDD & internal ref, 64 levels
Internal, -40°C to 85°C, +/- 4°C, 0.25°C resolution
Input High: 0.7 x VDD, Input Low: 0.3
x VDD, 13kΩ pull-up/pull-down
3 x 32-bit timers and 2x 24-bit RTC with 12-bit prescaler, watchdog timer
Australia, New Zealand
Bluetooth
Design Services
Ordering Information
•
•
Order a Development Kit
Contact Us
for pricing and ordering info
Description
BMD-330 module, nRF52840-QIAA, integrated antenna
BMD-330 Evaluation Kit with Segger programmer
Part Number
BMD-330-A-R
BMD-330-A-EVAL
Rigado has an experienced team of software, electrical, and mechanical
engineers that provide solutions to today’s
technological challenges.
Whether you need a network of industrial sensors, or a complete
product ready for mass production; Rigado can turn your ideas into
reality.
DeviceOps
TM
Rigado DeviceOps is a cloud-based platform for device monitoring and
secure firmware updates at scale
•
Easily track active devices & firmware versions
•
Identify & define groups of devices as targets for updates
•
Upload new firmware and create rules for distribution
•
Rollout updates with configurable tiers & fail-safe controls
•
Leverage secure connections that scale to support millions
of end-node devices
Availability Information
•
•
Status: Production
Modules will be available through Digi-Key, Arrow, Future,
and Mouser
www.rigado.com
3950 Fairview Industrial Dr SE Suite 100 Salem, Oregon 97302 USA
1.866.6RIGADO | +1 971.208.9870 | modules @rigado.com
