DESCRIPTION: QUIK-LOQ - FEMALE - VERTICAL - PANEL MOUNT
821B YYY - 2 1 3 R 00 1
SERIES
12.00 [0.475]
# OF POSITIONS
(Ex. 002)
**SEE CHART A**
2 = FEMALE
VERTICAL (PANEL MOUNT)
1 = GOLD FLASH
UNITS = MM [INCHES]
CHARACTERISSTICS
MATERIALS
SHELL : BRASS
SHELL PLATING : NICKEL
NUT : BRASS
NUT PLATING : NICKEL
LATCH SLEEVE : BRASS
LATCH SLEEVE PLATING : NICKEL
CONTACTS : COPPER ALLOY
CONTACT PLATING : 7µ" GOLD PLATED OVER 196µ" NICKEL MIN.
INSULATOR : PPS (HIGH TEMPERATURE)
MECHANICAL
DURABILITY: 5000 CYCLES
OPERATING TEMP. RANGE: -40 C ~ +200 C
PROCESS TEMPERATURE : 260 C FOR 5 SECONDS
MAX. TORQUE VALUE : 4.5 Nm [39 IN/lbs]
SHIELDING: 75dB @ 10MHz
40dB @ 1GHz
IP RATING: 50
1
4
[0.
2.1
]
76
RoHS COMPLIANT
NICKEL/CHROME PLATED SHELL
0.945
24.00
0.736
18.70
0.126
3.20
0.413
10.50
(ACROSS FLATS)
M12*1.0
0.551
14.00
0.630
16.00
0.417
10.60
PANEL CUTOUT
TOLERANCE = +0.10, -0.0
[+0.004, -0.00]
0.197
5.00
(MAX. PANEL THICKNESS)
CHART A
1
1
= KEY LOCATION
1
1
**VIEW FROM TERMINATION END**
1
1
**NOTE**
SEE PAGE 2 FOR BOARD LAYOUTS
1
1
1
2 POSITION
15 AMP MAX.
PIN
= 1.30 [0.051]
3 POSITION
12 AMP MAX.
PIN
= 1.30 [0.051]
4 POSITION
10 AMP MAX.
PIN
= 0.90 [0.035]
5 POSITION
9 AMP MAX.
PIN
= 0.90 [0.035]
6 POSITION
7 AMP MAX.
PIN
= 0.70 [0.028]
7 POSITION
7 AMP MAX.
PIN
= 0.70 [0.028]
8 POSITION
5 AMP MAX.
= 0.70 [0.028]
PIN
10 POSITION
2.5 AMP MAX.
PIN
= 0.50 [0.020]
14 POSITION
2 AMP MAX.
PIN
= 0.50 [0.020]
CONTACT
RESISTANCE
= 5 m
Ω
TEST VOLTAGE
= 1500V
WORKING VOLTAGE
= 500V
CONTACT
RESISTANCE
= 5 mΩ
TEST VOLTAGE
= 1300V
WORKING VOLTAGE
= 430V
CONTACT
RESISTANCE
= 6 mΩ
TEST VOLTAGE
= 1300V
WORKING VOLTAGE
= 430V
CONTACT
RESISTANCE
= 6 m
Ω
TEST VOLTAGE
= 1250V
WORKING VOLTAGE
= 415V
CONTACT
RESISTANCE
= 7.5 m
Ω
TEST VOLTAGE
= 1050V
WORKING VOLTAGE
= 350V
CONTACT
RESISTANCE
= 7.5 m
Ω
TEST VOLTAGE
= 950V
WORKING VOLTAGE
= 315V
CONTACT
RESISTANCE
= 7.5 m
Ω
TEST VOLTAGE
= 950V
WORKING VOLTAGE
= 315V
CONTACT
RESISTANCE
= 10 m
Ω
TEST VOLTAGE
= 900V
WORKING VOLTAGE
= 300V
CONTACT
RESISTANCE
= 10 m
Ω
TEST VOLTAGE
= 800V
WORKING VOLTAGE
= 260V
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
DRAWN:
DATE:
SCALE:
SHEET
OF
REV:
M. SIGMON
CHECKED:
DATE:
02-10-16
N.T.S.
1
DWG NO.
2
1
821BYYY-213R001
DESCRIPTION: QUIK-LOQ - FEMALE - VERTICAL - PANEL MOUNT
UNITS = MM [INCHES]
BOARD LAYOUTS
= KEY LOCATION
A
A
45° .
P
TY
A
2 POS
A = 0.80 [0.031]
B = 2.80 [0.110]
3 POS
A = 0.80 [0.031]
B = 3.00 [0.118]
4 POS
A = 0.80 [0.031]
B = 3.40 [0.134]
3
TY 6°
P.
B
5 POS
A = 0.80 [0.031]
B = 3.40 [0.134]
6 POS
A = 0.80 [0.031]
B = 3.70 [0.146]
3°
°
22
TY . 5 °
P.
A
51
.4
10
2.
86
18°
.
T YP
°
45 P.
TY
3
TY 6°
P.
60
TY °
P.
B
C
B
25
1
.7
°
B
10 POS
7 POS
A = 0.80 [0.031]
B = 3.70 [0.146]
B
14 POS
A = 0.60 [0.024]
B = 4.40 [0.173]
C = 1.80 [0.071]
8 POS
A = 0.80 [0.031]
B = 3.80 [0.150]
A = 0.60 [0.024]
B = 3.95 [0.156]
C = 1.40 [0.055]
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
DRAWN:
DATE:
SCALE:
SHEET
60
TY °
P.
B
B
B
A
°
72 P.
TY
0°
12 P.
TY
A
A
A
A
C
OF
REV:
M. SIGMON
CHECKED:
DATE:
02-10-16
N.T.S.
2
DWG NO.
2
1
821BYYY-213R001
