Product Family Data Sheet Rev_1.0 2017.04.12
LED Module
F-Series
Gen3
Features & Benefits
-
-
-
Efficacy improvement, 22% from Gen2 to achieve DLC premium
High lumen density linear board well-fit into industrial applications
4ft length option added
Applications
-
●
-
●
Industrial Lighting:
Warehouse, Plant, Parking lot, Etc
High ceiling Lighting
Linear, Troffer, Etc
3
Table of Contents
1.
2.
3.
4.
5.
6.
7.
APPENDIX
1.
Product Code Information
Characteristics
Structure and Assembly
Certification and Declaration
Label Structure
Packing Structure
Precautions in Handling & Use
-----------------------
-----------------------
-----------------------
-----------------------
-----------------------
-----------------------
-----------------------
3
5
11
14
15
17
18
Applicable Solid Wires
-----------------------
19
4
1. Product Code Information
- LT-F284B
Nominal CCT (K)
3000K
3500K
4000K
5000K
SEC Code
SI-B8V261280WW
SI-B8U261280WW
SI-B8T261280WW
SI-B8R261280WW
- LT-F562B
Nominal CCT (K)
3000K
3500K
4000K
5000K
SEC Code
SI-B8V261560WW
SI-B8U261560WW
SI-B8T261560WW
SI-B8R261560WW
- LT-F564B
Nominal CCT (K)
3000K
3500K
4000K
5000K
SEC Code
SI-B8V521560WW
SI-B8U521560WW
SI-B8T521560WW
SI-B8R521560WW
5
- LT-FB22B
Nominal CCT (K)
3000K
3500K
4000K
5000K
SEC Code
SI-B8V521B20WW
SI-B8U521B20WW
SI-B8T521B20WW
SI-B8R521B20WW
- LT-FB24B
Nominal CCT (K)
3000K
3500K
4000K
5000K
SEC Code
SI-B8VZ91B20WW
SI-B8UZ91B20WW
SI-B8TZ91B20WW
SI-B8RZ91B20WW
6
2. Characteristics
a) Maximum Rating
Item
Rated Lifetime
Ingress Protection (IP)
Ambient / Operating Temperature (t
amb
)
Storage Temperature
Rating
>50,000
no rating
-30 ~ +55
-30 ~ +80
Unit
hour
-
ºC
ºC
Remark
L70B50
b) Electro-Optical Characteristics
- LT-F284B
Item
Nom. CCT
(K)
3000
3500
Luminous Flux (Φ
v
)
4000
5000
3000
3500
Luminous Efficacy
4000
5000
3000
3500
CCT
4000
5000
Color Rendering Index (Ra)
Operating Current (I
f
)
Operating Voltage (V
f
)
Power Consumption
-
-
-
-
3809
4798
80
-
21.9
24.5
3955
4984
-
1120
23.0
25.8
4110
5177
-
1800
24.2
27.1
-
mA
Vdc
W
Integrating Sphere
-
I
f
= 1120mA
t
p
= 65ºC
157
162
2961
3340
175
181
3050
3454
194
201
3145
3577
K
Mac Adam 3 step
4050
4185
151
154
4500
4650
168
171
5000
5165
187
190
lm/W
I
f
= 1120mA
t
p
= 65ºC
Min
3900
3960
Typ.
4335
4400
Rating
Max
4815
4890
lm
Unit
Remark
Notes:
1)
2)
3)
t
p
: temperature at which performance is specified; measured at “Tc point”.
Samsung maintains a measurement tolerance of : Luminous flux: ±7 %, CRI: ±3.0, Voltage: ±0.3 V, Power Consumption:
±0.3W
Measurement tolerance of the color coordinates is ± 0.005
