2W005 - 2W10
Single Phase 2.0 AMPS. Silicon Bridge Rectifiers
WOB
Features
UL Recognized File # E-96005
Surge overload ratings to 50 amperes peak
Ideal for printed circuit board
Reliable low cost construction technique
results in inexpensive product
High temperature soldering guaranteed:
260
o
C / 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs., ( 2.3 kg ) tension
Mechanical Data
Case: Molded plastic
Lead: Pure tin plated, Lead free.
Polarity: As marked
Weight: 1.10 grams
Dimensions in inches and (millimeters)
Rating at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Maximum Ratings and Electrical Characteristics
o
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
A
= 50
o
C
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated Load
(JEDEC method )
Maximum Instantaneous Forward Voltage
@ 2.0A
Maximum DC Reverse Current @ T
A
=25
o
C
at Rated DC Blocking Voltage @ T
A
=125
o
C
Symbol 2W
005
V
RRM
50
V
RMS
35
V
DC
50
I
(AV)
I
FSM
V
F
I
R
2W
01
100
70
100
2W
02
200
140
200
2W
04
400
280
400
2.0
50
1.1
2W
06
600
420
600
2W 2W
Units
10
08
800 1000
V
560 700
V
800 1000
V
A
A
V
uA
uA
o
10
500
Typical Thermal resistance (Note)
R
θJA
40
R
θJL
15
Operating Temperature Range
T
J
-55 to +125
Storage Temperature Range
T
STG
-55 to +150
Note: Thermal Resistance from Junction to Ambient and from Junction to Lead at
0.375” (9.5mm) Lead Length for P.C.B. Mounting.
C/W
o
o
C
C
Version: A06
RATINGS AND CHARACTERISTIC CURVES (2W005 THRU 2W10)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
FIG.2- TYPICAL REVERSE CHARACTERISTICS
PER BRIDGE ELEMENT
2.0
10
AVERAGE FORWARD CURRENT. (A)
INSTANTANEOUS REVERSE CURRENT. ( A)
1.5
Tj=125
0
C
1.0
1
0.5
0
20
0.1
40
80
100
60
o
AMBIENT TEMPERATURE. ( C)
120
140
50
FIG.3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT PER BRIDGE ELEMENT
Tj=25
0
C
PEAK FORWARD SURGE CURRENT. (A)
0.01
40
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
30
1000
20
600
10
JUNCTION CAPACITANCE.(pF)
FIG.4- TYPICAL JUNCTION CAPACITANCE
500
Tj=25
0
C
0
1
2
5
10
20
NUMBER OF CYCLES AT 60Hz
50
100
400
300
200
100
0
0.1
20
10
FIG.5- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER BRIDGE ELEMENT
0.5
1
2
5
10
20
50 100
200
500 800
INSTANTANEOUS FORWARD CURRENT. (A)
REVERSE VOLTAGE. (V)
Tj=25
o
C
Pulse Width=300 s
1% Duty Cycle
1
0.1
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
FORWARD VOLTAGE. (V)
Version: A06
