Axial Lead and Cartridge Fuses

Designed to IEC Standard

5 x 20 mm

Fast-Acting Fuse 216 Series

• Designed to International (IEC) Standards for use globally.

• Meets the IEC 60127-2, Sheet 1 specification for Fast Acting Fuses.

• Available in Cartridge and Axial Lead Form.

• Available in ratings of 0.050 to 10 amperes.

• High breaking capacity.

ELECTRICAL CHARACTERISTICS:

% of Ampere

Rating

150%

210%

275%

Ampere

Rating

.05 – 6.3

8-16

.05 – 16

.05 – 4

5– 6.3

8-16

.05 – 6.3

8-16

.05 – 6.3

8-16

Opening

Time

60 minutes,

Minimum

30 minutes,

Minimum

30 minutes,

Maximum

0.01 sec.,

Min.;

2 sec.

Max.

0.01 sec.,

Min.;

3 sec.

Max.

0.04 sec.,

Min.;

20 sec.

Max.

.003 sec.,

Min.;

0.3 sec.

Max.

.01 sec.,

Min.;

1.0 sec.

Max.

.02 seconds,

Maximum

.03 seconds,

Maximum

ENVIRONMENTAL SPECIFICATIONS:

Operating temperature:

-55˚C to 125˚C

Thermal Shock:

MIL-STD-202F Method 107G, Test Condition B: (5

cycles –65°C to +125°C)

Vibration:

MIL-STD-202F Method 201A

Humidity:

MIL-STD-202F Method 103B, Test Condition A. high relative

humidity (95%) and elevated temperature (40°C) for 240 hours.

Salt Spray:

MIL-STD-202F Method 101D, Test Condition B

400%

1000%

INTERRUPTING RATING:

0.05 - 10A

1500A @ 250 VAC, 0.7-0.8 power factor

PHYSICAL SPECIFICATIONS:

Material:

Body: Ceramic

Cap: Nickel Plated Brass

Leads: Tin Plated Copper

Filler Sand (160mA – 10A)

Terminal Strength:

MIL-STD-202F Method 211A,

Test Condition A

Solderability:

Reference IEC 60127 Second Edition 2003-01 Annex A

ORDERING INFORMATION:

Cartridge

Catalog

Number

216.050

216.063

216.080

216.100

216.125

216.160

216.200

216.250

216.315

216.400

216.500

216.630

216.800

216

001

216

1.25

216

01.6

216

002

216

02.5

216

3.15

216

004

216

005

216

06.3

216

008

216

010

Ampere

Rating

.050

.063

.080

.100

.125

.160

.200

.250

.315

.400

.500

.630

.800

1.25

1.6

2.5

3.15

6.3

10*

Voltage

Rating

250

Nominal

Resistance

Cold Ohms

15.900

10.450

7.885

5.793

3.675

5.349

3.350

2.350

1.850

0.903

0.847

0.466

0.295

0.237

0.153

0.111

0.076

0.058

0.037

0.025

0.018

0.014

0.010

0.008

Nominal

Melting I

Sec.

0.00019

0.00054

0.00084

0.00450

0.00545

0.00576

0.00438

0.00891

0.015

0.036

0.169

0.179

0.288

0.180

0.477

1.008

1.870

2.697

6.700

14.996

27.460

56.429

64.316

154.339

Product Marking:

Cap 1: current and voltage rating.

Cap 2: Agency approval markings.

Packaging:

Available in Bulk (V=5, H=100, M=1000 pcs/pkg) or on

Tape/Reel (MRET1=1000 pcs/reel).

w w w. l i t t e l f u s e . c o m

421
