The ECF40 series is designed to minimize the no load power consumption and maximize efficiency
to facilitate equipment design to meet the latest environmental legislation. Approved for medical and
ECF40:
ITE applications in either Class I or Class II installations, this range of single output AC-DC power supplies
3.00 x 1.50 x 1.10” (76.2 x 38.1 x 28.0 mm)
are packaged in a low profile 1.1” height with a foot print of just 1.5” by 3”. The ECF40 provides up to
40W convection-cooled over the full 90-264 VAC input range, and operates down to 80 VAC with minimal
de-rating. The power supply features two AC line fuses and low leakage currents required by medical applications. The low profile, low noise and safety
approvals covering ITE and medical standards allows the versatile ECF40 series to be used in a wide range of applications.
Models & Ratings
Output Power
40 W
40 W
40 W
40 W
40 W
40 W
Notes
1. Typical efficiency measured at full load and 230 VAC input.
Output Voltage
12.0 V
15.0 V
18.0 V
24.0 V
36.0 V
48.0 V
Output Current
3.34 A
2.67 A
2.23 A
1.67 A
1.11 A
0.83 A
Efficiency
(1)
91%
92%
93%
91%
90%
90%
Model Number
ECF40US12
ECF40US15
ECF40US18
ECF40US24
ECF40US36
ECF40US48
Mechanical Details
Output Voltage Control
L1
3.00 (76.2)
Ø0.14 (3.6) through in 4 positions
CN1 - Input Connector
Pin 1
Pin 2
Pin 3
Neutral
Not Fitted
Line
C2
1.25 (31.57)
1.5 (38.1)
Line
Neutral
TR1
C13
-VE
+VE
C14
Output
Terminals
Mates with JST housing VHR-3N and JST
Series SVH-21T-P1.1 crimp terminals
Mounting hole marked with
must be
connected to safety earth for class I
applications
0.13
(3.18)
0.13
(3.18)
2.75 (69.85)
CN2 - Output Connector
1.11
(28.14)
Pin 1
Pin 2
+Vout
-Vout
Mates with JST housing VHR-2N and JST
Series SVH-21T-P1.1 crimp terminals
Notes
1. All dimensions shown in inches (mm).
Tolerance: ±0.02 (0.5)
2. Weight: 0.15 lbs (69 g) approx.
1
www.xppower.com
ECF40 Series
Summary
Characteristic
Input Range
No Load Input Power
Efficiency
Operating Temperature
Safety Approvals
ITE
Medical
-25
90
+70
Minimum
80
Typical
115/230
Maximum
264
0.15
AC-DC Power Supplies
Units
VAC
W
%
°C
Notes & Conditions
Derate output from 100% at 90 VAC to 90% at 85 VAC and
80% at 80 VAC
230 VAC (see fig.1 & 2)
See derating curve (fig.3)
IEC60950, UL60950-1, CSA 22.2 No.60950-1-11 Ed 2, EN60950-1, LVD
IEC60601-1 Ed 3.1 Including Risk Management, ANSI/AAMI ES60601-1 & CSA C22.2 No.6061-1:08, EN60601-1
Input
Characteristic
Input Voltage - Operating
Input Frequency
Power Factor
Input Current - Full Load
Inrush Current
Earth Leakage Current
No load Input Power
Input Protection
0.8/0.4
60
250
0.15
A
A
µA
W
Minimum
80
47
Typical
115/230
50/60
Maximum
264
63
Units
VAC
Hz
Notes & Conditions
Derate output from 100% at 90 VAC to 90% at 85 VAC and
80% at 80 VAC
Agency approval, 47-63 Hz
EN61000-3-2 class A
115/230 VAC
264 VAC cold start, 25
ºC
264 VAC/60 Hz
T3.15 A/250 A, 250 V Internal fuse fitted in line and neutral.
Output - Main Output
Characteristic
Output Voltage
Initial Set Accuracy
Output Voltage Adjustment
Minimum Load
Start Up Delay
Output Rise Time
Hold Up Time
Line Regulation
Load Regulation
Transient Response
Over/Undershoot
Ripple & Noise
Overvoltage Protection
Overload Protection
Short Circuit Protection
Temperature Coefficient
0.05
%/˚C
115
110
8.3/20
±0.5
1
4
5
3/2
140
160
10
0
1
50
2
Minimum
12
Typical
Maximum
48
±1
Units
VDC
%
%
A
s
ms
ms
%
%
%
%
% pk-pk
%
% I nom
Continuous trip and restart (hiccup)
Min at full load 115/230 VAC
90-264 VAC
0-100% load.
Recovery within 1% in less than 500 µs
for a 50-75% and 75-50% load step
Full load
12 V/15-48 V models
Vnom, recycle input to reset
No minimum load required
Notes & Conditions
See Models and Ratings table
50% load, 115/230 VAC
General
Characteristic
Efficiency
Isolation: Input to Output
Input to Ground
Output to Ground
Power Density
Mean Time Between Failure
Weight
500
0.15 (69.0)
4000
1500
500
8.1
Minimum
Typical
90
Maximum
Units
%
VAC
VAC
VAC
W/in
3
kHrs
lb(g)
MIL-HDBK-217F, Notice 2 +25
°C GB
Notes & Conditions
Average active mode efficiency at 25%, 50%, 75% and
100% load
2 MOPP
1 MOPP
1 MOPP at output voltage
www.xppower.com
2
ECF40 Series
Efficiency Vs Load
Figure 1
ECF40US12
AC-DC Power Supplies
100
Efficiency (%)
95
90
85
80
75
70
25
50
Load (%)
75
100
115VAC
230VAC
Figure 2
ECF40US24
100
Efficiency (%)
95
90
85
80
75
70
25
50
Load (%)
75
100
115VAC
230VAC
Environmental
Characteristic
Operating Temperature
Storage Temperature
Humidity
Operating Altitude
Shock
Vibration
Minimum
-25
-40
5
Typical
Maximum
+70
+85
95
5000/4000
Units
°C
°C
%RH
m
Non-condensing
ITE/Medical
Notes & Conditions
See derating curve, fig.3
±3 x 30g shocks in each plane, total 18 shocks. 30g = 11ms (+/- 0.5msecs), half sine. Conforms to EN60068-2-27
Single axis 10-500 Hz at 2g sweep and endurance at resonance in all 3 planes. Conforms to EN60068-2-6
3
www.xppower.com
ECF40 Series
Temperature Derating Curve
Figure 3
100
Some specification parameters
may not be met
AC-DC Power Supplies
Output Load (%)
50
EMC: Emissions
Phenomenon
Conducted
Radiated
Harmonic Current
Voltage Functions
0
-25 -20
0
+50
Ambient Temperature (ºC)
+70
Standard
EN55011/32
EN55011/32
EN61000-3-2
EN61000-3-3
Test Level
Class B
Class A
Class A
Criteria
Notes & Conditions
EMC: Immunity
Phenomenon
Medical Device EMC
Low Voltage PSU EMC
ESD
Radiated
EFT
Surge
Conducted
Magnetic Fields
Standard
IEC60601-1-2
EN61204-3
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
Test Level
Ed.4.0 : 2014
High severity level
±8kV contact, ±15kV air
3
3
Installation class 3
3
4
Dip 100% (0 VAC), 8.4 ms
Dip 100% (0 VAC), 16.7 ms
EN61000-4-11 (100 VAC)
Dip 60% (40 VAC), 200 ms
Dip 30% (70 VAC), 500 ms
Dip 20% (80 VAC), 5000 ms
Int 100% (0 VAC), 5000 ms
Dip 100% (0 VAC), 8.4 ms
Dip 100% (0 VAC), 16.7 ms
EN61000-4-11 (115 VAC)
Dip 60% (40 VAC), 200 ms
Dip 30% (70 VAC), 500 ms
Dip 20% (80 VAC), 5000 ms
Dip
100% (0 VAC), 10 ms
Dips and Interruptions
EN61000-4-11 (240 VAC)
Int 100% (0 VAC), 5000 ms
Criteria
as below
as below
A
A
A
A
A
A
A
B
B
B
B
B
A
B
B
B
B
B
A
B
B
B
B
A
A
A
B
A
A
A
B
A
A
30% derating
60% derating
75% derating
B
25% derating
Notes & Conditions
Dip 100% (0 VAC), 20 ms
Dip 60% (96 VAC), 200 ms
Dip 30% (168 VAC), 500 ms
Int 100% (0 VAC), 5000 ms
Dip
100% (0 VAC), 10 ms
Dip 100% (0 VAC), 20 ms
Dip 60% (40 VAC), 100 ms
Dip 30% (70 VAC), 500 ms
Dip
100% (0 VAC), 10 ms
Int 100% (0 VAC), 5000 ms
Dip 100% (0 VAC), 20 ms
Dip 60% (96 VAC), 100 ms
Int 100% (0 VAC), 5000 ms
Dip 20% (192 VAC), 5000 ms
EN60601-1-2 (100 VAC)
EN60601-1-2 (240 VAC)
Dip 30% (168 VAC), 500 ms
www.xppower.com
4
ECF40 Series
Safety Approvals
Safety Agency
CB Report
UL
TUV
CE
Safety Standard
IEC60950-1, IEC62368-1
UL60950-1, CSA 22.2 No.60950-1
EN60950-1, EN62368-1
LVD
AC-DC Power Supplies
Notes & Conditions
Information Technology
Information Technology
Information Technology
Safety Agency
CB Report
UL
CE
Safety Standard
IEC60601-1 Ed 3.1 Including Risk Management
ANSI/AAMI ES60601-1: & CSA C22.2 No.6061-1:08
EN60601-1
Notes & Conditions
Medical
Medical
Medical
Isolation
Primary to Secondary
Primary to Earth
Secondary to Earth
Safety Standard
2 x MOPP (Means of Patient Protection)
1 x MOPP (Means of Patient Protection)
1 x MOPP (Means of Patient Protection) at output voltage
