217200: DescriptionFAST BLOW ELECTRIC FUSE, 5A, 250VAC, 250VDC, 50A (IR), INLINE/HOLDER; CategoryCircuit protection; File Size220KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet View All

217200 Overview

FAST BLOW ELECTRIC FUSE, 5A, 250VAC, 250VDC, 50A (IR), INLINE/HOLDER

Preview

Download Datasheet

View All

Axial Lead and Cartridge Fuses

Designed to IEC Standard

5 x 20 mm

Fast-Acting Fuse 217 Series

• Designed to International (IEC) Standards for use globally.

• Meets the IEC 60127-2, Sheet 2 specification for Fast-Acting Fuses.

• Available in Cartridge and Axial Lead Form.

• Available in ratings of 0.032 to 15 amperes.

®

ELECTRICAL CHARACTERISTICS:

% of Ampere

Rating

150%

210%

275%

400%

Ampere

Rating

.032 – 6.3

8-15

.032-15

.032 – .100

.125 – 15

.032 – .100

.125 – 6.3

8 - 15

.032 – 6.3

8-15

Opening

Time

60 minutes,

Minimum

30 minutes,

Minimum

30 minutes,

Maximum

0.01 sec.,

Min.;

.5 sec.

Max.

0.05 sec.,

Min.;

2 sec.

Max.

.003 sec.,

Min.;

0.1 sec.

Max.

.01 sec.,

Min.;

0.3 sec.

Max.

.01 sec.,

Min.;

0.4 sec.

Max.

.02 second,

Maximum

.04 second,

Maximum

1000%

ENVIRONMENTAL SPECIFICATIONS:

Operating temperature:

-55˚C to 125˚C

Thermal Shock:

MIL-STD-202F Method 107G, Test Condition B: (5

cycles –65°C to +125°C)

Vibration:

MIL-STD-202F Method 201A

Humidity:

MIL-STD-202F Method 103B, Test Condition A. high relative

humidity (95%) and elevated temperature (40°C) for 240 hours.

Salt Spray:

MIL-STD-202F Method 101D, Test Condition B

INTERRUPTING RATING:

35 amperes or 10 x rated current;

(whichever is greater) to a maximum 100 amperes @ 250VAC, unity

Power Factor.

PHYSICAL SPECIFICATIONS:

Material:

Body: Glass

ORDERING INFORMATION:

Cartridge

Catalog

Number

217.032

217.040

217.050

217.063

217.080

217.100

217.125

217.160

217.200

217.250

217.315

217.400

217.500

217.600

217.630

217.800

217

001.

217

1.25

217

01.5

217

01.6

217

002.

217

02.5

217

003.

217

3.15

217

004.

217

005.

217

06.3

217

008.

217

010.

217

015.

Ampere

Rating

.032

.040

.050

.063

.080

.100

.125

.160

.200

.250

.315

.400

.500

.600

.630

.800

1

1.25

1.5

1.6

2

2.5

3.0

3.15

4

5

6.3

8*

10*

15*

Voltage

Rating

250

Nominal

Resistance

Cold Ohms

262.2

183.2

15.20

10.45

7.890

5.697

3.820

2.525

1.700

1.233

0.880

0.277

0.207

0.200

0.190

0.120

0.096

0.070

0.056

0.053

0.042

0.033

0.024

0.022

0.016

0.014

0.009

0.007

0.006

0.004

Nominal

Melting I

2

t

A

2

Sec.

0.000060

0.000085

0.000190

0.000550

0.000828

0.00450

0.00477

0.010

0.024

0.042

0.112

0.127

0.219

0.390

0.409

0.847

1.042

2.230

4.382

4.616

5.726

9.460

17.041

17.722

29.164

42.796

62.466

198.158

217.633

607.133

Cap: Nickel Plated Brass

Leads: Tin Plated Copper

Terminal Strength

:

MIL-STD-202F Method 211A,

Test Condition A

Solderability:

Reference IEC 60127 Second Edition 2003-01 Annex A

Terminal strength: MIL-STD-202F Method 211A, Test Condition A

Product Marking:

Cap 1: current and voltage rating.

Cap 2: Agency approval markings.

Packaging:

Available in Bulk (v=5, H=100, M=1000 pcs/pkg) or on

Tape/Reel (MRET1=1000 pcs/reel).

1

w w w. l i t t e l f u s e . c o m

409
