Plugs, Jacks, Adapters
F type plugs are available in three different crimp styles: two piece with separate ferrules, one piece crimp with a short crimp
body and a one piece crimp with a long body. Also, a twist-on type for tool-less installations. Jacks for bulkhead, inline, or PC
board, and a variety of adapters are all machined brass construction.
Part Number
810A209A
810A209D
810A209G
810B209G
810D209A
810A209MV
810D209D
810D209G
810E209A
810E209D
810E209G
810A409A
810A409G
810P209A
810P209G
816B519
826B519
832A519N
830A509
831B509
832A519
843A509
845A509
851A509
F0884
Description
2 Piece Crimp Plug, Short Ferrule
2 Piece Crimp Plug, Short Ferrule
2 Piece Crimp Plug, Short Ferrule
2 Piece Crimp Plug, Long Ferrule
2 Piece Crimp Plug, Short Ferrule
4 Pc Crimp Mini Coax. Uses BD11007 Tool
1 Piece Crimp Plug, Short Ferrule
1 Piece Crimp Plug, Short Ferrule
1 Piece Crimp Plug, Long Ferrule
1 Piece Crimp Plug, Long Ferrule
1 Piece Crimp Plug, Long Ferrule
Twist-On
Twist-On
Push-On
Push-On
Male Bulkhead Receptacle. 3/8-32 THD I.D.
Bulkhead Jack, Solder Tab
Inline Female/Female W/Nut &Washer
Inline, Male/Male
Inline Female/Male Push-On
Inline Female/Female
“ T” Adapter, Female/Male/Female
“ T” Adapter, Female/Female/Female
Right Angle Adapter, Male/Female
75 Ohm Male Terminator
RG/U
Cable
6
11
59
59
6
174
11
59
6
11
59
6
59
6
59
Any
Any
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Fig.
No.
117
117
117
118
119
117A
119
119
120
120
120
121
121
122
122
130A
123
124
125
125A
126
127
128
129
130
Fig. 117
Fig. 117A
Fig. 118
Fig. 119
Fig. 120
Fig. 121
Also See Push-EZ™ Next Page
Fig. 122
Fig. 123
Fig. 124
s
Adapters & Terminators
Fig. 125
Fig. 126
Fig. 125A
Fig. 127
Fig. 128
s
This recessed male acts as a jack & allows for a
replaceable female end by using a 832A519 adapter.
Also, this can be used to accommodate any adapter with
a female F interface on one side. The other end can be
BNC, TNC, or any style available. (See adapter pages)
