LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
AXF
AXF
SERIES
105
o
C Low profile, Snap-in Terminal Type
FEATURES
•
Load Life : 105
°
C 3000 hours, with 20mm height.
•
Smaller size with higher ripple current endurance than MXF series.
•
RoHS compliance.
SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
-40∼
+105
°
C
10∼ 100V.DC
+
- 20%(20
°
C,120Hz)
I=3
CV
(After 5 minutes application of rated voltage)
-25∼
+105
°
C
160∼ 450V.DC
Leakage Current(MAX)
I=
Leakage Current
(µ A)
V=
Rated Voltage
(V)
C=
Rated Capacitance
(µ F)
(20
°
C,120Hz)
(tanδ)
Dissipation Factor(MAX)
(V)
10 16 25 35 50 63 80 100 160
∼
420
∼
Rated Voltage
400 450
tanδ
0.55 0.50 0.45 0.40 0.35 0.30 0.25 0.20 0.15 0.20
(V)
Rated Voltage
Z(-25
°
C)/Z(20
°
C)
Z(-40
°
C)/Z(20
°
C)
10
∼
100
3
12
160
∼
250
3
-
315
∼
450
8
-
Impedance Ratio(MAX)
(120Hz)
After applying rated voltage with rated ripple current for 3000hrs at 105
°
C, the capacitors shall meet the following requirements.
Capacitance Change
Dissipation Factor
Leakage Current
+
Within - 20% of the initial value.
Not more than 200% of the specified value.
Not more than the specified value.
Endurance
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Frequency
(Hz)
60(50) 120
0.90
0.80
0.80
1.00
1.00
1.00
500
1.05
1.20
1.20
1k
1.10
1.30
1.25
10k <
=
1.15
1.50
1.40
SN
D
×
L
Case Size
10∼ 100WV
Coefficient
160∼ 250WV
315∼ 450WV
PART NUMBER
AXF
Rated Voltage
Series
Rated Capacitance
Capacitance Tolerance
Option
Terminal Code
Option
Code
PET Sleeve without plate
PVC Sleeve without plate
PVC Sleeve with plate
DIMENSIONS
SN
［4(3.5)mm½terminal type
(mm)
EFC
OOE
Blank
