SMT POWER INDUCTORS
Unshielded Drum Core - P0751NL/52NL Series
Height:
5.5mm Max
Footprint:
13.0mm x 9.4mm Max
Current Rating:
up to 6.8A
Inductance Range:
1.0µH to 1000µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
6,7
Number
P0751.102NL
P0751.152NL
P0751.222NL
P0751.332NL
P0751.472NL
P0751.682NL
P0751.103NL
P0751.153NL
P0751.223NL
P0751.333NL
P0751.473NL
P0751.683NL
P0752.104NL
P0752.154NL
P0752.224NL
P0752.334NL
P0752.474NL
P0752.684NL
P0752.105NL
Inductance
@ I
PK
A
DC
(µH ± 20%)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
Irated
5
(A)
6.8
6.4
6.1
5.4
4.8
4.4
3.8
3.0
2.6
2.0
1.6
1.4
1.2
1.0
0.8
0.6
0.5
0.4
0.3
DCR (MAX)
(mΩ)
10
12
15
18
33
44
50
55
114
120
168
240
380
570
840
1020
1460
2170
3300
Saturation Current
(A) @
25°C
9.0
8.0
7.0
6.4
5.4
4.6
3.8
3.0
2.6
2.0
1.6
1.4
1.2
1.0
0.8
0.6
0.5
0.4
0.3
Heating Current
(A)
6.8
6.4
6.1
5.4
4.8
4.4
3.9
3.1
2.7
2.1
1.8
1.5
1.3
1.0
0.8
0.6
0.5
0.4
0.3
NOTES:
1. The temperature of the component (ambient plus temperature
rise) must be within the specified operating temperature range.
2. Inductance tested at 100kHz, 10mV
RMS
3. Inductance drop = 10% typical at the saturation current
4.
ΔT
= 15°C rise typical at the heating current
5. The rated current is the lower of the saturation or heating current
6. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to the part number
(i.e. P0751.102NL becomes P0751.102NLT). Pulse complies to industry standard tape and
reel specification EIA481.
7. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed parts are not
necessarily RoHS compliant, but are electrically and mechanically equivalent to NL versions.
If a part number does not have the "NL" suffix, but an RoHS compliant version is required,
please contact Pulse for availability.
Mechanical
SUGGESTED PAD LAYOUT
.110
2,79
.115
2,92
.290
7,37
.370 MAX
9,40
.211
5,36
Schematic
XXX
.510 MAX
12,95
1
.215
5,46
MAX
2
.004/0,10
Weight
. . . . . . . . 0.8 grams
Tape & Reel
. . . . . . 800/reel
.520
13,21
.945
± .012
24,00
± 0,30
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
TAPE & REEL LAYOUT
.380
9,65
.472
12,00
USER DIRECTION OF FEED
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
18
SPM2007 (11/07)
