Crystal unit
MHz RANGE CRYSTAL UNIT
Built-in thermistor
Product Number (please contact us
)
FA-128S : X1E000361xxxx18
FA - 128S
•Nominal
frequency range
•External
dimensions
•Overtone
order
•Applications
:
16 MHz to 54 MHz
:
2.0 × 1.6 × 0.9 mm
:
Fundamental
:
Mobile phone, Bluetooth, W-LAN
:
ISM band radio, Clock for MPU
GPS, Smart phone
Actual size
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature range
Operating temperature range
Level of drive
Frequency tolerance
Frequency versus
temperature characteristics
Load capacitance
Motional resistance (ESR)
Frequency aging
Thermistor resistance
Thermistor B constant
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
C
L
R
1
f_age
―
Specifications
16.000 MHz to 54.000 MHz
-40
°C
to +125
°C
-40
°C
to +85
°C
100
µW
Max.
±10 ×
10
±12 ×
10
-6
Conditions / Remarks
Fundamental
Please contact us about available frequencies.
Storage as single product.
Recommended: 1 to 100
µW
Please contact us about reference temperature.
*1
-6
*1
6 pF to
∞
As per table below
-6
±1 ×
10 / year Max.
Please contact us about specifications.
Please contact us for inquiries.
-30
°C
to +85
°C
Please contact us for inquiries.
Please specify.
-30
°C
to +85
°C
+25
°C,
First year
―
*1
Please contact us for available frequency tolerances as they are dependent upon the nominal frequency.
Motional resistance (ESR)
Frequency
16.0 MHz
≤
f_nom < 18.0 MHz
18.0 MHz
≤
f_nom < 20.0 MHz
20.0 MHz
≤
f_nom < 24.0 MHz
24.0 MHz
≤
f_nom < 26.0 MHz
26.0 MHz
≤
f_nom
≤
54.0 MHz
Product name
(Standard form)
FA-128S
Motional resistance
200
Ω
Max.
150
Ω
Max.
100
Ω
Max.
80
Ω
Max.
60
Ω
Max.
19.200000MHz
7.0 +10.0-10.0
-6
Model
Frequency
Load capacitance(pF)
Frequency tolerance(
×
10
,
+25
°C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
External dimensions
FA-128S
2.0±0.1
#4
#3
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
2.2
Internal connection
(TOP VIEW)
#4
#3
1.6±0.1
192 TP
O E1Y97
#1
#2
0.9 Max.
1.8
#1
#2
0.46
0.75
0.43
0.75
#1
C 0.2 M in.
#2
Pin map
Pin
1
2
connection
Crystal
GND,
thermistor
Crystal
thermistor
0.65
3
#4
0.65
#3
4
