DESCRIPTION: QUIK-LOQ - FEMALE - VERTICAL - PANEL MOUNT
1.083
27.50
0.787
20.00
0.138
3.50
UNITS = MM [INCHES]
CHARACTERISSTICS
MATERIALS
SHELL : BRASS
SHELL PLATING : NICKEL
NUT : BRASS
NUT PLATING : NICKEL
LATCH SLEEVE : BRASS
LATCH SLEEVE PLATING : NICKEL
CONTACTS : COPPER ALLOY
CONTACT PLATING : 7µ" GOLD PLATED OVER 196µ" NICKEL MIN.
INSULATOR : PPS (HIGH TEMPERATURE)
MECHANICAL
DURABILITY: 5000 CYCLES
OPERATING TEMP. RANGE: -40 C ~ +200 C
PROCESS TEMPERATURE : 260 C FOR 5 SECONDS
MAX. TORQUE VALUE : 6.0 Nm [53 IN/lbs]
SHIELDING: 75dB @ 10MHz
40dB @ 1GHz
IP RATING: 50
0.531
13.50
(ACROSS FLATS)
M15*1.0
0.709
18.00
0.787
20.00
0.177
4.50
(MAX. PANEL THICKNESS)
822B YYY - 2 1 3 R 00 1
SERIES
15.00 [0.591]
**VIEW FROM TERMINATION END**
1
1
1
1 = GOLD FLASH
CHART A
1
1
= KEY LOCATION
# OF POSITIONS
(Ex. 002)
**SEE CHART A**
2 = FEMALE
VERTICAL (PANEL MOUNT)
RoHS COMPLIANT
NICKEL/CHROME PLATED SHELL
59
4]
2 POSITION
30 AMP MAX.
PIN
= 2.00 [0.079]
CONTACT
RESISTANCE
= 3 mΩ
TEST VOLTAGE
= 2100V
WORKING VOLTAGE
= 700V
3 POSITION
17 AMP MAX.
PIN
= 1.60 [0.063]
CONTACT
RESISTANCE
= 4 mΩ
TEST VOLTAGE
= 2400V
WORKING VOLTAGE
= 800V
4 POSITION
15 AMP MAX.
PIN
= 1.30 [0.051]
CONTACT
RESISTANCE
= 5 mΩ
TEST VOLTAGE
= 1850V
WORKING VOLTAGE
= 610V
6 POSITION
12 AMP MAX.
PIN
= 1.30 [0.051]
CONTACT
RESISTANCE
= 5 mΩ
TEST VOLTAGE
= 1350V
WORKING VOLTAGE
= 450V
8 POSITION
10 AMP MAX.
PIN
= 0.90 [0.035]
CONTACT
RESISTANCE
= 6 mΩ
TEST VOLTAGE
= 1500V
WORKING VOLTAGE
= 500V
.
15
0.
1[
1
1
1
1
1
1
0.535
13.60
PANEL CUTOUT
10 POSITION
8 AMP MAX.
= 0.90 [0.035]
PIN
CONTACT
RESISTANCE
= 6 mΩ
TEST VOLTAGE
= 1450V
WORKING VOLTAGE
= 500V
12 POSITION
7 AMP MAX.
PIN
= 0.70 [0.028]
CONTACT
RESISTANCE
= 7.5 mΩ
TEST VOLTAGE
= 1250V
WORKING VOLTAGE
= 480V
14 POSITION
6.5 AMP MAX.
PIN
= 0.70 [0.028]
CONTACT
RESISTANCE
= 7.5 mΩ
TEST VOLTAGE
= 1150V
WORKING VOLTAGE
= 380V
16 POSITION
6 AMP MAX.
PIN
= 0.70 [0.028]
CONTACT
RESISTANCE
= 7.5 mΩ
TEST VOLTAGE
= 950V
WORKING VOLTAGE
= 315V
19 POSITION
5 AMP MAX.
PIN
= 0.70 [0.028]
CONTACT
RESISTANCE
= 7.5 mΩ
TEST VOLTAGE
= 850V
WORKING VOLTAGE
= 280V
26 POSITION
2 AMP MAX.
PIN
= 0.50 [0.020]
CONTACT
RESISTANCE
= 10 mΩ
TEST VOLTAGE
= 950V
WORKING VOLTAGE
= 315V
TOLERANCE = +0.10, -0.0
[+0.004, -0.00]
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
**NOTE**
SEE PAGE 2 FOR
BOARD LAYOUTS
SCALE:
DRAWN:
M. SIGMON
DATE:
02-10-16
N.T.S.
SHEET
1
OF
2
REV:
2
CHECKED:
DATE:
DWG NO.
822BYYY-213R001
DESCRIPTION: QUIK-LOQ - FEMALE - VERTICAL - PANEL MOUNT
UNITS = MM [INCHES]
BOARD LAYOUTS
= KEY LOCATION
22.5°
TYP.
A
A
A
45
TYP°
.
45
TY °
P.
A
A
A
°
54 .
P
TY
0°
12 P.
TY
B
B
B
7
TY 2°
P.
B
B
B
C
2 POS
A = 0.80 [0.031]
B = 4.40 [0.173]
3 POS
A = 0.80 [0.031]
B = 4.60 [0.181]
4 POS
A = 0.80 [0.031]
B = 5.00 [0.197]
6 POS
A = 0.80 [0.031]
B = 5.60 [0.220]
8 POS
A = 0.80 [0.031]
B = 6.40 [0.252]
10 POS
A = 0.80 [0.031]
B = 6.20 [0.244]
C = 2.15 [0.085]
20°
TYP.
22.5°
TYP.
45
TY °
P.
18°
TYP.
A
8.1
TY 8°
P.
°
.36
16 YP.
T
7
TY 2°
P.
A
3
TY 0°
P.
60
TY °
P.
D
B
A
°
120 P.
TY
10°
TYP.
36°
TYP
.
54
TY °
P.
B
C
B
B
32.7
3
TYP °
.
15°
TYP.
40°
TYP
.
C
B
12 POS
A = 0.80 [0.031]
B = 6.50 [0.256]
C = 2.8 [0.110]
26 POS
16 POS
19 POS
A = 0.80 [0.031]
B = 6.70 [0.264]
C = 3.50 [0.138]
86°
12. P.
TY
14 POS
A = 0.80 [0.031]
B = 6.50 [0.256]
C = 2.65 [0.104]
A = 0.60 [0.024]
B = 7.00 [0.276]
C = 4.20 [0.165]
D = 1.6 [0.063]
A = 0.80 [0.031]
B = 6.60 [0.260]
C = 3.10 [0.122]
N
C
RoHS COMPLIANT
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF NorComp AND
SHALL NOT BE REPRODUCED, COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
NorComp
DRAWN:
M. SIGMON
DATE:
02-10-16
SCALE:
N.T.S.
SHEET
2
OF
25.71°
TYP.
30°
TYP.
5°
.5 .
24 YP
T
C
C
C
A
A
DATE:
CHECKED:
2
REV:
1
DWG NO.
822BYYY-213R001
