Preliminary Datasheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS
General Description
The AZ75232 combines three drivers and five receiv-
ers, which conform to the EIA/TIA-232-F and ITU
v.28 standards. Each receiver converts EIA/TIA-232-F
inputs to 5-V TTL/CMOS levels and each driver con-
verts TTL/CMOS input levels into EIA/TIA-232-F
levels.
The flow-through pinout facilitates simple non-cross-
over board layout. The AZ75232 provides a one-chip
solution for the common 9-pin serial RS-232 interface
between data terminal and data communications equip-
ment.
The AZ75232 is available in SOIC-20, SSOP-20 and
TSSOP-20 packages.
AZ75232
Features
·
·
·
·
·
Single Chip with Easy Interface between UART
and Serial-Port Connector
Meet the Requirement of EIA/TIA-232-F and
ITU v.28 Standards
Designed to Support Data Rates up to 120kbit/s
3 Drivers and 5 Receivers
Flow-Through Pinout
Applications
·
·
Mother Board
Peripheral Equipment
SOIC-20
SSOP-20
TSSOP-20
Figure 1. Package Types of AZ75232
Aug. 2006 Rev. 1. 4
1
BCD Semiconductor Manufacturing Limited
Preliminary Datasheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS
Pin Configuration
M/GS/G Package
(SOIC-20/SSOP-20/TSSOP-20)
AZ75232
V
DD
RA1
RA2
RA3
DY1
DY2
RA4
DY3
RA5
V
SS
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
CC
RY1
RY2
RY3
DA1
DA2
RY4
DA3
RY5
GND
Figure 2. Pin Configuration of AZ75232 (Top View)
Pin Description
Pin
Number
1
2
3
4
5
6
7
8
9
10
Pin
Name
V
DD
RA1
RA2
RA3
DY1
DY2
RA4
DY3
RA5
V
SS
Function
Positive Supply Voltage for Driver
Receiver Input
Receiver Input
Receiver Input
Driver Output
Driver Output
Receiver Input
Driver Output
Receiver Input
Negative Supply Voltage for Driver
Pin
Number
11
12
13
14
15
16
17
18
19
20
Pin
Name
GND
RY5
DA3
RY4
DA2
DA1
RY3
RY2
RY1
V
CC
Ground
Receiver Output
Driver Input
Receiver Output
Driver Input
Driver Input
Receiver Output
Receiver Output
Receiver Output
Supply Voltage for Receiver
Function
Aug. 2006 Rev. 1. 4
2
BCD Semiconductor Manufacturing Limited
Preliminary Datasheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS
Functional Block Diagram
V
DD
1
2
RA1
3
RA2
4
RA3
5
DY1
6
DY2
7
RA4
8
DY3
9
RA5
V
SS
10
11
GND
12
RY5
13
DA3
14
RY4
15
DA2
16
DA1
17
RY3
18
RY2
20
V
CC
19
RY1
AZ75232
Figure 3. Functional Block Diagram of AZ75232
Ordering Information
AZ75232
Circuit Type
Package
M: SOIC-20
GS: SSOP-20
G: TSSOP-20
Temperature
Range
-40 to 85
o
C
-40 to 85
o
C
-40 to 85
o
C
Part Number
Tin Lead
AZ75232M
AZ75232MTR
Lead Free
AZ75232M-E1
AZ75232MTR-E1
AZ75232GS-E1
AZ75232GSTR-E1
AZ75232G-E1
AZ75232GTR-E1
-
E1: Lead Free
Blank: Tin Lead
TR: Tape and Reel
Blank: Tube
Package
Marking ID
Tin Lead
AZ75232M
AZ75232M
Lead Free
AZ75232M-E1
AZ75232M-E1
AZ75232GS-E1
AZ75232GS-E1
232GE
232GE
Packing Type
Tube
Tape & Reel
Tube
Tape & Reel
Tube
Tape & Reel
SOIC-20
SSOP-20
TSSOP-20
BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant.
Aug. 2006 Rev. 1. 4
3
BCD Semiconductor Manufacturing Limited
Preliminary Datasheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS
Absolute Maximum Ratings (Note 1)
Parameter
Symbol
V
DD
Supply Voltage
V
SS
V
CC
Input Voltage Range
V
I
Driver
Receiver
SOIC-20
Power Dissipation
(TA=25
o
C)
P
D
V
O
I
OL
T
J
T
STG
T
LEAD
SSOP-20
TSSOP-20
Driver Output Voltage Range
Receiver Low-Level Output Current
Operating Junction Temperature
Storage Temperature Range
Lead Temperature (Soldering, 10sec)
-15 to 15
20
150
-65 to 150
260
Value
15
-15
7
-15 to 7
-30 to 30
1340
1210
1100
V
mA
o
o
AZ75232
Unit
V
V
mW
C
C
o
C
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Max-
imum Ratings" for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter
Supply Voltage
Symbol
V
DD
V
SS
V
CC
High-Level Input Voltage (Driver Only)
Low-Level Input Voltage (Driver Only)
High-Level Output Current
Low-Level Output Current
Operating Temperature Range
Driver
Receiver
Driver
Receiver
V
IH
V
IL
I
OH
I
OL
T
A
-40
Min
7.5
-15
4.5
1.9
0.8
-6
-0.5
6
16
85
Max
15
-7.5
5.5
V
V
mA
mA
o
C
Unit
V
Aug. 2006 Rev. 1. 4
4
BCD Semiconductor Manufacturing Limited
Preliminary Datasheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS
Electrical Characteristics
(T
A
=25
o
C, unless otherwise specified.)
Parameter
Symbol
Conditions
Min
Typ
Max
Unit
VOLTAGE SUPPLY SECTION (V
CC
=5V, V
DD
=9V, V
SS
=-9V, unless otherwise specified)
V
DD
=9V, V
SS
=-9V
All inputs at
1.9V, no load
Supply Current from V
DD
I
DD
All inputs at
0.8V, no load
V
DD
=12V, V
SS
=-12V
V
DD
=15V, V
SS
=-15V
V
DD
=9V, V
SS
=-9V
V
DD
=12V, V
SS
=-12V
V
DD
=15V, V
SS
=-15V
V
DD
=9V, V
SS
=-9V
All inputs at
1.9V, no load
Supply Current from V
SS
I
SS
All inputs at
0.8V, no load
Supply Current from V
CC
High-Level Output Voltage
Low-Level Output Voltage
High-Level Input Current
Low-Level Input Current
High-Level Short-Circuit
Output Current
Low-Level Short-Circuit Out-
put Current
Output Resistance
I
CC
V
OH
V
OL
I
IH
I
IL
I
OS(H)
I
OS(L)
r
O
V
DD
=12V, V
SS
=-12V
V
DD
=15V, V
SS
=-15V
V
DD
=9V, V
SS
=-9V
V
DD
=12V, V
SS
=-12V
V
DD
=15V, V
SS
=-15V
All inputs at 5V, no load, V
CC
=5V
V
IL
=0.8V, R
L
=3kΩ
V
IH
=1.9V, R
L
=3kΩ
V
I
=5V
V
I
=0V
V
IL
=0.8V, V
O
=0V
V
IH
=2V, V
O
=0V
V
CC
=V
DD
=V
SS
=0, V
O
=-2Vto 2V
-4.5
4.5
300
-12
12
6
7.5
-7.5
-6
10
-1.6
-19.5
19.5
DRIVER SECTION (V
CC
=5V, V
DD
=9V, V
SS
=-9V, unless otherwise specified)
V
V
µA
mA
mA
mA
Ω
15
19
25
4.5
5.5
9
-15
-19
-25
-3.2
-3.2
-3.2
30
mA
mA
mA
AZ75232
DRIVER SECTION (V
CC
=5V, V
DD
=12V, V
SS
=-12V, unless otherwise specified)
Propagation Delay Time
Low to High Level Output
Propagation Delay Time
High to Low Level Output
Transition Time
Low to High Level Output
Transition Time
High to Low Level Output
t
PLH
t
PHL
t
TLH
R
L
=3kΩ to 7kΩ, C
L
=15pF
R
L
=3kΩ to 7kΩ, C
L
=15pF
R
L
=3kΩ to 7kΩ
C
L
=15pF
C
L
=2500pF (Note 2)
C
L
=15pF
C
L
=2500pF (Note 2)
315
75
60
1.7
40
1.5
500
175
100
2.5
75
2.5
ns
ns
ns
µs
ns
µs
t
THL
R
L
=3kΩ to 7kΩ
Aug. 2006 Rev. 1. 4
5
