Ground modular terminal block - UT 35-PE/S - 3215928
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Ground modular terminal block, with screwfix, Connection method: Screw connection, Cross section: 1.5
mm² - 35 mm², AWG: 16 - 2, Width: 16 mm, Color: green-yellow, Mounting type: NS 35/7,5, NS 35/15
The figure shows a similar product
Key Commercial Data
Packing unit
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 STK
86.667 g
85369010
China
Technical data
General
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Open side panel
Terminal block mounting
Oscillation, broadband noise test result
1
2
1
35 mm²
green-yellow
PA
V0
8 kV
3
III
I
No
2.5 Nm ... 3 Nm (PE foot with mounting screw, M5)
Test passed
09/01/2016 Page 1 / 10
https://www.phoenixcontact.com/us/products/3215928
Ground modular terminal block - UT 35-PE/S - 3215928
Technical data
General
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
Acceleration
Test duration per axis
Test directions
Shock test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Relative insulation material temperature index (Elec., UL 746 B)
Static insulating material application in cold
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 1, class B, body mounted
f
1
= 5 Hz to f
2
= 150 Hz
1.857 (m/s ) /Hz
0,8 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
5g
30 ms
3
X-, Y- and Z-axis (pos. and neg.)
130 °C
-60 °C
2 2
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 130 °C
Dimensions
Width
End cover width
Length
Height NS 35/7,5
Height NS 35/15
16 mm
2.2 mm
60.2 mm
65.7 mm
73.2 mm
Connection data
Note
Connection method
Connection in acc. with standard
Note
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Please observe the current carrying capacity of the DIN rails.
Screw connection
IEC 60947-7-2
Note: Product releases, connection cross sections and notes on
connecting aluminum cables can be found in the download area.
1.5 mm²
35 mm²
16
2
1.5 mm²
35 mm²
16
09/01/2016 Page 2 / 10
https://www.phoenixcontact.com/us/products/3215928
Ground modular terminal block - UT 35-PE/S - 3215928
Technical data
Connection data
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2
1.5 mm²
35 mm²
1.5 mm²
35 mm²
1.5 mm²
16 mm²
1.5 mm²
10 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
10 mm²
sleeve, max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
1.5 mm²
10 mm²
18 mm
B9
M6
3.2 Nm
3.7 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
IEC 60947-7-2
V0
Drawings
Circuit diagram
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
27141118
27141118
27141118
27141118
09/01/2016 Page 3 / 10
https://www.phoenixcontact.com/us/products/3215928
Ground modular terminal block - UT 35-PE/S - 3215928
Classifications
eCl@ss
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27141141
27141141
27141141
27141141
ETIM
ETIM 2.0
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000901
EC000901
EC000901
EC000901
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39121410
Approvals
Approvals
Approvals
EAC / EAC / UL Recognized / cUL Recognized / cULus Recognized
Ex Approvals
Approval details
EAC 7500651.22.01.00246
EAC EAC-Zulassung
09/01/2016 Page 4 / 10
https://www.phoenixcontact.com/us/products/3215928
Ground modular terminal block - UT 35-PE/S - 3215928
Approvals
UL Recognized
mm²/AWG/kcmil
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
16-2
600 V
C
16-2
600 V
cUL Recognized
mm²/AWG/kcmil
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
16-2
600 V
C
16-2
600 V
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
Accessories
Accessories
DIN rail
DIN rail perforated - NS 35/ 7,5 PERF 2000MM - 0801733
DIN rail, material: steel galvanized and passivated with a thick layer, perforated, height 7.5 mm, width 35 mm, length:
2000 mm
DIN rail, unperforated - NS 35/ 7,5 UNPERF 2000MM - 0801681
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35 mm, length: 2 m
