6220/12C SL002

Description
MULTI-PAIR 25COND 22AWG 500'
CategoryWire/cable
File Size180KB,4 Pages
ManufacturerAlpha Wire
Websitehttp://www.alphawire.com/zh-CN/
Environmental Compliance
Download Datasheet Parametric Compare View All

6220/12C SL002 Overview

MULTI-PAIR 25COND 22AWG 500'

6220/12C SL002 Parametric

Parameter NameAttribute value
Cable typeMultiple pairs
Number of conductors25 (12.5 twisted pairs)
Wire gauge22 AWG
Number of wire strands7/28
conductor materialCopper, tin plated
Sheath (insulation) materialPolyvinyl chloride (PVC)
Sheath (insulation) diameter0.580"(14.73mm)
Shield typefoil
length500.0'(152.4m)
Casing colorslate color
grade-
characteristicdrain wire, drawstring
Voltage300V
Operating temperature-20°C ~ 80°C
use-
Sheath (insulation) thickness0.0500"(1.270mm)
conductor insulationFoamed polypropylene (FPP)
shielding materialaluminum
Shielding range100%
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 6220/12C
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Pair
1
2
3
4
c) Pair
(1) Twists:
2) Component 2
a) Conductor
b) Insulation
(1) Color(s)
Cond
1
3) Cable Assembly
a) Twists:
4) Shield:
a) Foil Direction
b) Drain Wire
5) Jacket
a) Color(s)
b) Ripcord
Color
RED
13 Components Cabled
1.7 Twists/foot (min)
Alum/Mylar Tape, 25% Overlap, Min.
Foil Facing Out
22 (7/30) AWG TC
0.050" Wall, Nom.,PVC
SLATE
1 End 810 Denier Nylon
ALPHA WIRE-* P/N 6220/12C 12PR / 1C 22 AWG
SHIELDED 75C (UL) TYPE CM OR AWM 2919 LOW VOLTAGE
COMPUTER CABLE --- LLXXXXXX CSA TYPE CMG 60C FT4
CE ROHS
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
0.580 (0.619 Max.)
Cond
Color
Cond
Color
Color
BLACK-RED
BLACK-WHITE
BLACK-GREEN
BLACK-BLUE
12 X 1 PAIR
22 (7/30) AWG TC
0.020" Wall, Nom. Polyethylene, Foam
Alpha Wire Color Code A
Pair
5
6
7
8
Color
BLACK-BROWN
BLACK-YELLOW
BLACK-ORANGE
RED-GREEN
Pair
9
10
11
12
Color
RED-WHITE
RED-BLUE
RED-YELLOW
RED-BROWN
0.030
0.070
2/Cond Cabled Together
6.0 Twists/foot (min)
1 X 1 COND
22 (7/30) AWG TC
0.020" Wall, Nom. Polyethylene, Foam
0.030
0.070
c) Print
Applicable Specifications

6220/12C SL002 Related Products

6220/12C SL002 6220/12C SL001
Description MULTI-PAIR 25COND 22AWG 500' MULTI-PAIR 25COND 22AWG 1000'
Cable type Multiple pairs Multiple pairs
Number of conductors 25 (12.5 twisted pairs) 25 (12.5 twisted pairs)
Wire gauge 22 AWG 22 AWG
Number of wire strands 7/28 7/28
conductor material Copper, tin plated Copper, tin plated
Sheath (insulation) material Polyvinyl chloride (PVC) Polyvinyl chloride (PVC)
Sheath (insulation) diameter 0.580"(14.73mm) 0.580"(14.73mm)
Shield type foil foil
length 500.0'(152.4m) 1000.0'(304.8m)
Casing color slate color slate color
characteristic drain wire, drawstring drain wire, drawstring
Voltage 300V 300V
Operating temperature -20°C ~ 80°C -20°C ~ 80°C
Sheath (insulation) thickness 0.0500"(1.270mm) 0.0500"(1.270mm)
conductor insulation Foamed polypropylene (FPP) Foamed polypropylene (FPP)
shielding material aluminum aluminum
Shielding range 100% 100%
