UltraGuard Series
ESD Protection for Low Leakage Requirements
GENERAL DESCRIPTION
Faster semiconductor clock speeds and an increasing reliance on batteries as power
sources have resulted in the need for varistors that exhibit very low leakage current. The
UltraGuard (UG) Series of AVX Transient Voltage Suppressors address this problem.
The UG Series is the ideal transient protection solution for high clock speed integrated
circuit application, battery-operated device, backlit display, medical/instrument applica-
tion, low voltage power conversion circuits and power supervisory chip sets. In addition,
UltraGuard’s low leakage characteristics are also suitable for optic circuits like LDD,
SerDes, and laser diodes.
Discrete Chips
0402, 0603,
and 0805
2-Element Arrays
(0405 and 0508)
4-Element Arrays
(0612)
GENERAL
CHARACTERISTICS
• Operting Teperature: -55°C to +125°C
• Working Voltage: 3.0dc - 32Vdc
• Case Size: 0402-1206
0405 2xArray, 0508 2xArray
0612 4xArray
• Leakage: 1μA Max
• Energy: 0.02-1.2J
• Peak Current: 80-200A
• Typ Cap: 30-5000pF
FEATURES
• Bi-Directional protection
• Ultra low leakage 1uA max
• Multi-strike capability
• Single, 2 and 4 element components
• Compact footprint
• EMI/RFI filtering
APPLICATIONS
• Battery operated devices
• High clock speed IC
• Low voltage power conversion
• Power supervisory chip sets
• Optic circuits (LDD, SerDes
• Laser diodes
• Any circuit with low leakage
requirements
HOW TO ORDER
VC
Surface
Mount Chip
UG
Series
Low
Leakage
Series
04
Case Size
04 = 0402
06 = 0603
08 = 0805
12 = 1206
0180
Maximum
Working
Voltage
0030 = 3.0V
DC
0050 = 5.0V
DC
0075 = 7.5V
DC
0100 = 10.0V
DC
0150 = 15.0V
DC
0180 = 18.0V
DC
0320 = 32.0V
DC
L
Capacitance
L = Low
H = High
1
No. of
Elements
W
Packaging
(pieces per reel)
D = 1,000 (7" reel)
R = 4,000 (7" reel)
T = 10,000 (13" reel)
W = 10,000 (7" reel, 0402 only)
P
Termination
Finish
P = Ni/Sn
(Plated)
MG
Array
UG
Series
Low
Leakage
Series
06
Case Size
04 = 0405
05 = 0508
06 = 0612
0150
Maximum
Working
Voltage
0030 = 3.0V
DC
0050 = 5.0V
DC
0075 = 7.5V
DC
0100 = 10.0V
DC
0150 = 15.0V
DC
L
Capacitance
L = Low
H = High
4
No. of
Elements
2 = 2 Elements
4 = 4 Elements
W
Packaging
(pieces per reel)
D = 1,000 (7" reel)
R = 4,000 (7" reel)
T = 10,000 (13" reel)
P
Termination
Finish
P = Ni/Sn
(Plated)
36
UltraGuard Series
ESD Protection for Low Leakage Requirements
AVX Part Number
MGUG040030L2 _ _
MGUG050030L2 _ _
MGUG060030L4 _ _
VCUG040030L1 _ _
VCUG060030L1 _ _
VCUG080030H1 _ _
VCUG080030L1 _ _
VCUG120030H1 _ _
VCUG120030L1 _ _
MGUG040050L2 _ _
MGUG050050L2 _ _
MGUG060050L4 _ _
VCUG040050L1 _ _
VCUG060050L1 _ _
VCUG080050L1 _ _
VCUG120050H1 _ _
VCUG120050L1 _ _
MGUG040075L2 _ _
MGUG050075L2 _ _
MGUG060075L4 _ _
VCUG040075L1 _ _
VCUG060075L1 _ _
VCUG080075H1 _ _
VCUG080075L1 _ _
VCUG120075H1 _ _
VCUG120075L1 _ _
MGUG040100L2 _ _
MGUG050100L2 _ _
MGUG060100L4 _ _
VCUG040100L1 _ _
VCUG060100L1 _ _
VCUG080100H1 _ _
VCUG080100L1 _ _
VCUG120100H1 _ _
VCUG120100L1 _ _
MGUG040150L2 _ _
MGUG050150L2 _ _
MGUG060150L4 _ _
VCUG040150L1 _ _
VCUG060150L1 _ _
VCUG080150H1 _ _
VCUG080150L1 _ _
VCUG120150H1 _ _
VCUG040180L1 _ _
VCUG080320L1 _ _
V
W
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10
10
10
10
10
10
10
10
10
15
15
15
15
15
15
15
15
18
32
V
W
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
2.3
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
7.1
11
11
11
11
11
11
11
11
14
22
V
B
(Min)
6.8
17.2
17.2
6.8
6.8
6.8
6.8
6.8
6.8
20
17.2
17.2
10.8
10.8
10.8
16.3
16.3
20
17.2
17.2
16.3
16.3
16.3
16.3
16.3
16.3
20
23
23
23
23
23
23
23
23
20
20
20
25
31.1
31.1
31.1
31.1
28
42.3
V
C
18
32
32
18
18
18
18
18
18
50
32
32
22
22
22
32
32
50
32
32
32
32
32
32
32
32
50
42
42
42
42
42
42
42
42
50
50
50
50
60
60
60
60
55
77
I
VC
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
I
L
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
E
T
0.05
0.1
0.1
0.05
0.1
0.3
0.1
0.4
0.1
0.02
0.1
0.1
0.05
0.1
0.1
0.4
0.1
0.02
0.1
0.1
0.05
0.1
0.3
0.1
0.4
0.1
0.02
0.1
0.1
0.05
0.1
0.3
0.1
0.4
0.1
0.02
0.1
0.05
0.02
0.1
0.3
0.1
0.4
0.05
0.1
I
P
15
30
30
20
30
120
40
150
40
15
30
30
20
30
40
150
40
15
30
30
20
30
120
40
150
40
15
30
15
20
30
100
30
150
30
15
20
20
15
30
100
30
120
10
40
Cap
300
425
425
175
750
3000
1100
3000
1200
40
425
425
175
550
750
1050
600
40
425
425
85
350
900
325
1050
600
40
225
120
65
150
550
225
900
350
50
50
75
40
155
250
120
500
30
50
Freq
M
M
M
M
K
K
K
K
K
M
M
M
M
K
K
K
K
M
M
M
M
K
K
K
K
K
M
M
M
M
K
K
K
K
K
M
M
M
M
K
K
K
K
M
M
Case
0405
0508
0612
0402
0603
0805
0805
1206
1206
0405
0508
0612
0402
0603
0805
1206
1206
0405
0508
0612
0402
0603
0805
0805
1206
1206
0405
0508
0612
0402
0603
0805
0805
1206
1206
0405
0508
0612
0402
0603
0805
0805
1206
0402
0805
Elements
2
2
4
1
1
1
1
1
1
2
2
4
1
1
1
1
1
2
2
4
1
1
1
1
1
1
2
2
4
1
1
1
1
1
1
2
2
4
1
1
1
1
1
1
1
Termination Finish Code
Packaging Code
V
CIR
(DC)
V
CIR
(AC)
Cap Req
I
L
Cap
Freq
DC Circuit Voltage (V)
AC Circuit Voltage (V)
Standard or Low
Maximum Leakage Current at the Circuit Voltage (μA)
Typical Capacitance (pF) @ frequency specified and 0.5 Vrms
Frequency at which capacitance is measured (K = 1kHz, M = 1MHz)
37
UltraGuard Series
ESD Protection for Low Leakage Requirements
PHYSICAL DIMENSIONS
0402 Discrete
Length
Width
Thickness
Term Band Width
1.00 ±0.10 (0.040 ±0.004)
0.50 ±0.10 (0.020 ±0.004)
0.60 Max. (0.024 Max.)
0.25 ±0.15 (0.010 ±0.006)
mm (inches)
0603 Discrete
1.60 ±0.15 (0.063 ±0.006)
0.80 ±0.15 (0.032 ±0.006)
0.90 Max. (0.035 Max.)
0.35 ±0.15 (0.014 ±0.006)
0805 Discrete
2.01 ±0.20 (0.079 ±0.008)
1.25 ±0.20 (0.049 ±0.008)
1.02 Max. (0.040 Max.)
0.71 Max. (0.028 Max.)
0405 Array
Length
Width
Thickness
Term Band Width
1.00 ±0.15 (0.039 ±0.006)
1.37 ±0.15 (0.054 ±0.006)
0.66 Max. (0.026 Max.)
0.36 ±0.10 (0.014 ±0.004)
0508 Array
1.25 ±0.20 (0.049 ±0.008)
2.01 ±0.20 (0.079 ±0.008)
1.02 Max. (0.040 Max.)
0.41 ±0.10 (0.016 ±0.004)
0612 Array
1.60 ±0.20 (0.063 ±0.008)
3.20 ±0.20 (0.126 ±0.008)
1.22 Max. (0.048 Max.)
0.41 ±0.10 (0.016 ±0.004)
SOLDER PAD DIMENSIONS
0.61
(0.024)
0.51
1.70 (0.067
)
(0.020)
0.61
(0.024)
0.89
(0.035)
2.54
(0.100)
0.76
(0.030)
0.89
(0.035)
0.51
(0.020)
mm (inches)
1.02
(0.040)
3.05
(0.120)
1.02
(0.040)
1.02
(0.040)
1.27
(0.050)
0.76
(0.030)
0402
0612 4-Element Array
A
0.89
(0.035)
0603
0805
E
D
D
E
B
1.65
(0.065)
C
2.54
(0.100)
D
0.46
(0.018)
E
0.76
(0.030)
C
A
B
C
B
A
2-Element Arrays
A
0405
0508
0.46
(0.018)
0.89
(0.035)
B
0.74
(0.029)
1.27
(0.050)
C
1.20
(0.047)
2.16
(0.085)
D
0.38
(0.015)
0.46
(0.018)
E
0.64
(0.025)
0.76
(0.030)
38
