Time Delay Relays
Dedicated - Interval
TS2 / TS6 SERIES
Description
The TS2 Series is designed for 24, 120 or 230VAC and the
TS6 Series is designed for 12 or 24VDC. These series are
capable of controlling load currents of up to 1A steady state,
10A inrush. Encapsulated circuitry and the reliability of a
±2% repeat accuracy make the TS2 and TS6 ideal for cost
sensitive applications.
TS2
TS6
Operation (Interval)
Upon application of input voltage, the time delay begins. The
output energizes during the time delay. At the end of the time
delay, the output de-energizes and remains de-energized until
input voltage is removed.
Reset:
Removing input voltage resets the time delay and
the output.
N/L2
Wiring Diagram
L1
Features & Benefits
FEATURES
Analog circuitry
Totally solid state
and encapsulated
V = Voltage
L = Load
R
T
is used when external
adjustment is ordered.
Note: TS6 is not reverse
polarity protected.
BENEFITS
Repeat accuracy + / - 2%,
Factory calibration + / - 10%
No moving parts to arc and wear out over time and
encapsulated to protect against shock, vibration,
and humidity
Provides 100 million operations in typical conditions
Can be used in the harshest environments
1A steady, 10A inrush
solid-state output
Rated for operation
up to 75°C
Accessories
B
A
P1004-XX
(fig. A),
P1004-XX-X
(fig. B)
Versa-Pot
Panel mountable, industrial potentiometer
recommended for remote time delay adjustment.
P1023-6 Mounting bracket
The 90° orientation of mounting slots makes
installation/removal of modules quick and easy.
P0700-7 Versa-Knob
Designed for 0.25 in (6.35 mm) shaft of
Versa-Pot. Semi-gloss industrial black finish.
Ordering Information
MODEL
INPUT
VOLTAGE
ADJUSTMENT
TIME DELAY
SWITCHING
MODE
MODEL
INPUT
VOLTAGE
ADJUSTMENT
TIME DELAY
SWITCHING
MODE
TS22120
TS2223
TS2412
TS24130
TS2421
TS2422
TS2423
24VAC
24VAC
120VAC
120VAC
120VAC
120VAC
120VAC
Fixed
External
Fixed
Fixed
External
External
External
20s
2 - 180s
2s
30s
0.05 - 3s
0.5 - 60s
2 - 180s
n/a
n/a
n/a
n/a
n/a
n/a
n/a
TS2424
TS6116P
TS6122P
TS6123P
TS6321P
TS6323P
120VAC
12VDC
12VDC
12VDC
24VDC
24VDC
External
Fixed
External
External
External
External
5 - 600s
6s
0.5 - 20s
2 - 60s
0.05 - 3s
2 - 180s
n/a
Positive
Positive
Positive
Positive
Positive
If you don’t find the part you need, call us for a custom product 800-843-8848
© 2016 Littelfuse Protection Relays & Controls
www.littelfuse.com/ts2-ts6
Rev: 1-A-061016
Time Delay Relays
Dedicated - Interval
TS2 / TS6 SERIES
Accessories
P1015-64
(AWG 14/16)
Female Quick Connect
These 0.25 in. (6.35 mm) female terminals are
constructed with an insulator barrel to provide
strain relief.
P1015-18 Quick Connect to Screw Adapter
Screw adapter terminal designed for use with
all modules with 0.25 in. (6.35 mm) male quick
connect terminals.
C103PM (AL) DIN Rail
35 mm aluminum DIN rail available in a 36 in.
(91.4 cm) length.
P1023-20 DIN Rail Adapter
Allows module to be mounted on a 35 mm DIN
type rail with two #10 screws.
VTP(X)(X) Plug-on Adjustment Module
Mounts on modules with in-line adjustment
terminals. Rated at 0.25W at 55°C. Available in
resistance values from 5KΩ to 5MΩ.
Selection Table for VTP Plug-on Adjustment Accessory
TS6 12VDC
Time Delay
1
- 0.05-1s
2
- 0.5-20s
3
- 2-60s
4
- 5-120s
VTP P/N
VTP2A
VTP2E
VTP2F
VTP2H
Versa-Pot
(potentiometer)
Selection Guide
Specifications
Time Delay
Type
Range
12VDC
Analog circuitry
0.05 - 120s in 4 adjustable ranges or fixed
(1 MΩ max. R T )
0.05 - 600s in 4 adjustable ranges or fixed
±2% or 20ms, whichever is greater
≤ ±10%
≤ ±10%
≤ 150ms
12 or 24VDC; 24 or20VAC
±15%
10%
DC ≤ 1W; AC ≤ 2VA
Solid state
NO, closed during timing
1A steady state, 10A inrush at 60°C
DC
≅
1.0V @ 1A; AC
≅
2.5V @ 1A
Encapsulated
TS6 is not reverse polarity protected
≥ 2000V RMS terminals to mounting surface
≥ 100 MΩ
Surface mount with one #10 (M5 x 0.8) screw
H
50.8 mm (2”);
W
50.8 mm (2”);
D
30.7 mm (1.21”)
0.25 in. (6.35 mm) male quick connect terminals
Fig. A P/N
P1004-16
P1004-16
P1004-16
P1004-16
Fig. B P/N
P1004-16-X
P1004-16-X
P1004-16-X
P1004-16-X
TS2 & TS6 All Other Voltages
Time Delay
1
- 0.05-3s
2
- 0.5-60s
3
- 2-180s
4
- 5-600s
VTP P/N
VTP4B
VTP4F
VTP4J
VTP5N
Versa-Pot
(potentiometer)
Fig. A P/N
P1004-12
P1004-12
P1004-12
P1004-13
Fig. B P/N
P1004-12-X
P1004-12-X
P1004-12-X
P1004-13-X
Function Diagram
INTERVAL (IMPULSE-ON)
V = Voltage
NO = Normally
Open Contact
NC = Normally
Closed Contact
TD = Time Delay
R = Reset
= Undefined
Time
Other Voltages
Repeat Accuracy
Tolerance
(Factory Calibration)
Time Delay vs Temp.
& Voltage
Reset Time
Input
Voltage
Tolerance
DC Ripple
Power Consumption
Output
Type
Form
Maximum Load Current
Voltage Drop
Protection
Circuitry
Polarity
Dielectric Breakdown
Insulation Resistance
Mechanical
Mounting
Dimensions
Termination
Environmental
Operating/Storage
Temperature
Humidity
Weight
-40° to 75°C / -40° to 85°C
95% relative, non-condensing
≅
2.4 oz (68 g)
© 2016 Littelfuse Protection Relays & Controls
www.littelfuse.com/ts2-ts6
Rev: 1-A-061016
