1W005GM
THRU
1W10GM
Single Phase 1.0 AMP. Glass Passivated Bridge Rectifiers
Voltage Range
50 to 1000 Volts
Current
1.0 Ampere
Features
UL Recognized File # E-96005
Glass passivated junction
Surge overload ratings to 30 amperes
peak
Ideal for printed circuit board
Reliable low cost construction technique
results in inexpensive product
High temperature soldering guaranteed:
260℃/ 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs. ( 2.3 Kg ) tension
WOB
Mechanical Data
Cases: Molded plastic
Lead: Solder plated
Polarity: As marked
Weight: 1.10 grams
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25℃ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
1W
1W
Symbol
1W
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
= 50℃
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 1.0A
Maximum DC Reverse Current @ T
A
=25℃
at Rated DC Blocking Voltage @ T
A
=125℃
Typical Thermal Resistance (Note)
Operating Temperature Range
Storage Temperature Range
1W
1W
1W
1W
005GM
01GM 02GM 04GM 06GM 08GM 10GM
Units
V
V
V
A
A
V
uA
uA
℃/W
℃
℃
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
R
θ
JA
R
θ
JL
T
J
50
35
50
100
70
100
200
140
200
400
280
400
1.0
30
1.0
600
420
600
800 1000
560 700
800 1000
T
STG
Note: Thermal resistance from Junction to Ambient and from Junction to Lead Mounted on P.C.B.
with 0.2” x 0.2” (5mm x 5mm) Copper Pads.
10
500
36
13
-55 to +150
-55 to +150
- 698 -
RATINGS AND CHARACTERISTIC CURVES (1W005GM THRU 1W10GM)
FIG.1- MAXIMUM NON-REPETITIVE FORWARD SURGE
CURRENT PER BRIDGE ELEMENT
50
FIG.2- MAXIMUM FORWARD CURRENT DERATING
CURVE
1.6
PEAK FORWARD SURGE CURRENT. (A)
40
AVERAGE FORWARD CURRENT. (A)
1
2
10
20
40
60
100
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
30
20
10
0
20
40
NUMBER OF CYCLES AT 60Hz
120
80
100
60
o
AMBIENT TEMPERATURE. ( C)
140
160
FIG.3- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER BRIDGE ELEMENT
20
10
FIG.4- TYPICAL REVERSE CHARACTERISTICS
PER BRIDGE ELEMENT
10
INSTANTANEOUS FORWARD CURRENT. (A)
INSTANTANEOUS REVERSE CURRENT. ( A)
Tj=100
0
C
1
1
Tj=25
o
C
Pulse Width=300 s
1% Duty Cycle
0.1
0.1
Tj=25
0
C
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
0.01
0
20
40
60
80
100
120
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
140
FORWARD VOLTAGE. (V)
- 699 -
