2W005M - 2W10M
Single Phase 2.0 AMPS. Silicon Bridge Rectifiers
WOB
Features
UL Recognized File # E-96005
Surge overload ratings to 50 amperes peak
Ideal for printed circuit board
Reliable low cost construction technique
results in inexpensive product
High temperature soldering guaranteed:
260
o
C / 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs., ( 2.3 kg ) tension
Mechanical Data
Case: Molded plastic
Lead: Pure tin plated, Lead free.
Polarity: As marked
Weight: 1.10 grams
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
= 50
o
C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 2.0A
Maximum DC Reverse Current @ T
A
=25
o
C
at Rated DC Blocking Voltage @ T
A
=125
o
C
Symbol
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
2W
005M
50
35
50
2W 2W
01M 02M
100 200
70
140
100 200
2W
04M
400
280
400
2.0
50
1.1
2W
06M
600
420
600
2W 2W
Units
08M 10M
800 1000
V
560 700
V
800 1000
V
A
A
V
uA
uA
o
10
500
Typical Thermal resistance (Note)
R
θJA
40
R
θJL
15
Operating Temperature Range
T
J
-55 to +125
Storage Temperature Range
T
STG
-55 to +150
Note: Thermal Resistance from Junction to Ambient and from Junction to Lead at
0.375” (9.5mm) Lead Length for P.C.B. Mounting.
C/W
o
o
C
C
Version: A06
RATINGS AND CHARACTERISTIC CURVES (2W005M THRU 2W10M)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
FIG.2- TYPICAL REVERSE CHARACTERISTICS
PER BRIDGE ELEMENT
2.0
10
AVERAGE FORWARD CURRENT. (A)
INSTANTANEOUS REVERSE CURRENT. ( A)
1.5
Tj=125
0
C
1.0
1
0.5
0
20
0.1
40
80
100
60
o
AMBIENT TEMPERATURE. ( C)
120
140
50
FIG.3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT PER BRIDGE ELEMENT
Tj=25
0
C
PEAK FORWARD SURGE CURRENT. (A)
0.01
40
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
30
1000
20
600
10
JUNCTION CAPACITANCE.(pF)
FIG.4- TYPICAL JUNCTION CAPACITANCE
500
Tj=25
0
C
0
1
2
5
10
20
NUMBER OF CYCLES AT 60Hz
50
100
400
300
200
100
0
0.1
20
10
FIG.5- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER BRIDGE ELEMENT
0.5
1
2
5
10
20
50 100
200
500 800
INSTANTANEOUS FORWARD CURRENT. (A)
REVERSE VOLTAGE. (V)
Tj=25
o
C
Pulse Width=300 s
1% Duty Cycle
1
0.1
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
FORWARD VOLTAGE. (V)
Version: A06
