FINAL ACCEPTED ORDER DATE [2010/09]
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
AXW
AXW
SERIES
FEATURES
•
Load Life : 105°C 2000 hours.
•
Body diameter of
φ
10mm to
φ
18mm with high ripple current capability.
•
This series is two classes smaller than the current MXW series.
•
RoHS compliance.
SPECIFICATIONS
Items
Category Temperature Range
Characteristics
-25∼ +105
°
C
200∼ 450V.DC
+
-
20%
Rated Voltage Range
Capacitance Tolerance
(20
°
C, 120Hz)
I
=
3 CV
Leakage Current(MAX)
(After 5 minutes application of rated voltage)
I
=Leakage
Current
(µA)
Rated Voltage
(V)
tanδ
C
=Rated
Capacitance
(µF)
(20
°
C, 120Hz)
V
=Rated
Voltage
(V)
Dissipation Factor(MAX)
200∼ 250
0.12
400
0.15
420∼ 450
0.2
(tanδ)
After applying rated voltage with rated ripple current for 2000hrs at 105
°
C, the capacitors shall meet the following requirements.
+
Within - 20% of the initial value.
Not more than 200% of the specified value.
Not more than the specified value.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Impedance Ratio(MAX)
Rated Voltage(V)
Z(-25
°
C)/Z(20
°
C)
200∼ 250
3
400∼ 450
8
(120Hz)
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Frequency(Hz)
Coefficient
60(50) 120
0.8
0.8
1.0
1.0
500
1.20
1.25
1k
1.30
1.40
10k <
=
1.40
1.50
200∼ 250WV
400∼ 450WV
PART NUMBER
AXW
Rated Voltage
Series
Rated Capacitance
Capacitance Tolerance
Option
Lead Forming
D×L
Case Size
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
AXW
(mm)
DIMENSIONS
SLEEVE
φ
d
+
-
0.5
φ
D
φ
d
F
10
12.5 14.5
0.6
5.0
2.0
16
0.8
7.5
18
F
L+α MAX
15MIN
4MIN
φ
D+0.5MAX
α
STANDARD SIZE, RATED RIPPLE CURRENT
Cap
(µF)
WV
φ
D
φ
10
10×30 0.35
10×35 0.40
10×40 0.46
φ
12.5
200
φ
14.5
φ
16
φ
18
56
68
82
100
120
150
180
220
270
330
390
470
φ
10
10×30 0.29
10×35 0.33
10×40 0.37
φ
12.5
220
φ
14.5
φ
16
φ
18
12.5×30 0.53
12.5×35 0.62
12.5×40 0.70 14.5×30 0.66
14.5×35 0.80 16×30 0.76 18×30 0.81
14.5×40 0.90 16×35 0.88 18×30 0.87
16×40 1.10 18×35 1.01
18×40 1.13
18×45 1.27
12.5×30 0.43
12.5×35 0.49
12.5×40 0.58 14.5×30 0.58
14.5×35 0.68 16×30 0.67
14.5×40 0.78 16×35 0.77 18×30 0.77
16×40 0.88 18×35 0.88
18×40 1.01
18×45 1.13
Cap
(µF)
WV
φ
D
φ
10
φ
12.5
250
φ
14.5
φ
16
φ
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
φ
10
10×30 0.21
10×35 0.24
10×40 0.28
φ
12.5
400
φ
14.5
φ
16
φ
18
10×30 0.27
10×35 0.30
10×40 0.35
12.5×30 0.40
12.5×35 0.46
12.5×40 0.53 14.5×30 0.53
14.5×35 0.62 16×30 0.62
14.5×40 0.72 16×35 0.72 18×30 0.72
16×40 0.83 18×35 0.83
18×40 0.95
18×45 1.07
12.5×30 0.32
12.5×35 0.37
12.5×40 0.42 14.5×30 0.42
14.5×35 0.48
14.5×35 0.52 16×30 0.50
16×35 0.58 18×30 0.58
16×40 0.66 18×35 0.67
18×40 0.77
18×45 0.88
Cap
(µF)
WV
φ
D
φ
10
10×30 0.17
10×35 0.20
10×40 0.23
φ
12.5
420
φ
14.5
φ
16
φ
18
15
18
22
27
33
39
47
56
68
82
100
120
φ
10
10×30 0.15
10×35 0.18
10×40 0.21
φ
12.5
450
φ
14.5
φ
16
φ
18
12.5×30 0.27
12.5×35 0.31
12.5×40 0.36 14.5×30 0.36
14.5×35 0.43 16×30 0.43
14.5×40 0.51 16×35 0.51 18×30 0.51
16×40 0.57 18×30 0.57
18×35 0.61
18×40 0.66
12.5×30 0.25
12.5×35 0.28
12.5×40 0.32 14.5×30 0.32
14.5×35 0.38 16×30 0.38
14.5×40 0.44 16×35 0.44
16×40 0.49 18×30
18×35
18×40
18×45
0.48
0.55
0.65
0.74
Please check with us about individual WV, Cap., size and dimensions.
Size
φ
D×L(mm)
Ripple Current (A r.m.s./105
°
C, 120Hz)
