Part Number:
38214
UL Type PV Wire, (1) 14 AWG (41x30) TC, XLPE/PVC, 600V, 90°C
Product Description
One 14 AWG stranded (41x30) tinned copper conductors, cross-linked polyethylene insulation, PVC jacket.
Technical Specifications
Product Overview
Suitable Applications:
Interconnection wiring of grounded and ungrounded photovoltaic power systems as described in Section 690.31(A) of the 2008 NEC.
Physical Characteristics (Overall)
Conductor
AWG Stranding
14
41x30
Material
No. of Conductors
TC - Tinned Copper 1
1
14 AWG
Conductor Count:
Conductor Size:
Insulation
Material
Nominal Wall Thickness
XLPE - Cross Linked Polyethylene 0.048 in
XLPE - Cross Linked Polyethylene
Outer Jacket Material
Material
Nominal Diameter Nominal Wall Thickness
0.033 in
PVC - Polyvinyl Chloride 0.243 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
2.4 Ohm/1000ft
Current
Element
Max. Recommended Current [A]
Single conductor in free air @ 30 ambient 35 amps
Voltage
UL Voltage Rating
600 V
Temperature Range
UL Temp Rating:
Operating Temp Range:
90°C Wet/Dry
-40°C To +90°C
Mechanical Characteristics
Bulk Cable Weight:
Max Recommended Pulling Tension:
36 lbs/1000ft
53.5 lbs
Min Bend Radius/Minor Axis:
2.4375 in
Standards
NEC/(UL) Specification:
UL AWM Style:
Military Specification:
PV, RHW-2, USE-2
N/A
N/A
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (ROHS II):
EU Directive 2012/19/EU (WEEE):
EU Directive 2015/863/EU:
EU Directive Compliance:
Yes
Yes
Yes
Yes
Yes
EU Directive 2003/11/EC (BFR)
EU RoHS Compliance Date (yyyy-mm-dd): 2009-09-01
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Yes
Yes
Suitability
Suitability - Sunlight Resistance:
Yes
Flammability, LS0H, Toxicity Testing
UL Flammability:
UL voltage rating:
VW-1
600 V RMS
Plenum/Non-Plenum
Plenum (Y/N):
No
Part Number
Variants
Item #
Color Footnote
38214 0101000 Black
38214 0105000 Black
Footnote:
C
C - CRATE REEL PUT-UP.
