High Current Molded Power Inductor - PA4547.XXXNLT Series
Height: 1.5mm Max
Footprint: 3.8mm x 3.7mm Max
Current Rating: up to 5.5A
Inductance Range: 0.47uH to 10.0uH
High current, low DCR, and high efficiency
High reliability
Minimized acoustic noise and minimized leakage flux noise
Electrical Specifications @ 25°C - Operating Temperature -55°C to +125°C
Part
Number
PA4547.471NLT
PA4547.561NLT
PA4547.681NLT
PA4547.102NLT
PA4547.152NLT
PA4547.222NLT
PA4547.332NLT
PA4547.472NLT
PA4547.562NLT
PA4547.682NLT
PA4547.822NLT
PA4547.103NLT
Inductance
100KHz, 1.0V
uH±20%
0.47
0.56
0.68
1.00
1.50
2.20
3.30
4.70
5.60
6.80
8.20
10.00
Rated
Current
A
5.50
5.00
4.50
3.60
3.40
3.20
2.50
1.90
1.70
1.50
1.30
1.20
DC
Resistance
MAX.
mΩ
28
33
42
50
77
98
205
264
318
348
468
522
TYP.
mΩ
23.3
28
34
41
64
82
170
220
265
290
390
435
Saturation
Current
A
8.0
7.2
6.5
5.8
4.0
3.8
3.2
2.8
2.3
2.0
1.8
1.6
1
power.pulseelectronics.com
P824. C (11/17)
http://www.power.pulseelectronics.com/contact
SMT Power Inductor
High Current Molded Power Inductor - PA4547.XXXNLT Series
Notes:
1.
2.
Actual temperature of the component during system operation (ambient plus
temperature rise) must be within the standard operating range.
The saturation current is the current at which the initial inductance drops ap-
proximately 30% at the stated ambient temperature. This current is determined by
placing the compnent in the specified ambient environment and applying a short
duration pulse current (to eliminate self-heating effect) to the component.
The rated current is the DC current required to raise the component temperature by
approximately 40˚C. Take note that the components’ performanc varies depending
on the system condition. It is suggested that the component be tested at the system
level, to verify the temperature rise of the component during system operation.
The part temperature (ambient+temp rise) should not exceed 125½C under worst
case operating conditions. Circuit design, PCB trace size and thickness, airflow and
other cooling provisions all affect the part temperature. Part temperature should be
verified in the end application.
4.
3.
Mechanical
PA4547.XXXNLT
A
C
D
L
H
XXX
FINAL LAYOUT
B
E
G
SUGGESTED PAD LAYOUT
C
1.3±0.2
D
0.7±0.2
E
1.2±0.2
L
4.1
G
1.9
H
1.45
Series
PA4547.XXXNLT
All Dimensions in mm.
A
3.5±0.3
B
3.2±0.2
TAPE & REEL INFO
Marking
Marking
W
A
K
0
P
1
Direction of tape
G
SURFACE MOUNTING TYPE, REEL/TAPE LIST
REEL SIZE (mm)
A
PA4547.XXXNLT
Ø330
G
12.4
P
1
8
TAPE SIZE (mm)
W
12
K
0
1.8
QTY
PCS/REEL
3000
2
power.pulseelectronics.com
P824. C (11/17)
http://www.power.pulseelectronics.com/contact
SMT Power Inductor
High Current Molded Power Inductor - PA4547.XXXNLT Series
Typical Performance Curves
PA4547.471NLT
PA4547.561NLT
0.8
80
1
80
0.64
64
0.8
64
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
0.48
48
0.6
48
0.32
32
0.4
32
0.16
16
0.2
16
0
0
1.6
DC CURRENT(A)
3.2
4.8
6.4
8
0
0
0
2
DC CURRENT(A)
4
6
8
10
0
1
PA4547.681NLT
80
1.4
PA4547.102NLT
80
0.8
64
1.12
64
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
0.6
48
0.84
48
0.4
32
0.56
32
0.2
16
0.28
16
0
0
1.38
DC CURRENT(A)
2.76
4.14
5.52
6.9
0
0
0
1.16
DC CURRENT(A)
2.32
3.48
4.64
5.8
0
2.5
PA4547.152NLT
50
4
PA4547.222NLT
60
2
40
3.2
48
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
1.5
30
2.4
36
1
20
1.6
24
0.5
10
0.8
12
0
0
0.8
DC CURRENT(A)
1.6
2.4
3.2
4
0
0
0
0
0.76
DC CURRENT(A)
1.52
2.28
3.04
3.8
3
power.pulseelectronics.com
P824. C (11/17)
http://www.power.pulseelectronics.com/contact
TEMP. RISE(
o
C)
TEMP. RISE(
o
C)
TEMP. RISE(
o
C)
SMT Power Inductor
High Current Molded Power Inductor - PA4547.XXXNLT Series
PA4547.332NLT
PA4547.472NLT
5
85
7
110
4
68
5.6
88
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
3
51
4.2
66
2
34
2.8
44
1
17
1.4
22
0
0
0.64
DC CURRENT(A)
1.28
1.92
2.56
3.2
0
0
0
0.56
DC CURRENT(A)
1.12
1.68
2.24
2.8
0
8
PA4547.562NLT
100
10
PA4547.682NLT
60
6.4
80
8
48
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
4.8
60
6
36
3.2
40
4
24
1.6
20
2
12
0
0
0.46
DC CURRENT(A)
0.92
1.38
1.84
2.3
0
0
0
0.4
DC CURRENT(A)
0.8
1.2
1.6
2
0
12
PA4547.822NLT
60
13
PA4547.103NLT
80
9.6
48
10.4
64
INDUCTANCE (uH)
INDUCTANCE (uH)
TEMP. RISE(
o
C)
7.2
36
7.8
48
4.8
24
5.2
32
2.4
12
2.6
16
0
0
0.36
DC CURRENT(A)
0.72
1.08
1.44
1.8
0
0
0
0.32
DC CURRENT(A)
0.64
0.96
1.28
1.6
0
4
power.pulseelectronics.com
P824. C (11/17)
http://www.power.pulseelectronics.com/contact
TEMP. RISE(
o
C)
TEMP. RISE(
o
C)
TEMP. RISE(
o
C)
SMT Power Inductor
High Current Molded Power Inductor - PA4547.XXXNLT Series
For More Information
Pulse Worldwide
Pulse Europe
Headquarters
Pulse Electronics GmbH
15255 Innovation Drive Ste 100 Am Rottland 12
San Diego, CA 92128
58540 Meinerzhagen
U.S.A.
Germany
Pulse China Headquarters
Pulse Electronics (ShenZhen) CO., LTD
D708, Shenzhen Academy of
Aerospace Technology,
The 10th Keji South Road,
Nanshan District, Shenzhen,
P.R. China 518057
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yan An Road West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Pulse South Asia
135 Joo Seng Road
#03-02
PM Industrial Bldg.
Singapore 368363
Pulse North Asia
1F., No.111 Xiyuan Rd
Zhongli City
Taoyuan City 32057
Taiwan (R.O.C)
Tel: 858 674 8100
Fax: 858 674 8262
Tel: 49 2354 777 100
Fax: 49 2354 777 168
Tel: 65 6287 8998
Fax: 65 6280 0080
Tel: 886 3 4356768
Fax: 886 3 4356820
