ADJD-xMxx
High Power Light Strip, Ring & Round
Data Sheet
Description
Avago’s Light Strip, Ring & Round Power LEDs range of
products offers a series of LEDs which provides better life-
time robustness and reliability compared to the conven-
tional light sources. They are mounted on a metal-core
PCB and thereby making it easier for thermal manage-
ment. The wide radiation pattern of the Line Power LED
makes it an ideal light source to illuminate a wide area.
Features
x
Available in Cool White and Warm White color.
x
Various options with different number of LEDs on
MCPCB to meet different lighting output requirement
x
Energy efficient
x
Exposed pad for excellent heat transfer
x
Integrated heat sink to simplify thermal management
design for efficient heat dissipation
x
Long operation life.
x
Wide viewing angle.
x
Silicone encapsulation
x
Ease of mechanical mounting
x
Plug & Play assembly for ease of installation
x
Lead free and ROHS compliant
Applications
x
Reading light
x
Architectural lighting
x
Decorative lighting
x
Backlighting
x
Task lighting
x
Safety / Emergency lighting
x
Illumination in vending machine
x
Refrigeration lighting
x
Retail lighting
x
Illumination for machine vision equipment
Specifications
x
InGaN technology
x
Smooth wide radiation pattern
Device Selection Guide (T
J
= 25°C)
[1]
Module
Type
Luminous Flux, Φv
[2,3]
(lm)
Color
No. of LEDs
3
3
Cool White
4
6
9
12
Strip
3
3
Warm White
4
6
9
12
Round
Ring
Round
Ring
Warm White
Cool White
7
8
7
8
Test
Current
Max.
(mA)
Part Number
ADJD-WM00
ADJD-WM01
ADJD-WM10
ADJD-WM21
ADJD-WM30
ADJD-WM40
ADJD-YM00
ADJD-YM01
ADJD-YM10
ADJD-YM21
ADJD-YM30
ADJD-YM40
ADJD-WMR0
ADJD-WMR3
ADJD-YMR0
ADJD-YMR3
Min.
Typ.
Dice
Technology
56.0
80.0
124.0
350
InGaN
56.0
70.0
95.0
350
InGaN
56.0
56.0
80.0
70.0
124.0
95.0
350
350
InGaN
InGaN
Notes:
1. Applicable to a single unit of LED only. Data are based on ASMT-Mxx4 component level device only.
2.
I
V
is the total luminous flux output as measured with an integrating sphere at 25ms mono pulse condition.
3. Flux tolerance is ±10 %.
Part Numbering System
ADJD – x
1
M x
2
x
3
– N x
4
x
5
x
6
x
7
Packaging Option
x
2
x
3
Table 1.
No. of
LEDs
3
3
4
6
9
12
7
8
Module
Type
Strip
Strip
Strip
Strip
Strip
Strip
Round
Ring
Resistor
No
Yes
No
Yes
No
No
No
No
Driving
Condition
Current
Voltage
Current
Voltage
Current
Current
Current
Current
Color Bin Selection
Maximum Flux Bin Selection
Minimum Flux Bin Selection
Please refer to Table 1
Color
W - Cool White
Y - Warm White
Note:
1. Please refer to Page 10 for selection details.
00
01
10
21
30
40
R0
R3
4
Absolute Maximum Ratings at T
A
= 25°C
Parameter
DC Forward Current
Input Voltage
[2]
Operating Ambient Temperature Range
Storage Temperature Range
Note:
1.DC forward current.
2.Input Voltage only applicable for ADJD-xM01 and ADJD-xM21.
[1]
ADJD-
xM00
350
xM10
350
xMR0
350
xM40
700
xMR3
700
xM30
1050
xM01
12
xM21
12
Units
mA
V
°C
°C
-40 to +85
-40 to +100
Optical Characteristics at 350 mA (T
J
= 25°C)
[1]
Correlated Color
Temperature, CCT
(Kelvin)
Color
Min
Max
Viewing Angle 2θ½
[2]
(Degrees)
Typ
Luminous Efficiency
(lm/W)
Typ
Part Number
ADJD-WM00
ADJD-WM01
ADJD-WM10
ADJD-WM21
ADJD-WM30
ADJD-WM40
ADJD-WMR0
ADJD-WMR3
ADJD-YM00
ADJD-YM01
ADJD-YM10
ADJD-YM21
ADJD-YM30
ADJD-YM40
ADJD-YMR0
ADJD-YMR3
No. of
LEDs
3
3
4
6
9
12
7
8
3
3
4
6
9
12
7
8
Cool White
4000
10000
110
65
Warm White
2600
4000
110
57
Notes:
1. Applicable to a single unit of LED only. Data are based on ASMT-Mxx4 component level device only.
2.
T½
is the off-axis angle where the luminous intensity is ½ the peak intensity.
Electrical Characteristic at 350 mA (T
J
= 25 °C)
[1]
Forward Voltage V
F
(Volts)
Dice Type
InGaN
Input Voltage V
in [2]
(Volts)
Typ.
3.5
Min.
2.8
Max.
4.0
Typ.
10.2
Max.
12.0
Notes:
1. Applicable to a single unit of LED only. Data are based on ASMT-Mxx4 component level device only.
2. Input Voltage only applicable for ADJD-xM01 and ADJD-xM21.
5
