DF7-08S-3.96C: DescriptionBoard Connector, 8 Contact(s), 1 Row(s), Female, Socket; CategoryThe connector; File Size47KB，1 Pages; ManufacturerHirose; Websitehttp://www.hirose-connectors.com/

Download Datasheet Parametric Compare View All

DF7-08S-3.96C Overview

Board Connector, 8 Contact(s), 1 Row(s), Female, Socket

DF7-08S-3.96C Parametric

Parameter Name	Attribute value
Maker	Hirose
Reach Compliance Code	unknown
Is Samacsys	N
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	DF7
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	1
Options	GENERAL PURPOSE
Total number of contacts	8
Base Number Matches	1

Preview

Download Datasheet

View All

sSockets

Photograph shows contacts inserted

HRS No.

680-0009-2

680-0010-1

680-0011-4

680-0012-7

680-0013-0

680-0014-2

680-0015-5

680-0016-8

680-0017-0

Product No.

DF7-02S-3.96C

DF7-03S-3.96C

DF7-04S-3.96C

DF7-05S-3.96C

DF7-06S-3.96C

DF7-07S-3.96C

DF7-08S-3.96C

DF7-09S-3.96C

DF7-10S-3.96C

Number of Contacts

2

3

4

5

6

7

8

9

10

A

10.00

13.96

17.92

21.88

25.84

29.80

33.76

37.72

41.68

B

3.96

7.92

11.88

15.84

19.80

23.76

27.72

31.68

35.64

NOTE 1: Sold by the package. One package contains 100 pieces.

NOTE 2: The lock form will differ partially for odd numbers of contacts.

NOTE 3: There are no walls on the lock portion sides for 2 contacts.

* See Page 9 for retainers.

8

DF7-08S-3.96C Related Products

	DF7-08S-3.96C	DF7-02S-3.96C	DF7-03S-3.96C	DF7-04S-3.96C	DF7-05S-3.96C	DF7-06S-3.96C	DF7-07S-3.96C	DF7-09S-3.96C
Description	Board Connector, 8 Contact(s), 1 Row(s), Female, Socket	Board Connector, 2 Contact(s), 1 Row(s), Female, Socket	Board Connector, 3 Contact(s), 1 Row(s), Female, Socket	Board Connector, 4 Contact(s), 1 Row(s), Female, Socket	Board Connector, 5 Contact(s), 1 Row(s), Female, Socket	Board Connector, 6 Contact(s), 1 Row(s), Female, Socket	Board Connector, 7 Contact(s), 1 Row(s), Female, Socket	Board Connector, 9 Contact(s), 1 Row(s), Female, Socket
Maker	Hirose	Hirose	Hirose	Hirose	Hirose	Hirose	Hirose	Hirose
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Is Samacsys	N	N	N	N	N	N	N	N
Body/casing type	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	DF7	DF7	DF7	DF7	DF7	DF7	DF7	DF7
Mixed contacts	NO	NO	NO	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE
Number of rows loaded	1	1	1	1	1	1	1	1
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Total number of contacts	8	2	3	4	5	6	7	9
Base Number Matches	1	1	1	1	1	1	1	1
